Model(s):
HOEF-J0030
HOEF-J0040
HOEF-J0050
• Important operating
and maintenance
instructions included.
Congratulations!
Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning fireplaces.
The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and efficiency.
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions
before using appliance.
Electric Fireplace
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
Owner's Manual
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the HOEF-J0030 and is the answer not in the manual?

Questions and answers

Summary of Contents for 1Easylife HOEF-J0030

  • Page 1 Electric Fireplace Owner’s Manual Installation and Operation Model(s): HOEF-J0030 HOEF-J0040 HOEF-J0050 NOTICE DO NOT DISCARD THIS MANUAL • Important operating • Read, understand and follow • Leave this manual with and maintenance these instructions for safe party responsible for use instructions included.
  • Page 2 IMPORTANT SAFETY INFORMATION! WARNING  Read all instructions before using this heater!  This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear.
  • Page 3  ALWAYS mount to wall bracket before use. DO NOT set on the floor, or other surface, to use.  NEVER use a wall mount bracket from another manufacturer.  This product is not intended to be a primary heat source. It is for supplemental heat only. ...
  • Page 4 B. Wood Screws C .Drywall anchors F.Log set E. Wall Bracket Remote Fixed on back of firebox control Fireplace Decorative Crystals Specification and Dimension PRODUCT DIMENSIONS Model Number HOEF-J0030 30” 17.0” 4.13” 26.2” 16.2” 9.1” 23.7” 76.2cm 43.2cm 10.5cm 66.5cm 41.2cm 23.2cm...
  • Page 5 Installation and Assembly Your appliance is a wall-mounted, recessed and /or mantel installed appliance. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffic areas. NOTE： Follow all National and local electrical codes. MINIMUM CLEARANCE TO COMBUSTIBLES Measurements are taken from the glass front.
  • Page 6 RECESSED TO WALL INSTALLATION Figure (1) Hole cut size...
  • Page 7 Figure (1) STEP 1. Selection a dry wall to open a hole for fireplace box. Size of hole as below chat Figure (1) Framing Hole Size Model Number 26.77”(68.0cm) 16.54”(42.0cm) HOEF-J0030 36.77”(93.4cm) 16.54”(42.0cm) HOEF-J0040 HOEF-J0050 46.77”(118.8cm) 16.54”(42.0cm) STEP 2. Fix the four wall anchors in each side of the fireplace box according to the dimensions...
  • Page 8 STEP 3. Take off the two screws in both sides of fireplace. Figure (3) STEP 4. Have two person to take the glass panel out of the fireplace box（Lift up glass first, then goes to premise）. Place it to a soft and clean place. Figure (4) , take two pcs of foam out of fireplace(5).
  • Page 9 See Figure (9) (10) STEP 5. Have two person to move the fireplace box to the wall hole or fireplace mantel (6). If the appliance is fully recessed into the wall:  Use the 4 screws(B provided) to lock the appliance into wall with the existing two side flanges, see Figure(7) ...
  • Page 10 Wall Mounted Installation Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. 1.Select a location that is not prone to moisture and is located at least 36”(914mm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc.
  • Page 11 NOTE: It is strongly Recommended that the mounting bracket(d) be screwed into the wall studs where possible. If the wall studs cannot be used, ensure that the supplied plastic anchors are used to affix the bracket to the wall and the bracket is adequately secured. 1.With the wall mounting bracket installed have two people lift the appliance up and insert the two hooks on the bracket into the two slots on the back of the appliance.Use original 4x8mm screws to fasten wall bracket.
  • Page 12 Fig.8...
  • Page 13 Logset /Crystal Ember Installation (Note: Please make the installation according to the embers which you bought or selected.) 1.Glass front must be removed and the appliance must be mounted in its final location before the logset/crystal embers are installed. A. If your fireplace come with lotset, remove the logset from the package, put it to the fireplace designed place. Figure 1.
  • Page 14 WARNING Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure do to so could result in electric shock, fire, serious injury, or death. Power Plug the power cord into a 120V Volt 12.5 Amp grounded outlet (see IMPORTANT SAFETY INFORMATION on Pages 2 and 3).Make sure the outlet is in good condition and that the plug is not loose.NEVER exceed the maximum amperage for the circuit.
  • Page 15 BUTTON FUNCTION ACTION&INDICATION Enables control panel functions and remote 1. Press once. Indicator light turns on. Power turns control.Turn on flame effect. on. All functions enabled. OFF: Disables control panel functions and remote 2. Press again. Indicator light turns off. Power POWER control.Turn off flame effect.
  • Page 16 NEVER dispose of batteries in fire. Failure to observe this precaution may result in an explosion. Dispose of batteries at your local hazardous material processing center. CARE AND MAINTENANCE Cleaning ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace.
  • Page 17 2. Not aiming control correctly. control. 2. Aim control at sensor located directly behind glass screen in 3. Defective remote control and /or center of unit just above logs. sensor 3. Replace remote control and/or sensor. 1 easylife electric fireplace Email : support@1easylife.com.cn...
