- Page 1 User Manual Upright Freezer MODEL: CCUL50W6, CCUL50B6 CCUL50WV6, CCUL50BV6 CCUL60W6, CCUL60B6 CCUL60WV6, CCUL60BV6...
- Page 2 Page 2...
- Page 3 CONTENTS SAFETY INFORMATION Important Safety Instructions Refrigerant Grounding Instructions SET UP & USE Installation Guide 7-11 Parts & Features 12-13 Operation Instructions CLEANING & CARE 15-16 TROUBLE SHOOTING & WARRANTY Before You Call For Service Customer Service Troubleshooting Limited Warranty PRODUCT REGISTRATION Thank you for purchasing our W Appliance product.
- Page 4 SAFETY INFORMATION DANGER WARNING CAUTION DANGER - Immediate hazards WARNING - Hazards or unsafe CAUTION - Hazards or unsafe which WILL result in severe practices which COULD result in practices which COULD result in personal injury or death severe personal injury or death minor personal injury IMPORTANT SAFETY INSTRUCTIONS WARNING...
- Page 5 SAFETY INFORMATION 9. Do not refreeze foods that have been thawed completely. The United States Department of Agriculture in Home and Garden Bulletin No. 69 reads: “…You may safely refreeze frozen foods that have thawed if they still contain ice crystals or if they are still cold- below 40˚F.
- Page 6 SAFETY INFORMATION GROUNDING INSTRUCTIONS ELECTRICAL REQUIREMENTS The electrical requirements are a 115 volt 60 Hz, AC only, 15 amp. It is recommended that a separate circuit serving only the product be provided. The product is equipped with a 3-wire cord having a 3-prong grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded.
- Page 7 SET UP & USE INSTALLATION GUIDE 1. Unpack your freezer by removing all packaging materials like carton, base, foams, adhesive tape, etc. 2. Remove all accessories, internal packaging material used to hold shelves, ice tray, etc. in place. 3. Clean the remains of all adhesive tap used and remove all printed material supplied.
- Page 8 SET UP & USE PROTECTION FROM HEAT AND MOISTURE • Do not install your freezer in any location where heavy moisture is present or if the location is not properly insulated. This freezer is not designed to operate in temperature setting below 55° Fahrenheit. •...
- Page 9 SET UP & USE 1. Remove any loose items in the freezer and carefully place it on its back. 2. Using a Philips head screwdriver remove the 4 screws and bottom door hinge. Set them aside. 3. Remove the top hinge cover. 4.
- Page 10 SET UP & USE 3. Lift the top and remove the 2 screws and the hinge from the right side. 4. Gently lift the door away from the hinge pin and remove the door. Re-insert the 2 screws and hinge on the opposite side. 5.
- Page 11 SET UP & USE 8. Align the door to the cabinet and secure it with the bottom hinge pin and bracket by inserting the 4 screws into the holes. Tighten the screws. Make sure the leg is tightened in the front hole of the bracket. 9.
- Page 12 SET UP & USE PARTS & FEATURES CCUL5W, CCUL5B,CCUL5WV, CCUL5BV Temperature Control Freezer Door (4) Shelves Leveling Legs Page 12...
- Page 13 SET UP & USE PARTS & FEATURES CCUL65W, CCUL65B,CCUL65WV, CCUL65BV Temperature Control Freezer Door (5) Shelves Leveling Legs Page 13...
- Page 14 SET UP & USE OPERATION INSTRUCTIONS TEMPERATURE CONTROL NOTE: · If the freezer has been placed in a horizontal or tilted position for any period of time wait 24 hours before plugging the unit in. • The settings of the temperature control are OFF, 1 (warmest), 2, 3 (coldest). Adjust the temperature control to the setting that best suits your needs.
- Page 15 CLEANING & CARE CLEANING AND MAINTAINING The freezer should be cleaned and maintained once a month. Before doing so, you must unplug the freezer. POWER INTERRUPTION In case of a power interruption/outage, unplug the power cord from the wall outlet. Replug the power cord to the wall outlet once the power has been restored.
- Page 16 CLEANING & CARE DOOR GASKET Clean door gaskets every three months according to general instructions. Gasket must be kept clean and pliable to assure a proper seal. • Petroleum jelly applied lightly on the hinge sides of gaskets will keep the gasket pliable and ensure a good seal.
- Page 17 TROUBLESHOOTING & WARRANTY TROUBLESHOOTING & WARRANTY BEFORE YOU CALL FOR SERVICE IF THE FREEZER FAILS TO OPERATE: A) Check to make sure that the freezer is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds and plug it in again securely. B) Check for a blown circuit fuse or a tripped main circuit breaker.
- Page 18 TROUBLESHOOTING & WARRANTY TROUBLESHOOTING Troubleshoot your problem by using the chart below. If the freezer still does not work properly, contact W Appliance Co. customer service center or the nearest authorized service center. Customers must never troubleshoot internal components. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Freezer does not...
- Page 19 TROUBLESHOOTING & WARRANTY LIMITED WARRANTY Any repair, replacement, or warranty service, REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY and all questions about this product should OF THE CUSTOMER; W Appliance Co. SHALL 1 (855) be directed to W Appliance Co. at NOT BE LIABLE FOR ANY INCIDENTAL OR 855-0294 from the USA or Puerto Rico.
- Page 20 © 2020 W Appliance Company LLC. All Rights Reserved. May 2020...
