Operating Instructions

Dishwashers

To prevent accidents and machine damage, read these instructions

before installation or use.

en-US

HG07-W

M.-Nr. 12 515 390

Need help?

Do you have a question about the G 7936 and is the answer not in the manual?

Questions and answers

Summary of Contents for Miele G 7936

Page 1 Operating Instructions Dishwashers To prevent accidents and machine damage, read these instructions before installation or use. en-US HG07-W M.-Nr. 12 515 390...
Page 3 Activating the safety lock ....................29 Miele@home (depending on model) ................30 Basic settings........................31 Setting the language ....................31 Setting up Miele@home (depending on model) ..........31 Setting the time ......................32 Setting the water hardness ..................32 Activating AutoDos....................33 Reactivation salt ......................
Page 4 Contents Remote Update (depending on the model)..............47 SmartStart (depending on the model) ................ 48 EcoStart ........................... 49 Temperature ........................50 Display ..........................50 Brightness........................50 Color scheme ......................50 Volume ..........................51 Refill indicators ....................... 51 AutoOpen ........................52 2nd interim rinse ......................
Page 5 Contents Manual detergent dispensing ..................78 Detergent dispensing....................78 Adding detergent ...................... 78 Operation ........................80 Turning on the dishwasher .................... 80 Selecting a program ....................... 80 Display of program duration ..................81 Starting a program ......................81 End of the program......................82 Energy management ......................
Page 6 Contents General dishwasher problems..................119 Noises ..........................121 Poor cleaning results...................... 122 Customer Service ......................126 Contact in the event of a fault ..................126 Appliance warranty and product registration ............. 126 Optional accessories....................127 Installation........................129 Water inlet ........................129 Water drainage........................
Page 7 IMPORTANT SAFETY INSTRUCTIONS. Miele cannot be held liable for injury or damage caused by non- compliance with these instructions. Keep the installation sheet and the operating instructions in a safe...
Page 8 IMPORTANT SAFETY INSTRUCTIONS Appropriate use  This dishwasher is intended for use in the home and in similar en- vironments, for example – in shops, offices, and similar work settings – on agricultural estates – by guests in hotels, motels, bed and breakfasts, and other typical home settings.
Page 9 IMPORTANT SAFETY INSTRUCTIONS Safety with children  Children must be kept away from the dishwasher unless they are constantly supervised.  Children must not be allowed to clean or maintain the appliance.  Children should be supervised in the vicinity of the dishwasher. Never allow children to play with the dishwasher.
Page 10 It is most important that this basic safety requirement is fulfilled. If in doubt, the electrical installation should be checked by a qualified service technician. Miele cannot be held liable for the consequences of an inadequate or lack of grounding system (e.g., electric shock). ...
Page 11 IMPORTANT SAFETY INSTRUCTIONS  The dishwasher must not be installed underneath a cooktop. The high temperatures radiated by cooktops could damage the dish- washer below. For the same reason, the dishwasher must not be in- stalled next to open fires or other appliances that give off heat, such as heaters etc., not normally found in a kitchen.
Page 12 If the power cord is damaged, it must only be replaced with a spe- cific cord of the same type (available from Miele Customer Service). For safety reasons, this must only be done by Miele Customer Ser- vice or a service technician authorized by Miele.
Page 13 This bulb must only be used for the purpose for which it is intended. The bulb is not suitable for room lighting. Replacement bulbs may only be installed by an au- thorized technician or by Miele Customer Service. Correct installation ...
Page 14 The machine must only be operated with properly adjusted door springs. If the door cannot be adjusted properly, contact Miele. The minimum/maximum weight of the front panel is quoted in the technical data for your dishwasher on the Miele website.
Page 15 IMPORTANT SAFETY INSTRUCTIONS  Do not sit, stand, or lean on the opened door. The dishwasher can tip over. This could injure you or damage the dishwasher.  Dishes may be very hot at the end of the program. Allow the dishes to cool until they are comfortable enough to handle before un- loading them.
