- Page 1 FIOS-640T IP66 6.5Inch 8Ohm 70V/100V IP66 Indoor / Outdoor 2-Way Speaker Pair With Bass Enhancement Radiator (BER) User Manual...
- Page 2 3. Speaker Location Because of their well-behaved off-axis response and excellent dispersion, your new Focus Audio speakers are less critical to position than most loudspeakers. For the best possible listening experience, place the speakers in the desired location about 1.5 - 2.4m feet apart. Even though the speakers carry an certified IP66 standard, select an install location that is protected from rain, snow, and direct sunlight for an extended product service life.
- Page 3 To mark the proper locations for mounting, remove the speaker mounting bracket by unscrewing the round plastic end-caps at each end of the speaker. If needed use a stud finder to locate a solid mounting area. Place the speaker mounting bracket against the mounting surface, use a level to ensure the mount is straight and mark the hole locations on the mounting surface with a pencil.
- Page 4 5. Speaker Cable Don’t compromise your sound quality by using thin, inexpensive speaker wire. We recommend using high quality oxygen free copper two-conductor speaker cable. For low-impedance applications (8 ohm) and runs less than 15m we recommend 16-gauge cable, and for longer runs we recommend 14 gauge or larger cable. (Wire size is less important for 70V /100V distributed audio applications but still may affect performance.) 6.
- Page 5 7. Transformer settings Depending on your application you will need to adjust the transformer settings. If you are using stereo amplifier the transformer should set to the 8 ohm position. If you are using a 70V/100V amplifier set the dial to the desired 70V/100V tap setting. Remove the endcap to expose the settings dial, this adjustment can be made with flat head screw driver.
- Page 6 Check the connections at the back of the receiver, and then at the speaker; make sure that no strands of wire from one connector are touching the other connector. Specification Model number FIOS-640T Description 6.5 Inch 2-way indoor/outdoor speaker Woofer 6.5 Inch polypropylene cone...
- Page 7 284mm 285mm 140mm 178mm 197mm...
- Page 8 See Focusaudiosg.com for details.
