EMAC GENE-3150 Manual

Risc cpu module
Hide thumbs

Advertisement

Quick Links

Download this manual
To learn more about EMAC's products and services and how they can help your project
http://ftp.emacinc.com/Tech_Info/About_EMAC_Products_and_Services.pdf
Authorized Distributor, Integrator, and Value-Added Reseller
Manual downloaded from
ftp.emacinc.com
For purchase information please contact
info@emacinc.com
For technical support please submit a ticket at
www.emacinc.com/support

Advertisement

loading
Need help?

Need help?

Do you have a question about the GENE-3150 and is the answer not in the manual?

Questions and answers

Related Manuals for EMAC GENE-3150

Summary of Contents for EMAC GENE-3150

  • Page 1 To learn more about EMAC’s products and services and how they can help your project http://ftp.emacinc.com/Tech_Info/About_EMAC_Products_and_Services.pdf Authorized Distributor, Integrator, and Value-Added Reseller Manual downloaded from ftp.emacinc.com For purchase information please contact info@emacinc.com For technical support please submit a ticket at...
  • Page 2 R I S C C P U M o d u l e G E N E - 1 3 5 0 GENE-1350 TI OMAP 3503/3530 Processor RISC CPU Module USB2.0 Host x 2 / USB2.0 Client x1 RS-232 x 1/ RS-23 2/485 x 1 TTL UART x 1 256MB NAND Flash, SD, MicroS D GENE-1350 Rev.A Manual 1st Ed.
  • Page 3 R I S C C P U M o d u l e G E N E - 1 3 5 0 Copyright Notice This document is copyrighted, 2010. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice.
  • Page 4 R I S C C P U M o d u l e G E N E - 1 3 5 0 Acknowledgments All other products’ name or trademarks are properties of their respective owners. Award is a trademark of Award Software International, Inc. CompactFlash™...
  • Page 5 R I S C C P U M o d u l e G E N E - 1 3 5 0 Packing List Before you begin installing your card, please make sure that the following materials have been shipped: •...
  • Page 6 R I S C C P U M o d u l e G E N E - 1 3 5 0 Contents Chapter 1 General Information 1.1 Introduction............1-2 1.2 Features ..............1-3 1.3 Specifications ............1-4 Chapter 2 Quick Installation Guide 2.1 Safety P recautions..........
  • Page 7 R I S C C P U M o d u l e G E N E - 1 3 5 0 2.18 UART1 Port Con nector (CN8) ......2-12 2.19 SIM Card Conne ctor (CN9)....... 2-13 2.20 Mini Card 1 Co nnector (CN10)......2-13 2.21 COM2 RS-232/422/485 Connector (CN11) ..
  • Page 8 R I S C C P U M o d u l e G E N E - 1 3 5 0 Chapter General Information 1- 1 Chapter 1 General Information...
  • Page 9 R I S C C P U M o d u l e G E N E - 1 3 5 0 1.1 Introduction GENE-1350 adopts TI OMAP 3503/3530 Processor. This RISC CPU module features low power consumption and cost -efficiency, to fu lfill the requirements of hardy and more cost-focusing applications.
  • Page 10 R I S C C P U M o d u l e G E N E - 1 3 5 0 1.2 Features TI OMAP 3503/3530 Processor 3D Graphics & Video Accelerator Support with 3530 Processor Onboard 128/256 MB (Optional) LP DDR RAM 10/100Base-TX Ethernet CRT/ 24-Bit TTL LCD/ 18-Bit LVDS LCD 2CH Audio...
  • Page 11 R I S C C P U M o d u l e G E N E - 1 3 5 0 1.3 Specifications System • CPU TI OMAP 3503/3530 600 MHz Processor System Memory Onboard 128/256MB (Optional) LP DDR RAM Ethernet Davicom DM9000AEP, 10/100Base-TX, RJ-45 x 1...
  • Page 12 R I S C C P U M o d u l e G E N E - 1 3 5 0 non-condensing MTBF (Hours) 100,000 Display Chipset TI OMAP 3 Resolution Up to 1280x768 for LCD Up to 1024x768 for CRT LCD Interface Up to 24-bit single channel TTL and 18-bit single channel...
  • Page 13 R I S C C P U M o d u l e G E N E - 1 3 5 0 Chapter Quick Installation Guide 2 - 1 Chapter 2 Quick Installation Guide...
  • Page 14 R I S C C P U M o d u l e G E N E - 1 3 5 0 2.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it. Do not make connections while the power is on, because a sudden rush of power can damage sensitive electronic components.
  • Page 15 R I S C C P U M o d u l e G E N E - 1 3 5 0 2.2 Location of Connectors and Jumpers Component Side CN20 CN26 CN17 USB1 CN13 CN25 CN15 CN19 CN28 CN21 CN24 CN23 CN22...
