FinishLynx Gold Package
Please verify that your FinishLynx Gold System contains all the components pictured here. If something is missing, or if you have
questions setting up your system after following this quick start guide, call: 1-800-989-LYNX. For additional tech support documents and
downloads, visit
www.finishlynx.com/support/
Item
Description
Carrying Case
EtherLynx Vision high
sensitivity camera
Timer-Enabled option for
Not pictured
5L500 camera
High Resolution option for
Not pictured
5L500 camera
C-Mount 8-48mm f1.2
Motorized Zoom Lens
CS Mount 2.8-10mm P-Iris
CS Mount to C Mount
Remote positioner
Geared head
Super head clamp
Camera tripod (x2)
8 port 10/100 Power over
Ethernet switch
Virtual photoeye unit & auto
Not pictured
capture plug-in
Be sure to keep your USB flash drive safe. It includes your Serial Numbers, Software, & Quick-Start Guides.
To access the files, insert the flash drive in your computer and click on START.html
Items Not Included
Laptop or netbook computer running Microsoft Windows. Your computer needs: 1 available serial port (or USB port with serial
adapter), and 1 available Ethernet port.
Printer (optional)
FinishLynx Gold Package Quick Start Guide – for Vision cameras
Part #
1A207
5L500
5LTE
5LHR
C848M
CS2810P
lens
MCS-C
Adapter
2L102
BG3275
BG2909
BG3036
PoE-Switch
5LACM
Item
Description
Normally closed start sensor
with light and mount
500 ft. start sensor cable
Connection box
Connection box cable
25 ft. Ethernet cables (x2)
Capture button and
USB/Serial adapter
Button splitter
MicroTab scoreboard,
carrying case and charger
RadioLynx Transmitter and
Receiver - with RadioLynx
start sensor (red casing)
IdentiLynx Full Frame Video
Camera kit
Lynx USB Flash Drive with
FinishLynx32 and LynxPad
Not Pictured
RadioLynx plug-in
Quick Start Guide
Part #
3L400
3L-Mount
3A100
C-Box
451
C10BT-25
1A205
B-SPL
UTabLED
3L900
SR -
IdentiLynx
5LSW and
9LSW01
5LPRL
Page 2
