OPERATOR'S
60V Lithium-Ion Backpack Battery
CHARGE BEFORE FIRST USE
WARNING: To reduce the risk of injury, the user must
read and understand the Operator's Manual before using this
product. Save these instructions for future reference.
MANUAL
Model number:
BP7615
BP7625
Advertisement
Summary of Contents for SUNSEEKER BP7615
- Page 1 OPERATOR’S MANUAL 60V Lithium-Ion Backpack Battery Model number: BP7615 BP7625 CHARGE BEFORE FIRST USE WARNING: To reduce the risk of injury, the user must read and understand the Operator’s Manual before using this product. Save these instructions for future reference.
- Page 2 READ ALL INSTRUCTIONS! READ & UNDERSTAND OPERATOR’S MANUAL This battery pack has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate. SAFETY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers.
- Page 3 WARNING: Risk of fire and burns. Do not recharge, disassemble, heat above 212 °F (100 °C), or incinerate. Keep battery out of reach of children and in original package until ready to use. Dispose of used batteries promptly according to local recycling or waste regulations. SAFETY INSTRUCTIONS This page depicts and describes safety symbols that may appear on this product.
- Page 4 Any damaged or disposed electric or electronic devices must be delivered to appropriate collection centers. Do not dispose electric tools, batteries/re-chargeable batteries together with household waste material. Electric tools and Recycle batteries that have reached the end of their life must be Symbols collected separately and returned to an environmentally compatible recycling facility.
- Page 5 Weight Kilogram Weight Pound Fahrenheit Temperature °F temperature Celsius Temperature °C temperature WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury. The term “power tool” in all of warnings listed below refers to corded power tools or battery operated (cordless) power tools.
- Page 6 packs may create a risk of injury and fire. Sunseeker batteries are designed specially for Sunseeker power tools. Use the batteries on any other tools may not only damage the batteries and tool but also create a risk of injury and fire.
- Page 7 coins, keys, nails screws or other small metal objects that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If ...
- Page 8 Save these instructions. Refer to them frequently and use them to instruct others who may use this tool. If you lend someone this tool, lend them these instructions also to prevent misuse of the product and possible injury. SAVE THESE INSTRUCTIONS! SPECIFICATIONS BATTERY BP7615 BP7625 Rated Voltage Max Capacity 900Wh 1500Wh...
- Page 9 Matched Charger CG768U CG768U Rapid Charging: 8A Rapid Charging: 8A Charging Current Normal Charging: 4A Normal Charging: 4A Rapid Charging: Rapid Charging: Approximately: 3.0H Approximately:1.8H Charging Time Standard Charging: Standard Charging: Approximately: 6.5H Approximately: 3.9H Operating Temperature -20°C ~ +45°C -20°C ~ +45°C Weight (Without...
- Page 10 Shoulder strap Handle Harness frame Harness release button Belt strap Harness Support Fig.1 OPERATION LED INDICATOR ON BACKPACK BATTERY This lithium-ion backpack battery is equipped with 5-LED battery power level indicator and an abnormal LED indicator to show the battery power level and the error. When in use, press the power indicator button on the battery to display the battery power level or the battery status.
- Page 11 5-LED Indicator Illustration Charge/Battery status LED#5 LED#4 LED#3 LED#2 LED#1 0%-5% Solid green 5%-15% Solid green 15%-35% Solid green 35%-70% Solid green 70%-100% Solid green ＜5% Flash green Error-abnormal Flash green temperature Note: The abnormal LED indicator please refer to trouble-shooting. BATTERY PROTECTION The battery circuitry protects the battery pack from extreme temperature, over- discharge, and over-charge.
- Page 12 WARNING: No heating activity for the battery is allowed under any circumstances. COLD WEATHER OPERATION This Lithium-Ion battery pack will provide optimal performance in temperatures between 50°F (10°C) and 80°F (26°C). When the battery pack is very cold, it may “pulse” for the first minute of use to warm itself.
- Page 13 is mounted into place. Fig.2 To Detach (Fig. 3 & 4) Push the harness release button on the top of battery, until you hear a clear “click” sound, the battery will be detached from the harness. Fig.3 Fig.4 HOW TO ADJUST THE BACKPACK BATTERY HARNESS Put your arms through the harness shoulder straps to support the backpack battery on your back and temporarily adjust both shoulder straps to comfortable positions, making sure that your shoulders are comfortable (Fig.
- Page 14 Snap the waist buckle on the belt strap and adjust its length so that the backpack battery is securely supported by your hips (Fig. 6 & 7). Snap the chest buckle and adjust its length if necessary (Fig. 8). Readjust the shoulder straps for security and comfort. Making sure that the backpack battery sits securely on your back with the weight supported by the waist strap, and without excess movement when you move (Fig.
- Page 15 WARNING: When servicing, use only identical Sunseeker replacement parts. Use of any other parts may create a hazard or cause product damage. To ensure safety and reliability, all repairs should be performed by authorized dealer/distributor.
- Page 16 WARNING: To reduce the risk of fire, personal injury, and product damage due to a short circuit, never immerse your tool, battery pack or charger in fluid or allow a fluid to flow inside them. Corrosive or conductive fluids, such as seawater, certain industrial chemicals, and bleach or bleach containing products, etc., Can cause a short circuit.
- Page 17 If your device should become useless somewhere in the future or you do not need it any longer, do not dispose of the device together with your domestic refuse, but dispose of it in an environmentally friendly manner. Please dispose of the device itself at an according collecting/recycling point. By doing plastic and metal parts can be separated and recycled.
- Page 18 WARNING: Upon removal of the battery pack for disposal or recycling, cover the battery pack’s terminals with heavy-duty adhesive tape. Do not attempt to destroy or disassemble the battery pack or remove any of its components. Lithium-Ion batteries must be recycled or disposed of properly. Also, never touch the terminals with metal objects and/or body parts as a short circuit may result.
- Page 19 Reinsert the charger plug into the The connection between the charger power supply. and power supply goes wrong. Allow the battery pack to reach normal temperature and charging will 5-LED The battery is too hot. begin when battery pack itself returns indicators to 3°C -57°C.
- Page 20 1 long flash & Discharge Discharge over-current phenomenon 4 short flash over current exists at the power supply side, reducing the power of the load and requiring re-plugging. 2 long flash & COM Error Check the COM line for poor contact . 1 short flash Replace the power device or charger has been the fault then replace the...
