Summary of Contents for Asus AY2401
- Page 1 E23412 First Edition / March 2024 Service Manual...
- Page 2 Warranty Statement, up to the listed contract price of each product. ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement.
- Page 3 Table of Contents Disclaimer ........................4 Guidelines........................4 Repair Tooling List .....................6 ASUS AY2401 overview ...................8 Major components ....................10 Disassembly .........................16 Assembly ........................22 Service Manual...
- Page 4 ASUS parts and correct tools. Please note that the product’s water resistance is not guaranteed if it is repaired by someone without the necessary skills.
- Page 5 • Ensure that the AeroActive Cooler X (AY2401) is powered down. • Disconnect the AC plug from the AeroActive Cooler X (AY2401). • Remove all rings, watches and any other metal objects from your hands. • Always wear a grounding strap on your hand to protect the AeroActive Cooler X (AY2401) from static discharge.
- Page 6 Repair Tooling List NOTE: The tools without part numbers can be purchased from electronics supply stores. 1. Thermal grease 3. Heating Platform for ROG 8: TSP- Waterproof Oil (110V) RIC-D1060 Part Number: Part Number: Part Number: 16TT0-000K8000 16TT0-000B8000 20LT0-00075000 4. Thermal Grease Plastic Blade Brush Fixtures...
- Page 7 10. Anti-Static Mat 11. ESD Gloves Service Manual...
- Page 8 ASUS AY2401 overview Top view Power button cover Cooler button Unlock button Rear view Front view Cooler button Aura light Bottom view Kickstand USB Type-C port 3.5mm headphone jack Service Manual...
- Page 9 Side view Cooling fins Service Manual...
- Page 10 Major components AY2401 DEVICE LABEL A AY2401 DEVICE LABEL B NOTE: This part is NOT reusable NOTE: This part is NOT reusable after disassembly. after disassembly. AY2401-1A BASE ASSY ROG SEALED LABEL FOR PHONE NOTE: This part is NOT reusable after disassembly.
- Page 11 AY2401 KEY RUBBER AY2401 USB RUBBER AY2401 FAN FUNCTION_BD AY2201 FAN GASKET AY2401 MB GASKET Service Manual...
- Page 12 AY2401 COOLING CHIP AY2201 MB KAPTON AY2401 MB KAPTON Service Manual...
- Page 13 AY2401_USB_FPC R2.0 AY2401 SUB_BD (NO EMI FILM) AY2401-1A HEATSINK AY2401 COOLING FAN AY2301 PCB CONDUCTIVE RING NOTE: This part is NOT reusable after disassembly. Service Manual...
- Page 14 AY2401-1A FRAME ASSY AY2401 FAN_LED_KEY_FPC AY2401-1A COVER ASSY Service Manual...
- Page 15 SCREW M1.4*8L (2.7,0.5) (K) #0 SCREW M1.4*2.5L (2.8,0.4) (K) #0 Service Manual...
- Page 16 Disassembly Caution: ASUS hereby provides a basic instruction for the disassembly of ASUS products, i.e. to remove components and materials that require selective treatments, which are defined by Annex II of the European Union (EU) Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/ EC.
- Page 17 - components containing refractory ceramic fibers as described in Commission Directive 97/69/EC of 5 December 1997 adapting to technical progress Council Directive 67/548/EEC relating to the classification, packaging and labelling of dangerous substances, - components containing radioactive substances with the exception of components that are below the exemption thresholds set in Article 3 of and Annex I to Council Directive 96/29/Euratom of 13 May 1996 laying down basic safety standards for the protection of the health...
- Page 18 Use tweezers to remove the DEVICE LABEL A & DEVICE LABEL B. NOTE: If the device label is difficult to remove, apply some alcohol. Use tweezers to remove the USB rubber. Service Manual...
- Page 19 Loosen the four M1.4*8L screws (circled) and detach the base assembly starting from the points indicated by the arrows. Remove the USB_FPC and SUB_BD from the main board. Remove the two M1.4*2.5L screws and then remove the cover assembly. Service Manual...
- Page 20 Remove the AY2201 MB KAPTON tape and unplug the KEY FPC from the main board. Remove the AY2401 MB KAPTON tape, unplug the FAN Cable and detach the Cooling Chip Cable connector from the main board. Loosen the two M1.4*2.5L screws and remove the main board.
- Page 21 Remove the FAN_KEY_LED_FPC from the FRAME ASSY if needed. 10. Loosen the three M1.4*8L screws and remove the FAN from the HEATSINK if needed. 11. Use the Heating Platform to heat up the chip at 70°C for 2 minutes, then remove the cooling chip if needed. Service Manual...
- Page 22 Assembly Assemble the FAN onto the HEATSINK and secure with three M1.4*8L screws. Position the fan wire so that it rests inside the hook. Service Manual...
- Page 23 Assemble the FAN_KEY_LED_FPC onto the FRAME ASSY. NOTE: Align the circled points with the alignment columns on the chassis. Assemble the HEATSINK onto the FRAME ASSY and secure with two M1.4*2.5L screws. NOTE: Paste two new PCB CONDUCTIVE RINGS when replacing a new HEATSINK.
- Page 24 Connect the KEY FPC to the MB and secure the connector with AY2201 MB KAPTON tape. Connect the FAN Cable and the Cooling Chip Cable to the MB and secure each connector with AY2401 MB KAPTON tape. NOTE: Position the cable close to the cooling chip. Service Manual...
- Page 25 Connect the USB FPC to the SUB_BD and secure the connector with AY2401 MB KAPTON tape. Install the SUB_BD into the bottom of the cover, attach the FPC to the MB, and paste an AY2401 MB KAPTON tape to the FPC as shown in the picture. Service Manual...
- Page 26 Remove the old thermal grease from the cooling chip and the back of the BASE ASSY. Apply new thermal grease, TSP-RIC-D1060, in the amount shown in the picture below, and evenly spread it over the cooling chip. Thread the USB male connector through the hole at the bottom of the BASE ASSY, then snap the entire assembly onto the unit.
- Page 27 10. Assemble the USB RUBBER and then use a stick to press down on it to ensure it adheres properly. 11. Paste a new DEVICE LABEL A and a new DEVICE LABEL B. Service Manual...
