- Page 2 Part List 1. Chassis with 3-cell AA battery holder 10. Right angle bracket 2 x 2 holes - 2 pcs. 2. KidBright32iA Board 11. 10mm. Plastic Standoffs - 4 pcs. 3. Base plate for KidBright32iA Board 12. Thumb Screw - 4 pcs. 4.
- Page 3 Assembly Robot (Step-by-Step) (1) Install the ball caster wheel set with the chassis by tightening the 2mm. screws and nut at the positions of the bottom side of the chassis following the photo below. Holes for mounting the ball caster wheel.
- Page 4 (2) Attach the KSERVO-360J servo motor to the robot chassis with two M3x25mm. screws. Tighten the mounting nuts and do the same on both sides. Bottom Side Top Side (3) Insert the Technics wheels to both motor shafts.
- Page 5 (4) Mount four 25mm. metal standoffs onto the robot chassis, tighten with M3x6mm. screws, and put 3 of AA batteries into the battery holder. 25mm. metal standoffs mounting holes 25mm. metal standoffs mounting holes M3x6mm. screws to tighten the metal standoffs Put 3 off AA batteries into the battery holder (5) Assemble the KidBright32iA board to the base plate with the 10mm.
- Page 6 (6) Mounte the KidBright32iA board that has been fix with the base plate onto the metal standoffs and tighten it with 4 of thumb screws. (7) Mount the ZX-03 Infrared sensor at the bottom of chassis to detect lines on the floor by using M3x10mm.
- Page 7 (8) Attach the ZX-SONAR1M ultrasonic sensor to the right angle bracket 2 x 2 holes with M3x6mm. flat head screws. (9) Mount the ZX-SONAR1M ultrasonic sensor with the right angle bracket 2 x 2 holes onto the robot chassis with M3x6mm. screws and tighten the nuts. mounting holes...
- Page 8 (10) Wiring instructions - Connect the ZX-SONAR1M ultrasonic sensor to connector. - Connect the ZX-03 infrared sensor (left) to connector and the ZX-03 infrared sensor (right) to connector. - Connect the left KSERVO-36J servo motor to connector and the right KSERVO-360J servo motor is connected to connector - Connect the KB-CHAIN cable between the KidBright32iA board and KB-CHAIN...
