400XAC
Quick Start Guide
3 Phase AC Power Source
MODELS 430XAC, 460XAC
POWER CHECKLIST
Power down output while connections are made.
Output & input cabling have unique AWG carrying capacity.
(Be sure to use the appropriate gauge for your application)
Work in a safe and orderly manner, your test station should always be neat.
Educate unqualified personnel of test area dangers.
Refrain from touching test connections and product while testing.
WARNING: An AC Power Source produces voltages and currents that can cause harmful or fatal electrical shock. This
guide was created for operators who have some familiarity with high voltage/current testing applications. To prevent
accidental injury or death, strictly follow all warnings within this guide.
