Kyocera PD-130VR Owner's Operating Manual

DRILLING IN METAL
Metals such as steel brass, aluminum sheets, stainless
steel, and pipe may also be drilled. Mark the point to be
drilled with a nail or a punch.
DRILLING IN CONCRETE
Rock and masonry are generally drilled in the impact
mode.
When drilling delicate materials such as wall tiles, it is es-
sential to start with ordinary drilling and once the tile is
pierced, to continue with impact drilling.
In deep boreholes the drill bit should be pulled out oc-
casionally in order to remove the dust and chips from the
hole.
AUX. HANDLE AND ADJUSTMENT STOPPER
Install the aux. handle (7) on the head of the housing and
insert the adjustment stopper (6) in the hole provided.
The aux. handle can swivel 360° for the most comfortable
position and easiest operation.
The stopper helps keep an accurate depth when drilling
holes.
MAINTENANCE
After use, check the tool to make sure that it is in top
condition. It is recommended that you take this tool to an
Authorised Service Centre for a thorough cleaning and
lubrication at least once a year.
DO NOT MAKE ANY ADJUSTMENTS WHILE THE MOTOR
IS IN MOTION.
ALWAYS DISCONNECT THE POWER CORD FROM THE
RECEPTACLE BEFORE CHANGING REMOVABLE OR
EXPENDABLE PARTS (BLADE, BIT, SANDING PAPER
ETC.), LUBRICATING OR WORKING ON THE UNIT.
WARNING!
To ensure safety and reliability, all repairs should be
performed by an AUTHORISED SERVICE CENTRE or
other QUALIFIED SERVICE ORGANISATION.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
WARNING To reduce the risk of injury, user must read
"
instruction manual "
" Class II construction tool in which protection against
electric shock does not rely on basic insulation only, but
in which additional safety precaution, such as double
insulation or reinforced insulation, are provided."
- 3 -
PD-130VR
69800975-00 STD
06-22
