Summary of Contents for bigboi SUCKR PRO
- Page 2 BIGBOI or any authorized resellers in your region.. Contact our customer service for corresponding help. BIGBOI will either repair or replace the product if any part or parts covered under this warranty which examination proves to be defective in workmanship or material during the warranty period.
- Page 3 GENERAL & SPECIFIC SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your SUCKR PRO works. Read and understand the following safety rules before operating. Learn its application and limitations as well as its specific potential hazards.
- Page 4 1.CONDITIONAL MARKS General warning sign （ Risk to people, explained by additional sign or text ） See the instructions on safety and operation techniques/brochure Wear hearing protection Wear eye protection Wear a mask Risk of electric shock ! Alternating current Degree of protection against dust and water Special disposal to prevent possible...
- Page 5 2.GETTING TO KNOW YOUR SUCKR PRO 1.Sofa brush 2.Vacuum cleaner tank 3.Lock catch 4.Air outlet plate 5.Extension plastic tube 6.Hose connector 7.Cover Handle Operation mode switch 10.Hose 11.Set of transport wheels 12.Remote 13.Crevice tool 14.Dust Bag 15.HEPA filter 16.Small round brush 17.Rotating floor brush...
- Page 6 BIGBOI is constantly working on improving its products and reserves the right to make changes to the appearance, design, equipment, and content of the original instructions for the safety and operation of the SUCKR PRO without notifying consumers. All possible changes will be aimed exclusively at the improvement...
- Page 7 3.TECHNICAL DATE Parameter SUCKR PRO Rated voltag 220-240 V Frequency 50/60HZ Rated Powe 1600W Container volume Wet volume(max) Water tank(extraction) 4.5L Vacuum Pressure (inches of water) 84.3inchH2O Air suction capacity at Air Inlet 40L/S Suction (max) 22 KPA Pump Power ≤21W...
- Page 8 SUCKR PRO. If condensation forms on the components and parts of the SUCKR PRO, its further preparation for work or operation is prohibited until the condensation dries completely.
- Page 9 Install the four transport wheels（1）(Pic.4) For hard-to-reach areas, use the crevice tool (3)(Pic.5) Do not use the SUCKR PRO to suck up large pieces of garbage or household waste.This can lead to clogging of the rod, flexible hose, or clogging of the nozzle.
- Page 10 ①Turn the switch to position 'I' （Pic 9） ② Press the setting button(S) twice （Pic 11）,press on/off(A) on the remote ( Pic 10 ) ③The SUCKR PRO stops working when matching. Then after 10 seconds, the remote works （Note： SUCKR PRO already...
- Page 11 5.When the first use XTRACTR KIT, code matching is required, steps as follows, ①Turn the switch to position 'I'（Pic 9） , the SUCKR PRO starts working② Press the setting button(S) twice （Pic 11）， press V or S on the remote ( Pic 14) ③The SUCKR PRO stops when matching .
- Page 12 Never use solvents or other aggressive chemicals to clean non-metallic parts of the SUCKR PRO. These chemicals can degrade the properties of the materials used in these parts. Do not allow any liquid to get inside the SUCKR PRO. Pic.15...
- Page 13 Remove the cassette filter from the top cover of the vacuum cleaner, rinse with water and dry(Pic.16). -When using a paper bag, remove it, dispose of it and install a new bag. After wet cleaning: -Remove the upper part of the vacuum cleaner, pour out the collected liquid, shake or blow the inside of the tank, wash the filter and collect the vacuum cleaner.
- Page 14 7.STORAGE AND TRANSPORTATION It is recommended to store the SUCKR PRO in a dry place inaccessible to children, at a temperature from -5°C to +40°C, with a relative humidity of no more than 80%. If you have stored or transported the u n i t at a temperature lower than that, a t which you plan to use it, you must ensure that there is no condensation on the unit.
- Page 15 9.POSSIBLE FAULTS AND METHODS OF THEIR ELIMINATION Malfunctio Possible reason Handling method Engine housing Clean the ventilation holes. Poor cooling overheating Make sure that the ventilation holes are not closed during operation. Contamination of the Clean the filter element. filter element Make sure that the electrical Mismatch of network parameters...
- Page 16 10. PARTS DIAGRAM MODEL SUCKR PRO...
- Page 17 11. PARTS LIST MODEL SUCKR PRO Setting button...
