- Page 1 COMPETITION SERIES Mono Hochleistungs-Verstärker / Mono High-Power Amplifier GZCA 3000.M1-24V Owner´s manual Anleitung / AWV4.0...
- Page 2 GROUND ZERO GZCA 3000.M1-24V COMPETITION SERIES...
- Page 3 GROUND ZERO GZCA 3000.M1-24V Ausstattungsmerkmale / Features • Mono Hochleistungs-Verstärker • 24 V Betriebsspannung • Hocheffiziente Class D Technologie • 1 Ohm stabil • Regelbarer Tiefpass-Filter • Regelbarer Hochpass-Filter • Regelbarer Bassboost • Einstellbare Eingangsempfindlichkeit • Einschaltverzögerung • Thermische-Schutzschaltung •...
- Page 4 Daher wird empfohlen, für die Zusammenstellung der Anlage sowie deren Einbau und Abstimmung den Fachhandel oder eine spezialisierte Fachwerkstatt aufzusuchen. Thank you for choosing a great GROUND ZERO product! We hope you will enjoy this product from the COMPETITION series. This owner´s manual contains information you need to use this product.
- Page 5 Therefore, it requires professional high SPL levels to be achieved. In consequence, particular and powerful loudspeakers and power amplifiers need to be used. GROUND ZERO´s development department doesn´t make any compromise whenever the purpose of a product is defined that clear. As a result, each COMPETITION series member will be the right choice for demanding applications expecting very high SPL level audio reproduction with high sound quality.
- Page 6 GROUND ZERO GZCA 3000.M1-24V Technische Daten / Specifications model Modell / GZCA 3000.M1-24V Amplifier type Verstärkerart / Mono Class D Output power (RMS) Ausgangsleistung (RMS) / 1000 W (1% THD+N) @ 4 Ω CEA-2006-A Output power (RMS) Ausgangsleistung (RMS) / 1825 W (1% THD+N) @ 2 Ω...
- Page 7 GROUND ZERO GZCA 3000.M1-24V Einstellungen und Funktionen Zum Anschluss der Lautsprecherkabel Lautsprecheranschluss (Impedanz ≥ 1 Ohm) +24V Dauerstrom-Anschluss (+) (z.B. direkt an den Pluspol der Batterie) Remote-Anschluss des Steuergerätes Stromanschluss Masse-Anschluss an der Karosserie (-) (z.B. direkt an den Minuspol der Batterie) Gerät in Betrieb...
- Page 8 GROUND ZERO GZCA 3000.M1-24V Controls & Features To connect the speaker wires Speaker terminal (Impedance ≥ 1 ohm) +24V To be connected to the positive terminal of the battery To be connected to the remote output of the Power terminal head unit To be connected to the vehicle´s ground...
- Page 9 GROUND ZERO GZCA 3000.M1-24V Fehlerdiagnose Problem Kontrolle Hilfe Sicherungen prüfen Remote Kabel prüfen Leuchtet keine LED? +24 Volt prüfen Masse prüfen Kein Ton Kurzschluss am Lautsprecher Leuchtet die PRT LED? Gerät überhitzt Gerät defekt Sicherung prüfen Verstärker Keine Stromzufuhr +24 Volt prüfen schaltet Masse prüfen...
- Page 10 130 dB or more. Extreme levels can also hinder the perception of important traffic noises and distract from what is happening on the road. Ground Zero GmbH and its sales partners expressly assume no responsibility for hearing damage, physical damage or any damage to property or consequential damage resulting from improper or careless use or improper installation of its products.
- Page 11 Some music styles require higher levels while others prefer the soft tones. GROUND ZERO considers all the different wishes of customers during the development of new products. Along with this, the target is to create the most realistic sound, to transfer the soul of the music and the intention of the performer.
- Page 12 GROUND ZERO GZCA 3000.M1-24V GROUND ZERO Produkte werden in Deutschland entwickelt GROUND ZERO products are engineered in Germany GROUND ZERO – Internationaler Sponsor der GROUND ZERO - international sponsor of Ground Zero GmbH Erlenweg 25 - 85658 Egmating - Germany Tel.
