Summary of Contents for MK ILLUMINATION ARTIFICIAL TREE 750
- Page 1 ARTIFICIAL TREE 750 IP67 ARTIFICIAL TREE 750, 680-639 © 2021, MK ILLUMINATION 36 V...
- Page 2 ARTIFICIAL TREE 750, 680-639 Read this instruction manual before use! Recommended temperature range -20°C to +40°C Article Code Dimension LEDs Weight Mains Voltage Watt Artificial Tree 750 680-639 6000x7500x6000mm 12120 410 kg 230V~AC 50Hz 456 W Warnings & Precautions Warnings - Before you start 25 Pay close attention to this manual and stay with it’s warnings and...
- Page 3 Code QuickFix QuickFix ® ® 002-xxx, 029-xxx 015-xxx, 028-xxx 002-xxx, 029-xxx 015-xxx, 028-xxx Adapter Set: Adapter Set: 002-799 002-799 You find more detailed product Information in our product catalogue or on www.mk-illumination.com ARTIFICIAL TREE 750, 680-639 © 2021, MK ILLUMINATION...
- Page 4 ARTIFICIAL TREE 750, 680-639 Lesen Sie vor Inbetriebnahme des Produktes diese Bedienungsanleitung! Empfohlener Temperaturbereich -20°C bis +40°C Artikel Code Dimension LEDs Gewicht Versorgungsspannung Watt Artificial Tree 750 680-639 6000x7500x6000mm 12120 410 kg 230V~AC 50Hz 456 W Warnings & Precautions Warnings - Before you start 25 Befolgen Sie alle Anweisungen dieser Bedienungsanleitung Das Produkt ist für den Einsatz im Aussen- und Innenbereich...
- Page 5 Art. Nr. Art. Nr. QuickFix QuickFix ® ® 015-xxx, 028-xxx 015-xxx, 028-xxx 002-xxx, 029-xxx 002-xxx, 029-xxx Adapter Set: Adapter Set: 002-799 002-799 Weitere Produktinformationen finden Sie in unserem Produktkatalog oder auf www.mk-illumination.com ARTIFICIAL TREE 750, 680-639 © 2021, MK ILLUMINATION...
- Page 6 ARTIFICIAL TREE 750, 680-639 ASSEMBLY/DISASSEMBLY INFO ASSEMBLY/DISASSEMBLY INFO WORKERS ASSEMBLY TIME (not supplied) ACCESSORIES (not supplied) - Ladder - Scissor lift TOOLS (not supplied) - Fork key 13 (M8) ACCESSORIES IN PACKAGE ACCESSORIES IN PACKAGE 4 pcs M8x90 4 pcs...
- Page 7 2. Fix “BASE OF TREE” to the ground, via hooks prepared on the “ROOTS”, Detail 2. - For fixing use ground/floor anchors M12 (System 2). Illustration foto Illustration foto SCREW NUT GROUND/FLOOR ANCHOR WASHER System 2 System 2 Detail 2 ARTIFICIAL TREE 750, 680-639 © 2021, MK ILLUMINATION...
- Page 8 ARTIFICIAL TREE 750, 680-639 3. Gradually attach branches and twigs together, Picture 1. We recommend to start from top branches+twigs and then add bottom branches+twigs, Scheme 2. - Assembly same marked parts, Detail 3. BRANCH 1 BRANCH 1 Detail 3...
- Page 9 Scheme 3 Detail 5 STEEL WIRES: STEEL WIRES: WIRE 1 - 1200mm WIRE 1 - 1200mm WIRE 2 - 1000mm WIRE 2 - 1000mm WIRE 3 - 1200mm WIRE 3 - 1200mm ARTIFICIAL TREE 750, 680-639 © 2021, MK ILLUMINATION...
- Page 10 ARTIFICIAL TREE 750, 680-639 5. There are welded hooks on the “BASE OF TREE” for fixation by steel wires, Detail 6, Scheme 4. - Steel wires must be at least 3mm strong and in maximum angle 60 from the point of fixing to the point on the Artifical tree.
- Page 11 ARTIFICIAL TREE 750, 680-639 © 2021, MK ILLUMINATION...