Page 16 IMPORTANT SAFETY INSTRUCTIONS Accessories and parts  Only use original Miele accessories. If other parts are used, war- ranty, performance, and, if applicable, product liability claims will be invalidated. Transport  Damage to the dishwasher can compromise your safety. Before using the dishwasher, check it for any visible transport damage.
Page 17 IMPORTANT SAFETY INSTRUCTIONS FCC Declaration of Conformity  These devices comply with FCC Rules Part 15. This equipment has been tested and found to be in compliance with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules of Opera- tion and is subject to the following conditions: These devices may not cause harmful interference.
Page 18 Notes on the operating instructions These operating instructions apply to Additional information and comments several different dishwasher models of Additional information and comments different heights. are contained in a narrow frame. The specific dishwasher models are re- ferred to as follows: Instructions for the user Standard = 32 1/16"...
Page 19 Scope of delivery The following items are supplied: - dishwasher - operating instructions for using the dishwasher - installation sheet for installing the dishwasher - other installation accessories for in- stalling the dishwasher (see installa- tion sheet) - funnel for filling the reactivation salt (if available) - additional printed matter and add-ons if required...
Page 20 Guide to the appliance Appliance overview a Door locking pins i Salt reservoir b Top spray arm j Data plate c 3D MultiFlex cutlery tray k Rinse aid reservoir d Upper basket (depending on model) l Detergent compartment e Middle spray arm m AutoDos detergent outlet f Aeration valve n AutoDos (automatic dispensing)
Page 21 Guide to the appliance Lower basket a Glass holder b FlexCare Glass & Bottle c MultiClip d XL-Assist e Hinged spikes f StrawClean...
Page 22 For turning the dishwasher on and off. For further information, see “Display functions” under “Guide to the appli- b Optical interface ance”. For Miele Customer Service. e Back sensor button c Remote sensor button For navigating back to the previous For activating/deactivating the Re-...
Page 23 Guide to the appliance The sensor button on the control field Display functions and in the display react to fingertip con- The display is used to select or set the tact. following: The touch display can be scratched - the program by pointed or sharp objects, e.g., - any Options pens.
Page 24 Guide to the appliance Examples of how to operate the appli- Lists ance You can scroll to the right or the left by swiping your finger across the display. Main menu  Programs 11:02  Use the Back sensor control to switch from the Programs menu to the main ComfortWash ...
Page 25 Guide to the appliance Numerical values Roll-down menu You can set numerical values in some The roll-down menu can be used to dis- menus. play information about the selected pro- gram.  Time  Extras 11:02  AutoDos IntenseZone  12 00 Quick Extra clean...
Page 26 Guide to the appliance SuperVision menu You can use the  sensor control in the display to show the status of your Miele domestic appliances.  Programs  11:02  ComfortWash   °C 4:01 2:27 Sensor Wash ExtraQuiet  ...
Page 27 Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed.
Page 28 Before using for the first time If the door is opened during operation, Every dishwasher is tested at the fac- all functions are automatically inter- tory. There will be residual water in the rupted. machine from this test. It is not an in- dication that the dishwasher has been ...
Page 29 Before using for the first time Closing the door Activating the safety lock  Push the baskets in. Use the safety lock to prevent children opening the dishwasher door. The door  Raise the door upward until the catch can then only be opened by using a lot engages.
Page 30 - A WiFi network functions cannot be guaranteed. - The Miele app Miele@home availability - A Miele user account. The user ac- The ability to use the Miele app de- count can be created via the Miele pends on the availability of the Miele@home service in your country.
Page 31 Set up Miele@home?  Turn the dishwasher on using the appear on the display.  sensor control.  If you want to set up Miele@home The welcome screen will appear when now, select the option. Continue the dishwasher is turned on and the Tip: To postpone setup until later, select welcome melody will sound.
Page 32 Before using for the first time Setting the time Setting the water hardness The display changes to the screen for The time is updated automatically if a setting the water hardness. connection is established with the WiFi network. - The dishwasher must be programmed to the correct water hardness for your The display will then change to the area.