  • Page 16 R I S C C P U M o d u l e G E N E - 1 3 5 0 Solder Side CN27 2 - 4 Chapter 2 Quick Installation Guide...
  • Page 17 R I S C C P U M o d u l e G E N E - 1 3 5 0 2.3 Mechanical Drawing Component Side 146.05 143.81 142.88 142.88 139.73 142.36 139.73 134.48 132.92 128.05 123.83 123.24 122.88 119.81 116.06 107.23...
  • Page 18 R I S C C P U M o d u l e G E N E - 1 3 5 0 Solder Side 142.88 122.88 98.68 91.46 67.46 33.73 9.53 8.89 8.89 0.00 2 - 6 Chapter 2 Quick Installation Guide...
  • Page 19 R I S C C P U M o d u l e G E N E - 1 3 5 0 2.4 List of Jumpers The board has a number of jumpers that allow you to configure your system to suit your application. The table below shows the function of each of the board's jumpers: Label Function...
  • Page 20 R I S C C P U M o d u l e G E N E - 1 3 5 0 CN11 COM2 RS232/422/485 Connector CN12 Battery Connector CN13 Micro SD Connector CN14 JTAG Connector CN15 Touch Panel Connector CN16 Backup Battery Connector CN17...
  • Page 21 R I S C C P U M o d u l e G E N E - 1 3 5 0 2.6 Setting Jumpers You configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.
  • Page 22 R I S C C P U M o d u l e G E N E - 1 3 5 0 2.7 Reset Selection (JP1) Function PWRON HWRST# WARMRST# 2.8 COM2 VCC Selection (JP2) Function 3.3V (Default) 2.9 COM2 RS-232/422/485 Selection (JP3) Function RS-485 RS-232 (Default)
  • Page 23 R I S C C P U M o d u l e G E N E - 1 3 5 0 2.12 Camera Module Connector (CN2) Signal Signal VCC3.3 VCC3.3 VIO_1v8 CAM_HS CAM_VS CAM_PCLK CAM_XCLKA I2C_SDA I2C_SCL CAM_D0 CAM_D1 CAM_D2 CAM_D3 CAM_D4...
  • Page 24 R I S C C P U M o d u l e G E N E - 1 3 5 0 GPIO_3 GPIO_4 GPIO_5 GPIO_6 GPIO_7 GPIO_8 Ground Ground Note: The max. rating of Pin 1, 2 is 0.5A @ 3.3V; the max. rating of Pin 3 ~ Pin 1 0 is 8mA @ 3.3V 2.15 Left Audio Amplifier Output Connector (CN5)
  • Page 25 R I S C C P U M o d u l e G E N E - 1 3 5 0 Ground Note: The max. rating of Pin 1 is 0.5A @ 3.3V 2.19 SIM Card Connector (CN9) Signal Signal UIM_PWR UIM_RST...
  • Page 26 R I S C C P U M o d u l e G E N E - 1 3 5 0 Ground Ground VCC3.3_BAT Ground VCC3.3_BAT Null Ground Null Null Null Null VCCA1V5 Null Ground Null VCC3.3_DUAL1 2.21 COM2 RS-232/422/485 Connector (CN11) Signal Signal DCD2...
  • Page 27 R I S C C P U M o d u l e G E N E - 1 3 5 0 DAT0 DAT1 Ground Ground Ground Ground 2.24 JTAG Connector (CN14) Signal Signal R_JTAG_HDR_TMS R_JTAG_HDR_TRST R_JTAG_HDR_TDI Ground VCC_JTAG Null JTAG_HDR_TDO Ground JTAG_HDR_RTCK...
  • Page 28 R I S C C P U M o d u l e G E N E - 1 3 5 0 Null Ground Null VCCB1V5 Null UIM_PWR Ground UIM_DATA Null UIM_CLK Null UIM_RESET Ground UIM_VPP Null Ground Null W_DISABLE# Null IO_USB_nRESET Null...
  • Page 29 R I S C C P U M o d u l e G E N E - 1 3 5 0 Ground Ground VCC_PP1 VCC_PP1 LCD1_ENBKL Ground LCD1_CN_B0 LCD1_CN_B1 LCD1_CN_B2 LCD1_CN_B3 LCD1_CN_B4 LCD1_CN_B5 LCD1_CN_B6 LCD1_CN_B7 LCD1_CN_G0 LCD1_CN_G1 LCD1_CN_G2 LCD1_CN_G3 LCD1_CN_G4 LCD1_CN_G5 LCD1_CN_G6...
  • Page 30 R I S C C P U M o d u l e G E N E - 1 3 5 0 Null Null LVDSSPD LVDSSPC Null Null Null Null Null Null Null Null VCC_LVDS Ground Null Null Note: The max. rating of Pin 3,7,27 is 0.5A @ 3.3V 2.30 LCD Inverter Connector (CN20) Signal VCC_IVT (Inverter power)
  • Page 31 R I S C C P U M o d u l e G E N E - 1 3 5 0 Null Null Note: The max. rating of Pin 1 is 0.7A @ 5V 2.32 USB Client Connector (CN23) Signal VCC_USBOTG OTG_DN...
  • Page 32 R I S C C P U M o d u l e G E N E - 1 3 5 0 Null CRT_CN_SCL CRT_CN_HSYNC CRT_CN_VSYNC CRT_CN_SDA 2.35 SD Card Connector (CN27) Signal Signal MMC1_DAT3 MMC1_CMD Ground VDD_MMC1 MMC1_CLK Ground MMC1_DAT0 MMC1_DAT1 MMC1_DAT2...
  • Page 33 R I S C C P U M o d u l e G E N E - 1 3 5 0 GPMC_nCS7/IO_DIR GPMC_nCS5 Ground Null GPMC_A21 GPMC_nWE Null Ground GPMC_A17 GPMC_A20 GPMC_A18 GPMC_nBE0_CLE Ground Null GPMC_nOE Null GPMC_WAIT0 Null GPMC_WAIT3 GPMC_nCS0 GPMC_nWP...
  • Page 34 R I S C C P U M o d u l e G E N E - 1 3 5 0 GPMC_D11 Ground Ground GPMC_D12 GPMC_D13 GPMC_D14 GPMC_D15 VCC3.3_BAT VCC3.3_BAT GPMC_CLK Null I2C_SDA Null I2C_SCL Null Null VCC5 Null Null Null Ground...
  • Page 35 R I S C C P U M o d u l e G E N E - 1 3 5 0 Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬...
