Alemlube AA46001N Owner's Manual

Oil filter crusher with stand

Download this manual

Description

The AA46001N Oil Filter Crusher has been designed and engineered to reduce your recycling costs and take

a positive step towards an environmentally friendly workshop.

NSW/ACT

QLD/PNG

TEL: (02) 9677 1555

TEL: (07) 3204 9166

FAX: (02) 9675 1155

FAX: (07) 3204 1224

OWNER'S MANUAL

Oil Filter Crusher with Stand

VIC/TAS

TEL: (03) 8787 8288

FAX: (03) 8787 8266

Visit our website at

www.alemlube.com.au

SA/NT

TEL: (08) 9302 4199

TEL: (08) 8241 7111

FAX: (08) 9303 2095

FAX: (08) 8241 7011

www.alemlube.co.nz

AA46001N

September 2022

TEL: (09) 447 1007

FAX: (09) 447 1008

Need help?

Do you have a question about the AA46001N and is the answer not in the manual?

Page 1 OWNER’S MANUAL AA46001N Oil Filter Crusher with Stand September 2022 Description The AA46001N Oil Filter Crusher has been designed and engineered to reduce your recycling costs and take a positive step towards an environmentally friendly workshop. NSW/ACT QLD/PNG VIC/TAS SA/NT...
Page 2 OWNER’S MANUAL AA46001N Oil Filter Crusher with Stand Assembly Instructions 1. Install (106) Casters onto (102) Trolley with (104) Nut and (105) Spring Washer and tighten the screw. 2. Install (103) Crusher Base onto (102) Trolley with (108) Screw (109) Spring Washer and (110) Screw and tighten the screw.
Page 3 Parts and Drawing Breakdown for AA46001N AA46001N-019 AA46001N-020 AA46001N-005 AA46001N-018 AA46001N-006 AA46001N-046 AA46001N-046 AA46001N-017 AA46001N-048 AA46001N-049 AA46001N-016 AA46001N-015 AA46001N-060 AA46001N-045 AA46001N-013 AA46001N-007 AA46001N-044 AA46001N-061 AA46001N-021 AA46001N-043 AA46001N-005 AA46001N-014 AA46001N-042 AA46001N-012 AA46001N-041 AA46001N-040 AA46001N-039 AA46001N-011 AA46001N-004 AA46001N-038 AA46001N-010 AA46001N-024 AA46001N-009 AA46001N-037...
Page 4 Ordering Spare Parts Alemlube No. Description Alemlube No. Description AA46001N-001 Press Room AA46001N-039 Air Valve Piston AA46001N-002 Back-Up Ring AA46001N-040 Piston Cap AA46001N-003 O-Ring AA46001N-041 Screw AA46001N-004 Press Rod AA46001N-042 O-Ring AA46001N-005 Spring Lock AA46001N-043 Back-Up Ring AA46001N-006 Spring AA46001N-044...
