- Page 1 SimPal-T200 4G Temperature Monitor User Manual V2.2-2024...
- Page 2 SIMPAL-T200 4G Temperature Monitor Thank you for purchasing the SimPal-T200. SimPal-T200 4G Temperature Monitor is a remote temperature alarm device consisting of a 4G module and a built-in temperature sensor. It needs to work with 4G SIM card. All settings are done by send SMS to this device SIM card number.
- Page 3 SimPal-T200 4G Temperature Monitor USER MANUAL For your safety ..............5 Exception clause ............. 6 Chapter 1 Device instruction..........7 1.1 Device instructions ..........7 1.2 Light indicator ............8 1.3 Package contents ............9 Chapter 2 Operation guide ..........9 2.1 Installation ..............
- Page 4 SimPal-T200 4G Temperature Monitor USER MANUAL 2.8 Power failure alarm ..........14 2.9 Allow anyone check temperature ......14 2.10 Weak 4G signal alarm ........... 14 2.11 Reset factory settings..........15 Chapter 3 General Troubleshooting ......17 Chapter 4 Main Technical Parameters......19...
- Page 5 Do not keep shaking or fall down this device, otherwise it can be damaged. • SimPal-T200 is a wireless signal transmission device. Keep it away from electronic equipment likely to interfere with the wireless signals, in order to avoid signals interference.
- Page 6 SimPal-T200 4G Temperature Monitor USER MANUAL • Forbid to remove the power plug parts separately. Exception clause 1. We operate on a policy of continuous development. We reserve the right to make changes and improvements to any of the device described in this document without prior notice.
- Page 7 SimPal-T200 4G Temperature Monitor USER MANUAL Chapter 1 Device instruction 1.1 Device instructions 1 USB data port (Only for repair use) Power indicator 2 Reset button GSM indicator 3 Cable temp sensor connector 6 SIM card slot 7 Built-in temp sensor...
- Page 8 SimPal-T200 4G Temperature Monitor USER MANUAL 1.2 Light indicator Indicator Status Device function No power supply input Power Indicator Constant 230V AC power connected light Flash slowly Searching 4G network. Sending SMS Can not recognize SIM GSM Indicator...
- Page 9 2.2 Power on Power on: Plug the SimPal-T200 into wall socket for AC power supply, the device will start working. The power LED will constant light, the GSM LED will light one second and then off 3-4 seconds. After recognizing the SIM card, the GSM LED will flash slowly indicated that it is searching 4G network.
- Page 10 SIM card working abnormally, all functions of this device are invalid. 2.3 Download APP It can download APP to control the SimPal-T200 device, all settings can be done via APP. The APP is available on Google Play and Apple Store. Seach “SimPal GSM” to download the APP.
- Page 11 SimPal-T200 4G Temperature Monitor USER MANUAL • Successful SMS reply Welcome! Master’s number has been registered. After register Master number to the device, The Master allow to transfer the master number to a new number. The Master user sends following...
- Page 12 SimPal-T200 4G Temperature Monitor USER MANUAL Master or User sends following SMS message to: Check built-in sensor’s temperature: #01# Check cable sensor’s temperature: #16# (10) 2.6 Temperature alarm A range of temperature can be pre-set onto the device. If the surroundings temperature is detected crossing the temperature range, the device will send SMS alarm message to users’...
- Page 13 SimPal-T200 4G Temperature Monitor USER MANUAL can be set within the range of -50 to 100 centigrade degree. 2.6.3 Auto report temperature It can set device auto report temperature according weekly schedule, this can make sure device is online and know the temperature value is in normal range.
- Page 14 SimPal-T200 4G Temperature Monitor USER MANUAL • Delta value: the range is 3 to 20. • Time: The time range is 1 to 10 minutes. • Default delta is 5 degree and Time is 3 minute. #13#1# Rapid temperature change alarm - ON:...
- Page 15 SimPal-T200 4G Temperature Monitor USER MANUAL SMS when weak 4G signal - ON: #15#1# (27) SMS when weak 4G signal – OFF (default): #15#0# (28) 2.11 Reset factory settings • This function resets all programmed settings to their original values, including cleaning all user number and temperature parameter.
- Page 16 SimPal-T200 4G Temperature Monitor USER MANUAL...
- Page 17 SimPal-T200 4G Temperature Monitor USER MANUAL Chapter 3 General Troubleshooting General Possible Reason Solution Trouble Power Check external AC indicator light No power input. power is available. turns off SIM card no install Can’t find or indicator light properly: Plug out and...
- Page 18 SimPal-T200 4G Temperature Monitor USER MANUAL Note: If the problem can’t be solved with above guidelines, contact to your local distributor or after service center. I händelse av upprepade power restore notifikationer. Om signalstyrkan i ditt mobilnät är för låg skickas detta meddelande som SMS. Genom kommandot #15# Skall gränsvärdet vara en range från 0-31 där normal...
- Page 19 SimPal-T200 4G Temperature Monitor USER MANUAL Chapter 4 Main Technical Parameters 110~250V AC/ 12V DC Power input of device CEE 7/7 hybrid Schuko/French plug Operating temperature -10℃~+50℃ Store temperature -20℃~+60℃ Relative humidity 10-90%，without condensation Communication GSM PHASE 2/2+ protocols (including data operation) Data interface GSM SIM 1.8V/3.0V device...
- Page 20 SimPal-T200 4G Temperature Monitor USER MANUAL Appendix: SMS commands list Category Function Command Register Master number (1) #00# Change Master number (2) #10#New-Master# Add a user number (3) #08#User-Number# Check User number list (4) #08# Define the Delete a User number...
- Page 21 SimPal-T200 4G Temperature Monitor USER MANUAL Category Function Command Auto report temperature - (19) #21#0# OFF (default) Set rapid temp change (20) #14#Delta#Time# alarm value Rapid Rapid temp change alarm temperature (21) #13#1# - ON change Rapid temp change alarm...
- Page 22 SimPal-T200 4G Temperature Monitor USER MANUAL 4G Temperature Monitor...
