Summary of Contents for Star Electrika
- Page 1 OWNER’S MANUAL...
- Page 2 Fuses & Relays…………………… ……………………......INTRODUCTION AND SAFETY PRECAUTIONS……...1-1 Bulb Specification……………………………....5-2 Introduction…………………………………………….....1-1 Spare Wheel Removal…………………………....5-3 Safety Features………………………………………..... 1-1 Technical Specifications……………………………..5-3 VEHICLE OVERVIEW……………………………………..... 2-1 Front Overview………………………………………....2-1 Instrument Panel Overview……………………….... 2-2 Instrument Cluster Overview…………………….....2-4 Warning Lamps Overview…………………………... 2-5 STARTING AND DRIVING THE VEHICLE……………..3-1 Starting and Driving…………………………………....
- Page 3 Congratulations on purchasing. Star Electrika-A1.Your vehicle 3. The life span of Star products depend on many factors. has been designed to provide years of safe and dependable Improper use, abuse or harsh use in general may...
- Page 4 1.1 Vehicle overview Hand grip Outside rear View Mirror(ORVM) Windshield Wiper Windshield Rear Park Lamp/Brake Lamp License Plate Lamp Reversing Lamp Rear Turn Signal Lamp Headlamp 10. Turn Signal Lamp 10. Turn Signal Lamp 11. Head Lamp ON/OFF Switch 12. Wiper Switch 13.
- Page 5 Instrumental Panel Overview Head Lamp ON/OFF Switch Wiper Switch Cluster Head Lamp High/Low Beam Switch Horn Turn Indicator Switch Forward and Reverse Switch Voice Message Buzzer Switch Overview...
- Page 6 1.3 Instrument Cluster 1. Speed- km/h 2. Odometer/Trip meter 3. Battery Charge Status 4. Turn Indications 5. Reverse Indication 6. High beam Overview...
- Page 7 2.4 Warning Lamps Overview Lamp Status after Symbol Warning Lamp/Tell Tale Lamp Pre-check Action/remarks Engine Starts Indicates left turn lamp is blinking Slow Blinking: Normal operation Left Turn Signal Lamp Slow or Fast Blinking Fast blinking: One/more left turn lamp bulb has fused. Have the bulb replaced Indicates left turn lamp is blinking Slow Blinking: Normal operation...
- Page 8 3 STARTING AND DRIVING THE VEHICLE To reverse, make sure that your vehicle is stationary. Then Move button to reverse (R) mode. Turn the accelerator gently 3.1 Starting and Driving and drive backward. Ensure that there is enough charge for your immediate journey NOTICE Always ensure energy level is sufficient for proposed travel 1.
- Page 9 3.1 Vehicle Charging To charge, connect the input plug of the charger to the wall Always charge your vehicle using the charger supplied with vehicle. socket (220V AC) and the output plug to the charging socket It normally takes approximately 10-12 hrs to full charge from on the vehicle.
- Page 10 NOTICE Ensure the flap is closed to start the vehicle. . Use right rating accessories & should be fixed on • Ensure 220V AC supply has earthing provision. • company provided wiring connection arrangement Ensure charging to be done in proper ventilated area. •...
- Page 11 5.3 Spare wheel Removal 5.4 Technical Specifications Specification E-Rickshaw (Soft top) E-Rickshaw (Hard top) Spare wheel is located under the rear seat of the vehicle. Laden tyre pressure Lift the rear seat. • Front: 38psi & Rear: 46psi Front: 38psi & Rear: 46psi (front &...
- Page 12 Battery Specifications Lead Acid Battery/packaged under Front passenger seat Battery type/location Pack voltage 48V DC system Capacity 12 V 120 Ah X 4 Batteries Motor Specifications Motor Specifications Type BLDC motor Power(Peak) 1.9 KW Torque(Peak) 22Nm...
