- Page 1 Manual LED Light Pergola Gazebo San Pablo 3x3m, 3x4m and 4x4m 24-06-2024...
- Page 2 Part List for LED Light for Pergola Gazebo San Pablo 3x3m, 3x4m and 4x4m PART NAME DRAWING 12 V switching power supply＋ ＇ Power cord with plug+power cable of controller ＼＿ LED controller + power cable /> 三 Tee joint LED stripes 3m=2.6m, 4m=3.6m Cover...
- Page 3 Step 1: Install the LED stripe 4 onto the front and rear beam C (Tips: Distance of each transparent card is 20-25cm) Front and rear beam C*2 Female end Stripe bracket 6 Screw for stripe bracket 7 Stripe cover 5*2 LED stripe 4*2 Transparent card 8 Sub end...
- Page 4 Step 3： Step 2: Step 1: Connect the female end Connect the sub end of the LED cable 2 Connect the power cable 1 on the beam C with the sub end with the female end of the Tee joint 3; with the LED controller 2, on the B2;...
- Page 5 Contact information Austria Belgium Croatia Denmark Estonia Finland France Germany Ireland Italy Latvia Lithuania Nederland Norway Poland Portugal Spain Sweden Switzerland For more information please visit: www.dancovershop.com...
