Acuity Brands HOLOPHANE HLDMC Quick Start Manual

When using electrical equipment, basic safety precautions should always be followed including the following:
• To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/abrasions, and other hazards please read
all warnings and instructions included with and on the fixture box and all fixture labels.
• Before installing, servicing, or performing routine maintenance upon this equipment, follow these general precautions.
• Installation and service of this equipment should be performed by a qualified licensed electrician.
• This equipment is designed for use with germicidal UV radiation sources and must be installed in compliance with competent technical directions to
prevent risk of personal injury from UV radiation.
• UV radiation can pose a risk of personal injury. Overexposure can result in damage to eyes and bare skin. To reduce the risk of overexposure this
equipment must be installed in accordance with the manufacturer's site planning recommendations. This may include instructions on the relative
location of each germicidal system component, the minimum distances between UV-generating devices and other objects or surfaces, and protection
from line-of-sight exposure to UV radiation in occupied spaces located above the equipment mounting area (e. g. upper floor balconies, open
staircases, etc.)
• UV and optical radiation can be reflected by surrounding surfaces such as ceilings and walls. Since the reflective properties of surfaces can vary widely,
it should be considered as part of site planning. Follow the manufacturer's recommendations for selecting appropriate ceiling and wall finishes.
• IT IS THE RESPONSIBILITY OF THE INSTALLER TO ENSURE THAT PERSONS WILL NOT BE EXPOSED TO EXCESSIVE UV OR OPTICAL RADIATION DURING
EQUIPMENT OPERATION. THIS WILL REQUIRE THE INSTALLER TO CONDUCT AN ASSESSMENT OF IRRADIANCE OR ILLUMINANCE LEVELS IN THE
SURROUNDING OCCUPIED SPACES PRIOR TO OCCUPANCY.
• Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by unauthorized personnel.
• Maintenance and servicing of this UV generating equipment shall be performed by authorized personnel. Service personnel must wear appropriate
Personal Protective Equipment (PPE) if the equipment will be in operation during the maintenance or servicing work. Contact the equipment
manufacturer for PPE recommendations and guidance.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Do not use this equipment for other than intended use.
• Take precautions to ensure that the concentration of ozone in the installation is limited to a value that is within applicable permissible exposure limits.
Verify acceptable ozone concentrations in the installation taking into account the number of products in a given volume of space, the characteristics
of the ventilation system, access, and other factors. Permissible exposure limits vary based on the place of ozone application, the length of exposure,
and other factors and are publicly available. For reference, the EPA National Ambient Air Quality Standard is 0.070 ppm maximum concentration
averaged over 8 hours and current OSHA regulations set an eight-hour time-weighted average permissible exposure limit of 0.10 ppm. The amount of
ozone emitted by this equipment does not exceed a concentration of 0.001 ppm over an 8-hour period, as tested in accordance with UL 867.
• Not intended for use with wall switches. Connect to an unswitched circuit intended for 24/7/365 continuous operation.
• All references to "disinfection" are referring generally to the reduction of pathogenic bioburden and are not intended to refer to any specific
definition of the term as may be used for other purposes by the U.S. Food and Drug Administration or the U.S. Environmental Protection Agency. The
disinfection technology as incorporated in Acuity Brands products is not for use as a medical device or for the disinfection of medical devices.
• It is the obligation of the end-user to consult with appropriately qualified Professional Engineer(s), Certified Infection Control professionals, and
Certified Industrial Hygienists, as applicable, to determine whether this equipment and its installation meets the applicable requirements for system
performance, code compliance, safety, suitability and effectiveness for use in a particular application design. In no event will Acuity Brands Lighting be
responsible for any loss resulting from any use of this equipment in an application design.
• DO NOT INSTALL DAMAGED PRODUCT! This equipment has been properly packed so that no parts should have been damaged during transit. Inspect
to confirm. Any part damaged or broken during or after installation should be replaced. Contact the manufacturer for replacement.
• Follow all disposal laws when replacing or disposing. Excimer lamps do not contain hazardous materials and can be recycled by standard electronics
recyclers.
• Do not install below the minimum height specified in these installation instructions.
• This equipment, including the lamp modules, must be stored in a dust-free environment and be handled while wearing clean gloves. Since Far-UVC
radiation is absorbed by proteins and other organic compounds, accumulation of dust particles or touching of the optical radiation surface will
negatively impact the output of the UV radiation source and its germicidal power.
• Replacement lamp modules must be purchased through Acuity Brands Lighting. Contact Acuity Brands Lighting when module reaches end of life.
These instructions do not purport to cover all details or variations in equipment nor to provide every possible contingency to meet in connection with
•
installation, operation, or maintenance. Should further information be desired, or should problems arise which are not covered sufficiently for the
purchaser's or owner's purposes, please contact the Holophane Field Service Department at (740) 345-9631.
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION
Holophane | 3825 Columbus Rd., Granville, OH 43023 | Phone:
© 2021 Acuity Brands Lighting, Inc. All rights reserved.
HLDM Cylinders UVC Module Repair Kit
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
IMPORTANT SAFETY INSTRUCTIONS
OCCUPIED SPACES DIRECT IRRADIATION UV EQUIPMENT
866-HOLOPHANE | www.holophane.com
Page 1 of 6
912-00264-004
Rev. F | 09/22/22
