BodyCraft XFT-BRACKET Owner's Manual

Adjustable Mount for TV or Connect-22 OPTION,
Base Lot Number: _ _ _ _ _ _ _ _ _ _ _ _ _
Purchased Date: ___ / ___ / ______
Dealer's Name:__________________________
Please register your products at:
https://www.bodycraft.com/product-registration/
Detailed Parts List & Images
Part #
XFT-V2-Bracket-001-ASM
XFT-V2-Bracket-002
XFT-V2-Bracket-003
XFT-V2-Bracket-004
XFT-V2-Bracket-005
XFT-V2-Bracket-006
Installation of the XFT-BRACKET OPTION to a XFT-V2.
XFT-BRACKET
for the BODYCRAFT XFT-V2
Owner's Manual
Bracket for Console, Adjustable Telescopic ,VESA Mount for TV or Connect-22 - Assembly
Screw, Flat Phillips Head, Countersunk, M6 x 16mm L - BLK
Screw, Pan Phillips Head, M4 x 10mm L - SILVER
Cable Clip Mounts
Wrench, Hex, 5mm
Label - Lot Code
To see in
FULL COLOR
& additional
information,
scan this QR code.
Detailed Parts List
XFT-V2
1
Open your Camera
App and point it at
the QR Code
QTY
1
2
4
10
1
1
XFT-BRACKET_v1.2
