GENERAL DESCRIPTION:
Sounder mod. ECO500/ECO560/ECO500LS/ECO500XLS/ECO560LS with patented anti-foam system, double-micro anti-
shock system against hard hits and high-luminous and low-consumption led flashing light. Anti-opening and anti-
removal tamper protection – programmable sound and timing – alarm counting – microprocessor self-test of: battery
and speaker with anomaly negative output – programming of separate siren and flashing unit command – input for
flashing-unit reset – immediate or permanent optical indication of ON/OFF system – electronic circuit protected against
polarity inversion and resin tropicalization against humidity – external cover in ABS, painted metal or Stainless Steel
(ECO500XLS), bottom and internal cover in painted zinc-plated steel. The sensors detecting removal, opening, foam and
shock are series-connected and in case of a tampering attempt show the alarm by opening the contact between two
terminals TAMPER.
TECHNICAL DATA:
Cover
ECO 500 L, ECO 560 L, ECO 500 LS, ECO 560 LS
Cover
ECO 500 XLS
Bottom and internal cover
Flash cover
Minimum supply voltage (to ensure full battery recharge)
Voltage of battery recharge
Minimum voltage of functioning
Maximum voltage of functioning
Batteries
Current consumption in stand-by
Battery autonomy in stand-by
Current consumption from control panel during battery recharge
Battery current consumption during sounder alarm
Current consumption of flashing unit
Current absorption of the control inputs (each)
Alarm voltage of sounder and flash
Block voltage of sounder and flash
Open collector output
Sounder block (option)
Sounder timing
Sounds frequency
Acoustic power
Duration of led flashing
Tamper switch
Size
ECO 500 LS, ECO 560 LS, ECO 500 LSX
Weight ECO 500 LS, ECO 560 LS
Weight ECO500 LSX
Operating humidity range
Operating temperatures
IP protection
Anti-tamper protection
Anti-foam device
Environmental class
Standards
Larmklass
Certification body
MA-SE-1140-00-06 Manuale ECO500 560 An0V EN50131 eng rev6
SELF-POWERED OUTDOOR ACOUSTIC ALARM DEVICE
ECO500 / ECO560 / ECO500LS / ECO500XLS / ECO560LS
ABS/painted ABS
stainless steel
painted zinc-plated steel
polycarbonate
13.8 V
13.0 13.8 V
10 V
15 V
12 V
1.2 Ah or 2.2 Ah
15 mA max
120 hours with 12 V 2.2 Ah battery
0.5 A 100 mA
1.3 A +100/-300 mA
90 10 mA
+0.5 mA @Vc= 12 V
; -0.3 mA @Vc=0 V
< 2.0 e > 3.5 V
(MAX 13.8 V
> 2.0 e < 3.5 V
(MAX 13.8 V
-10 mA Max
on request
3 minutes – programmable at 8 minutes
see Chart. 9
> 107 dB (A) @ 3 m.
1,000,000 flashes
N.C. 0.2 A max.
190x220x80 (HxLxD)
2,230 g
2,400 g
from 20 % to 100 %
from -25° C to + 70° C
IP34
cover opening, sounder removal, foam and shock
patented double micro-switch anti-foam device
IV
EN50131-4:2009 (degree 3)
SSF1014 v.5
T031:2018
Larmklass 3
Telefication BV/Applica Test & Certification AS
)
)
page 1 of 4
