Summary of Contents for Roithner LaserTechnik G098PU1600M
- Page 1 Manual of 980nm Fiber Coupled Laser Diode Module G098PU1600M G098PU1750M G098PU11300M G098PU25W G098PU209W G098PU312W G098PU322W 02.04.2012 Manual G098PU Series 1 of 10 This datasheet has been downloaded from http://www.digchip.com at this page...
- Page 2 1 Introduction Thank you for choosing this high power fiber coupled Laser Diode for your application. Please read that manual carefully before using this product. If there is any question about this manual, please contact us. The 980nm series high power Fiber coupled Laser Diodes with optimized QW structure have a high reliability, high performance.
- Page 3 2 Specifications 2.1 optical and electrical specification G098PU G098PU G098PU G098PU G098PU G098PU G098PU32 Type 1600M 1750M 11300M 209W 312W Optical specification 0.75 Rated output optical power λ Central Wavelength (nm) λ 980±10 980±10 980±10 980±10 980±10 980±10 980±10 Central Wavelength (nm) <4 <4...
- Page 4 Slope efficiency E : Characterization of the photo electronic conversion efficiency of Laser Diode after =ΔP/ΔI, where ΔP is the increment of output power corresponding to the the lasing begins; E increment of driving current ΔI. =ΔV/ΔI, where ΔV is the increment of voltage of laser diode corresponding to the Resistance R increment of driving current ΔI.
- Page 5 2.3 Dimension size 2.3.1 P1 Package Dimensions: PD - LD - LD + 02.04.2012 Manual G098PU Series 5 of 10...
- Page 6 2.3.2 P2 Package Dimensions: 2.3.3 P3 Package Dimensions: 02.04.2012 Manual G098PU Series 6 of 10...
- Page 7 3 Laser safety operating instructions 3.1 Laser usage requirements in environment A ultra-clean environment should be provided for operating the LD. The operating temperature should be controlled at –10 °C … 45 °C. Laser safety warning signs should be posted in the working place. 3.2 The requirements on the power supply driving the LD ...
- Page 8 The operating current of laser must not be higher than the given rate current. The excessive current would accelerate aging and shorten lifetime, even damage the LD. Keep the fiber pigtail clean. In non-working environment, you must use the protection case to avoid fiber pigtail from being polluted.
- Page 9 Short-circuit bridge When laser is working, please don’t point it straight to the fiber as shown below the yellow part, in order to prevent the fiber protection case from being damaged by high- power laser generated heat. Bending diameter of the fiber cannot be allowed to be less than 4cm. When bending the fiber, please make sure the starting point is away larger than 4cm from the fiber root.
- Page 10 × 3.4 Cooling system High-power semiconductor Laser Diodes are temperature-sensitive devices. High temperature will affect its performance. Its lifetime may also be shortened by working at high temperature. So the generated heat must be removed in time when the LD is working. Water cooling system or TEC system is recommended for keeping the LD working at appropriate temperature.
