Vacuum Gauge
On/Off
Switch
Dear Customer,
Congratulations on your purchase of this versatile and need-oriented suction unit. It will serve you well for years, if
properly looked after. The medical profession have long felt the need for a lightweight, easy-to-move, safe,
dependable and easy-to-regulate suction unit. EUROVAC fills this healthcare need to a degree unmatched by any
other unit. It is designed for use in hospitals, nursing homes, home care, pediatric care, ICUs and patient care. Non
corrosive and shockproof enclosure is pressure moulded in engineering plastic ABS giving smooth and
easy-to-clean surface.
ASSEMBLY
The pump is housed in the enclosure. To fasten it well with the base, two black head screws (used as holdfast for
transportation at the bottom of the unit) MUST be removed by rotating with the aid of a simple hand tool.
The bacterial filter is slipped into the safety jar (at the back) and the other end is connected to the nozzle marked
"Vacuum" on the jar lid. The second nozzle is marked "patient" and the tubing from this goes to the patient. The
release valve for adjusting the negative pressure, vacuum gauge and an on/off switch are on the panel. Main lead
and fuse are at the side of the unit.
The lid connector and bacterial filter MUST be twisted and then pulled out.
TECHNICAL DATA
Housing
Max. Vacuum / LPM
Pump Type
Jars
Filter
Tubing
w w w . a n a n d i n d . c o m
w w w . a n a n d i n d . c o m
Instruction Cum User Manual
For EUROVAC
ABS Plastic Moulded
600 mm Hg, 30 Ltrs / min Diaphragm
Pump
1 x 2 Ltr. PC Jar (option of 2nd jar
also available)
Bacterial Filter Autoclavable / Reusable
8 mm ID x 2 mtr. (Silicon)
An ISO 9001:2015 & 13485:2016 Certified Company
Vacuum control knob
Push-in Nozzle
Connector for
Patient use
Bacterial Filter
Electronic
Safety Jar
2 Ltr PC Jar
Vacuum Gauge
Power Supply
Noise Level
Dimensions
Net Weight
Overflow Safety
Page - 1
Fuse
Back Side
6.25 cm dia 0-760 mm Hg
220 V AC, 50 / 60 Hz, 90 Watt
55 dB A ± 3
41 x 22 x 37 cms
8 Kg
Mechanical / Electronic
DOC ID NO :
REV : 02
DATE : 01-11-2015
6112
Advertisement
Summary of Contents for ANAND MEDICAIDS EUROVAC
- Page 1 The medical profession have long felt the need for a lightweight, easy-to-move, safe, dependable and easy-to-regulate suction unit. EUROVAC fills this healthcare need to a degree unmatched by any other unit. It is designed for use in hospitals, nursing homes, home care, pediatric care, ICUs and patient care. Non corrosive and shockproof enclosure is pressure moulded in engineering plastic ABS giving smooth and easy-to-clean surface.
- Page 2 Instruction Cum User Manual For EUROVAC VACUUM AT ALTITUDES The specified maximum vacuum refers to sea level. According to local conditions and barometric pressure, slight deviations in vacuum reading may be noted. The table below shows several factors, by which the indicated maximum vacuum value must be multiplied, according to the altitude of location where the measurement is carried out.
- Page 3 Instruction Cum User Manual For EUROVAC The unit has not to be tampered with by any mechanic other than our factory engineer, or the person authorized. Filter OPTIONAL: Gauge When the unit is fitted Sensor Safety with two jars, the two-way...
- Page 4 For EUROVAC TERMS OF WARRANTY Anand Medicaids Private Limited warranty the high quality and workmanship of each Anand's EUROVAC for a period of one year subsequent to the date of delivery by the company. During this period, faulty material will be replaced free of charge. This warranty does not extend to components that are subject to wear and tear in the course of normal operation or due to improper treatment/maintenance as per instructions.
