- Page 1 QCWS WIND SENSOR FOR XQ50 AC SERIES MOTORS QCWSX RADIO WIND SENSOR FOR XQ50 AC SERIES MOTORS QCWSSX RADIO SUN/WIND SENSOR FOR XQ50 AC SERIES MOTORS Made in Italy...
- Page 2 QCWS TECHNICAL DETAILS DESCRIPTION INSTALLATION CONNECTIONS WIND SENSOR SETTING...
-
Page 3: Technical Details
Temp. di funzionamento -5°C /+40°C Dimensioni 270 x 120 x 90 mm DESCRIPTION The QCWS wind sensor is designed for residential use. Connected to XQ50 tubular motors, wind speed is continuously monitored, triggering the control to retract the awning automatically as needed. -
Page 4: Installation
INSTALLATION The QCWS wind sensor is supplied in 2 parts: 1) the main body and 2) the 3 cups fan, to be inserted, by hand pressure only, in its shaft on the main body. The QCWS wind sensor must be installed with the fan downwards and it should be placed close to the awning to make sure the wind speed is measured at the product. - Page 5 CONNECTIONS Only with motors with integrated receiver with a 4-wire power cable*. When connecting to a control unit follow the instructions on the same Remove the top cover of the sensor (4 screws) and connect the two- wire cables from the sensor terminals to the motor wires (no polarity is required).
- Page 6 (in case of installations combined with a QCX09 unit or a XQ50-motor with electronic-radio limit switch). According to the GAPOSA transmitter used, select the channel / group on which you want to change the sensitivity level of the wind sensor, then: 1...5...
- Page 7 WIND SENSOR SETTING It is possible to chose among 5 levels of sensitivity (for the correspondence between the level chosen and the wind speed, follow the table below); WIND - LEVEL OF SENSITIVITY Livel 1 10 Km/h - Low wind speed Livel 2 20 Km/h - Low/medium wind speed Livel 3...
- Page 8 QCWSX / QCWSSX TECHNICAL DETAILS DESCRIPTION FUNCTIONS INSTALLATION CONNECTIONS CONNECTION SENSOR/MOTOR WIND SENSOR SETTING SUN SENSOR SETTING (only QCWSSX)
- Page 9 TECHNICAL DETAILS Power supply 230Vac 50 Hz Frequency 868,30 MHz Radiated power <10 mW Coverage (int/ext) 20 m / 200 m Wind sensor (5 levels) 10 / 20 / 30 / 40 / 50 Km/h Sun sensor (4 levels) 5 / 20 / 40 / 60 Klux (QCWSSX) Protection rate IP54 Working temperature...
- Page 10 FUNCTIONS Wind protection function Retracts and prevents the awning to open for 20 minutes if the wind threshold is exceeded. Sun protection function [QCWSSX] This function allows the awning to open after 2 minutes if the sun threshold value is exceeded. Note: The awning opens completely up to the down limit unless an intermediate position is previously set (Just for motors with electronic encoded tubular motors with built-in radio receiver).
- Page 11 FUNCTIONS Awning feedback • W ind alarm - Manual extension is stopped after 2 seconds and the awning retracts • S ensor loss (Motor safety mode*) - Manual extension works in “press and hold” way only. In this status of safety mode the awning anyway retracts automatically every 30 minutes.
- Page 12 INSTALLATION Before installing and using the radio sensor please read the instructions carefully. This device has to be installed by a professional installer. Before the installation check the compatibility of the device with the associated motors and controls. The installer must comply with the standards and legislationin the country in which the device is being installed Note: ensure that sensors are not installed close to metal...
- Page 13 CONNECTION 1. Open the top cover by the 4 screws on the bottom. 2. Connect the power line as described below. Check that the power supply corresponds to the label data. 3. Close the top cover and tight the screw to seal it. 230 V~ / 50 Hz Power supply Additional Accessories required:...
-
Page 14: Checking Connection
CONNECTION SENSOR/MOTOR IMPORTANT: First program a transmitter with the motor then set the limits of the motor and finally set the transmitter with the sensor. Programming procedure of sensor is like adding a new transmitter to the motor so: <3” Press and hold PROG-TX button Press and hold for at least 3 seconds S button on the wind... - Page 15 SETTING WIND THRESHOLD (5 levels to be selected ONLY through the transmitter) Important: The wind threshold setting is individual for each engine/channel. Before starting the procedure, select the motor/ channel on which you want to set it. 1...5 1...5 1...5 (level) (level) (level)
- Page 16 SETTING WIND THRESHOLD The wind speed level that the sensor detects is displayed by the number (from 1 to 5) of LEDs ON: WIND THRESHOLD (wind speed) LOW/ MEDIUM/ MEDIUM HIGH MEDIUM HIGH 10 Km/h 20 Km/h 30 Km/h 40 Km/h 50 Km/h LED 1 LED 2...
- Page 17 Liv 2 Liv 3 Liv 4 disabled 5 Klux 20 Klux 40 Klux 60 Klux high lightness lightness LED 6 LED 7 LED 8 LED 9 GAPOSA srl - via Ete, 90 63900 Fermo - Italy T. +39.0734.220701 - info@gaposa.com...
