MCO Home MH-A100-CO User Manual

MCOHome CO Detector is an air quality device which compatible with Z-Wave technology, it is
mainly used to detect CO concentration in industrial, agricultural, and residence environment. It can
be added into any Z-Wave network, and is compatible with any other Z-Wave certified devices.
 Power Supply：AC85-260V 50-60Hz or DC12V (Adaptor)
 Self dissipation: <3W
 CO detection range: 0-1000ppm
 Default alarm threshold: 70ppm (adjustable)
 Dimension：129 (dia.)* 38mm
 Hole Pitch：60mm or 82mm
 Housing: Tempered glass+ PC Alloy
Optional Model
MH-A100-CO-WA
MH-A100-CO-WD
To protect yourself and others from danger and to protect the device from damage, please read the
safety information before using it.
Important!
 A qualified electrician with the understanding of wiring diagrams and knowledge of electrical
safety should complete installation following the instructions.
 Before installation, please confirm the real voltage complying with the device's specification. Cut
off any power supply to secure the safety of people and device.
 During installation, protect the device from any physical damage by dropping or bumping. If
happens, please contact the supplier for maintenance.
 Keep the device away from acid-base and other corrosive solids, liquids, gases, to avoid damage.
 Avoid overexertion during operation, to protect device from mechanical damage.
 Read all instructions and documentation and save for future reference.
MCOHome Technology Co., Ltd 2014
www.mcohome.com
CO Detector
MH-A100-CO
Introduction
Specification
Power Supply
85-260VAC
12VDC
Safety Information
Output
Relay 5A
Relay 5A
User Manual
Installation
Wall-mounted
Wall-mounted
1
