Summary of Contents for ignik FIRECAN DELUXE

  • Page 1 DELUXE FIR E P IT & GRI LL OWN ER’S M ANUA L MO DEL # IGP RO - 0032 2...
  • Page 2 WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. FIRE OR EXPLOSION HAZARD If you smell gas: 1. Shut off gas to the appliance 2.
  • Page 3 WARNING: FOR OUTDOOR USE ONLY Installation and service must be performed by a qualified installer, service agency, or gas supplier. WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
  • Page 4 Never use a flame. Bubbles in the water indicate a leak. Check that your connections are not cross-threaded and they are tight. Perform another leak test. If there is still a leak, remove the cylinder and contact IGNIK for service or repairs.
  • Page 5 Inspect hose prior to each use of the unit. The hose assembly must be replaced prior to the appliance being put into operation if there is evidence of excessive abrasion or wear, or if the hose is damaged. Contact Ignik Outdoors should you require a replace- ment hose.
  • Page 6 FIRECAN DELUXE PARTS ™ FireCan Deluxe™ Fire Pit / Grill - Model # IGPRO-00322 Removable Lid Lid Lock Removable Insert Handle Grill Grate Handle Connection Grill Insert FireCan™ Housing Silicone Flame Screen Handles Grill Fire Pit Quick-Connect Quick-Connect Foldable Legs...
  • Page 7 2. Remove all items from inside the unit including the regulator hose, grill grate, and insert handle, discard all packaging. 3. Fold open all foldable legs and place FireCan Deluxe™ on a flat, non-flammable surface. 4. Pull back spring collar of Quick-Connect socket and push on to Quick-Connect stem attaching the regulator hose to the FireCan Deluxe™...
  • Page 8 GRILL MODE WARNING: The FireCan Deluxe™ Grill Insert must be removed before igniting in Fire Pit Mode. There are 2 separate input valve stems for Grill Mode and Fire Pit Mode. Make sure to verify that the proper input valve is connected before lighting.
  • Page 9 FIRE PIT MODE WARNING: The FireCan Deluxe™ Grill Insert must be removed before igniting in Fire Pit Mode. There are 2 separate input valve stems for Grill Mode and Fire Pit Mode. Make sure to verify that the proper input valve is connected before lighting.
  • Page 10 * Do not use the fire pit until all leaks are corrected . 5. Place the tank to the side or rear of the FireCan Deluxe™. Make sure the hose does not touch any part of the FireCan Deluxe™...
  • Page 11 2. With hand ready on the Flame Adjustment Knob, place elongated lighter (BBQ style lighter) in Ignition Hole on side of FireCan Deluxe™ and ignite lighter. CAUTION: Make sure to double check the icon for Grill Mode or Fire Pit Mode. DO NOT LIGHT IN FIRE PIT MODE WITH THE GRILL INSERTED INTO THE FIRECAN HOUSING.
  • Page 12 4. After cool, remove Quick-Connect Socket from FireCan Deluxe™, and remove hose connector from LP tank valve.. 5. When FireCan Deluxe™ is cool to the touch, it is safe to coil and place hose inside. 6. Reconnect lid by placing lid hinge on FireCan Deluxe™...
  • Page 13 Never clean the stainless steel when it is hot. Do not use chemical cleaners on the Grill Grate, other than soapy water. Allow Firecan Deluxe™ to dry, and store covered or indoors. NOTE: After initial use, the FireCan Housing and Grill Insert may discolor (usually a mix of bluish, reddish or yellow color).
  • Page 14 KEEP UP ON THE LATEST & HELP US BE THE CHANGE @ignikoutdoors #MORHEATLESSWASTE #STAYOUTLONGER W W W . I G N I K . C O M I G N I K O u t d o o r s 4 0 3 M a d i s o n A v e N # 2 4 0 , B a i n b r i d g e I s l a n d , W A 9 8 1 1 0 W E G I V E 1 % O F A L L...
