Magna MCC1 Assembly Instructions

IMPORTANT SAFETY INSTRUCTIONS
1. READ,UNDERSTAND AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
2. Do not exceed the overall maximum load capacity of 1200lbs(544kg), or the maximum dumping load capacity of
500lbs(226kg), the weight rating is based on an evenly-distributed load.
3. Do not allow children to use cart without supervision.
4. Do not use this cart to transport passengers.
5. This cart is not intended for highway use or to be used at high speed.
6. Distribute the load evenly over the surface of the tray.
7. Do not load items on the top edges of the tray.
8. If any parts become damaged, broken or misplaced, do not use the cart until replacement parts have been obtained.
9. Do not use the cart on surfaces that will bring damages to the pneumatic tires.
10. Do not inflate the tires TO MORE THAN 30 psi(2.07BAR).
11. It is recommended to inspect the cart for each usage.
12. KEEP THIS INSTRUCTION FOR FURTHER REFERENCES.
12
13
13
7
2
7
3
6
5
10
14
9
11
1
8
7
13
4
7
13
ASSEMBLY INSTRUCTIONS
MCC1 GARDEN CART
Tray
Dump Lock frame
1x
1x
2
1
Traction Handle
1x 1x
6
5
Bolts
Bolts Bolts
M8x20
M10x60 M10x50
7x
1x 2x
11
9 10
Front bracket
Rear bracket
1x
1x
4
3
Wheels
Axle
4x
1x
7 8
Bolts
Washer Lock nut
M8x20
and pin
4x
4x
12
13
M18
1x
14
