Operating Instructions
EasyNet Rack PDU Basic
SCHÄFER
IT-Systems
EasyNet Rack PDU Basic
Power distribution solution
SCHÄFER IT-Systems SCHÄFER Ausstattungssysteme GmbH Industriestraße 41 57518 Betzdorf,
Page 1 of
13
Tel.: +49 (0) 2741 283 770 sales@schaefer-it-systems.de
Germany
Stand: 28.06.2024 (subject to technical changes)
www.schaefer-it-systems.de
Advertisement
Summary of Contents for Schäfer EasyNet Series
- Page 1 Operating Instructions EasyNet Rack PDU Basic SCHÄFER IT-Systems EasyNet Rack PDU Basic Power distribution solution SCHÄFER IT-Systems SCHÄFER Ausstattungssysteme GmbH Industriestraße 41 57518 Betzdorf, Page 1 of Germany Tel.: +49 (0) 2741 283 770 sales@schaefer-it-systems.de www.schaefer-it-systems.de Stand: 28.06.2024 (subject to technical changes)
- Page 2 Operating Instructions EasyNet Rack PDU Basic Table of contents About these operating instructions ......................3 Updating the operating instructions ....................3 Applicable documents ........................3 Copyright ............................3 Presentation conventions ......................4 Safety ..............................5 Intended use ..........................5 Foreseeable misuse ........................5 Labelling on the product and its components ................5 Display of warnings in these operating instructions ..............6 Requirements for personnel ......................7 Safety instructions ........................7...
- Page 3 Operating Instructions EasyNet Rack PDU Basic About these operating instructions These operating instructions contain information and instructions that are necessary for safely operating the product. • Read these operating instructions carefully before using the appliance for the first time. • Keep the operating instructions in an easily accessible place for the entire service life of the product so that they are always available for reference.
- Page 4 Operating Instructions EasyNet Rack PDU Basic Presentation conventions Emphasis in the text Individual terms, paragraphs or information are labelled to improve readability. The labels have the following meanings: 1. Carry out the instructions one after the other in the sequence described. ✓...
- Page 5 Operating Instructions EasyNet Rack PDU Basic Safety The following instructions and information enable safe and proper use of the product. In addition to the information in these operating instructions, all information in the instructions for use of the connected devices and the accessories used must be followed. Intended use The SCHÄFER IT-Systems EasyNet Rack PDU is a power distribution solution for supplying power to electrical and electronic devices within the technical specifications provided by the manufacturer.
- Page 6 Operating Instructions EasyNet Rack PDU Basic Display of warnings in these operating instructions Warnings are labelled with the general warning sign, a signal word, a description of the hazard where necessary and measures to avoid the hazard. DANGER This symbol indicates an imminent danger to the life and health of persons. Failure to observe these instructions will result in serious damage to health and even life-threatening injuries.
- Page 7 Operating Instructions EasyNet Rack PDU Basic Requirements for personnel • Any person carrying out work on the product must have the appropriate specialist training for the type of work, and must have read and understood these operating instructions in full. This applies to all phases of the product's life and in particular to work on the electrical equipment.
- Page 8 Operating Instructions EasyNet Rack PDU Basic Conduct in an emergency • De-energise the product if it is safe to do so. • Do not extinguish the product with water. Use suitable extinguishing agents to extinguish fires in electrical systems. • Contact SCHÄFER IT-Systems in the event of malfunctions and unusual operating behaviour.
- Page 9 Operating Instructions EasyNet Rack PDU Basic Technical data The following information describes the most important specifications for the product. For further technical data, see the applicable data sheets in accordance with the type designation on the type plate. General specifications Specification Value Material...
- Page 10 Operating Instructions EasyNet Rack PDU Basic Internal separator Yes (for the varistor/surge protection function) No (for the mains voltage) Replacing the power strip after the surge protection function has Not mandatory, but the surge protection function is no longer available tripped Connection cable Min.
- Page 11 Operating Instructions EasyNet Rack PDU Basic Installation The product can be installed both vertically and horizontally in a rack using the mounting brackets. Illustration1: Horizontal mounting (example) Illustration2: Vertical mounting (example) Prerequisites • The product is free from damage. • The loads to be connected to the product are switched off.
- Page 12 Operating Instructions EasyNet Rack PDU Basic Maintenance and care DANGER When working on live parts, there is a risk of fatal electric shock. Before carrying out maintenance or servicing work, observe the five safety rules of electrical engineering. • Disconnect completely •...
- Page 13 Operating Instructions EasyNet Rack PDU Basic Disposal The crossed-out dustbin symbol indicates that a product and its accessories (e.g. mains cable) must not be disposed of with household waste at the end of their service life. To prevent harm to the environment or human health from uncontrolled waste disposal and to promote the sustainable reuse of material resources, separate these items from other types of waste and recycle them responsibly.
