Summary of Contents for SAHLINS 1011
- Page 1 No. 9972-1011110 HYDRAULIC POWER PACK 1011 / 1013 USER MANUAL...
- Page 2 Contents THANK YOU FOR CHOOSING A SAHLINS PRODUCT! SAFETY RULES INTRODUCTION TECHNICAL DATA COMPONENT PARTS OPERATION STARTING AND STOPPING THE MOTOR MAINTENANCE SPARE PARTS 1011 SPARE PARTS 1013 EC DECLARATION OF CONFORMITY...
- Page 3 THANK YOU FOR CHOOSING A SAHLINS PRODUCT! We want you to be happy with your equipment. This instruction manual has been written to facilitate its safe handling and maintenance. Please read the manual thoroughly before using the equipment so that you are aware of the safety measures you need to take when using it.
- Page 4 SAFETY RULES General safety rules 1. Read and acquaint yourself with all of the warnings, precautionary measures and instructions in the user and care manual, and read and learn the importance of all the signs on and around the equipment. In case of any doubt, ensure that you have answers to all your questions before starting the work.
- Page 5 Equipment safety 18. Warning, prohibition and information signs may not be concealed, changed, damaged or removed. 19. Never climb on the equipment during operation, transport or lift, and do not allow any one else to do it. 20. Check the components in the equipment before each operation to ensure that no parts are damaged or are suspected to be damaged.
- Page 6 29. Do not perform any inner controls on the oil system before it has been made pressureless. Oil under pressure may be hazardous if the pressure is released incorrectly. Oil can get very hot under operation. Wait till the system has cooled down before the work can be performed. 30.
- Page 7 INTRODUCTION HYDRAULIC POWER PACK Hydraulic units 1011 and 1013 are intended to be used as a hydraulic power source together with a number of SAHLINS’ products The unit’s construction is robust and when used correctly, it is safe, cost-effective and reliable.
- Page 8 TECHNICAL DATA PROPERTIES 1011-1000 1013-1000 Engine output 6 hp 13 hp Fuel Unleaded petrol, 91 octane or Unleaded petrol, 91 octane or higher higher Tank volume Maximum hydraulic pressure 160 bar 210 bar Maximum oil flow 11 liter / min...
- Page 9 COMPONENT PARTS NAME NAME Hydraulic fluid tank Throttle Fuel tank Glass sight gauge - hydraulic tank Motor switch Starter handle Fuel tank cap Spark plug Muffler Oil dipstick/Oil drain tap Air filter Hydraulic outlet - pressure Stand Hydraulic outlet - return Choke control Air tap/Oil refill hydraulic fluid Fuel tap...
- Page 10 OPERATION Hydraulic unit operation SAHLINS hydraulic unit is reliable in design to provide safety. It can help you to perform your work easily and facilitate your work. However, it is important that you follow these instructions carefully as improper handling can be hazardous.
- Page 11 STARTING AND STOPPING THE MOTOR CAUTION Do not start up the unit until all hydraulic hoses have been connected Start Fuel tap - Refuel (see technical data) before each operation. - Move the fuel tap lever to the ON position. - Move the choke control to the closed position.
- Page 12 MAINTENANCE Service schedule Interval Each time Once a month or Every third Every sixth Every year or 20 hours month or 50 month or 150 300 hours hours hours ☒ Inspect ☐ - ☐ - ☐ - ☐ - Engine switch Muffler ☒...
- Page 13 Cleaning Two filter elements 1. Unscrew the wing nut from the air cleaner cover and remove the cover. 2. Unscrew the wing nut from the air filter and remove the filter. 3. Remove the foam filter from the paper filter. 4.
- Page 14 SPARE PARTS 1011...
- Page 15 Ref. No. Qty. Part No. Part name 1010-5001 TANK 1010-5002 1010-5003 COUPLER 1010-5004 STAND 1010-4010 SHAFT COUPLING W. FAN BLADE 9610-005-04 RUBBER STAR 9610-005-02 COUPLING HEAD PUMP 1010-5008 SPACER 9601-0502 MOTOR VANGUARD 6 HP 9601-91539 WEDGE 9649-021 FLANGE JOINT 9642-00302 HYDRAULIC PUMP PLP 3,15 9634-371 FEMALE QUICK COUPLING...
- Page 16 SPARE PARTS 1013...
- Page 17 Ref. No. Qty. Part No. Part name 9601-0134 MOTOR HONDA 13 HP 9642-00601 HYDRAULIC PUMP 2103-4020 SHAFT COUPLING W. FAN BLADE 1012-506 MEDIUM SPACER - PUMP 1013-5001 MEDIUM SPACER - MOTOR 1010-5003 COUPLER 1010-5001 TANK 1010-5013 HYDRAULIC FILTER MOUNT 1010-5011 FILTER CAP 1012-5007 1013-5006...
- Page 20 Sahlins Sweden AB Företagsvägen 2 512 64 Holsljunga, Sweden +46(0)320 209 330 | sales@sahlins.com 01/09/2020...