Page 33 Before using for the first time Activating AutoDos Prompts will then appear in the display. The display changes to the settings After confirming these prompts with screen for AutoDos (see “Automatic dis- OK, the messages  Refill salt and start pensing/AutoDos”...
Page 34 Before using for the first time Reactivation salt If the water in your area is very soft and constantly lower than 5 gpg In order to achieve good cleaning re- (5 °dH – German scale), you do not sults, the dishwasher needs to operate need to add reactivation salt.
Page 35 Before using for the first time Filling the salt reservoir Before filling the salt reservoir for the first time, you must fill it with approx. 1.5 L of water to enable the salt to dis- solve. Once the dishwasher has been com- missioned, there is always sufficient water in the salt reservoir.
Page 36 Before using for the first time Refilling the salt After the salt reservoir has been filled, the refill indicator may still appear in the  When the refill reminder  Refill salt display if the salt concentration has not and start the “Rinse salt” program yet reached the correct level.
Page 37 Before using for the first time Rinse aid If you only ever wish to use combina- tion detergent products in your dish- Rinse aid is necessary to ensure that washer, you do not need to add rinse water does not cling and leave marks on aid.
Page 38 Before using for the first time Adding rinse aid  Wipe up any spilled rinse aid. This prevents excess foam developing dur- ing the next program. You can adjust the rinse aid dosage for best wash results (see “Rinse aid” un- der “Settings”).
Page 39 Settings Changing settings You can alter the dishwasher’s controls to suit changing requirements by ad-  Select the setting you want to justing the settings (depending on change. model). The selected setting is marked in or- The settings can be altered at any ange.
Page 40 Settings Language  Time The display can be set to appear in one The current time of day must be set be- of several different languages. fore you can use the timer option. You can change the language used in Setting the clock format the display and also the country via the You can select either a 24-hour or 12- sub-menu.
Page 41 Settings Water hardness °d gr/gal °fH Display Your dishwasher is fitted with a water softener. - The dishwasher must be programmed to the correct water hardness for your area. - Your local water authority will be able to advise you of the water hardness level in your area.
Page 42 Settings Setting the water hardness Rinse aid  Select the water hardness level in You can adjust the rinse aid dosage for your area and confirm with OK. best results. The rinse aid dosage can be set from 0 AutoDos (AutoDos) to 6 ml.
Page 43 Settings Miele@home (depending on the model) The Miele app is available to download free of charge from the Apple App Your dishwasher is equipped with an in- ® Store or from the Google Play Store™. tegrated Wi-Fi module. You can connect your dishwasher to your Wi-Fi network.
Page 44 Deactivate As an alternative to networking via the If you do not wish to use the Wi-Fi mod- Miele app, you can connect your dish- ule of your dishwasher, you can turn it washer to your Wi-Fi network using off.
Page 45 Settings Displaying the Connection status Reset network configuration? You can call up the current connection This menu option only appears if you status of your dishwasher. have already connected your dish- washer to your Wi-Fi network.  Select the menu op- Connection status tion and confirm with OK.
Page 46 Wi-Fi network using your dishwasher. Even if the option is Remote control switched off, you can use the Miele app SuperVision display to call up information about your appli- In order to use your dishwasher as the ance. However, you cannot start any SuperVision master appliance, you have programs or change any settings from it.
Page 47 If you do not install an update, you can mestic appliances to your Wi-Fi network continue to use your dishwasher as via WPS rather than with the Miele app, usual. However, Miele recommends in- the appliances are not automatically stalling updates.
Page 48 - Do not turn the dishwasher off during the update. Otherwise, the update will be aborted and will not be in- stalled. - Some software updates can only be carried out by Miele Customer Ser- vice.
Page 49 Settings Setting the electricity-rate times EcoStart Before you can use the option, EcoStart This option is not available in all areas. you must set at least one electricity-rate time. In order to run your dishwasher in the most economical way, you can use the ...
Page 50 Settings Changing the electricity-rate times Temperature You can change the start, finish, or prior- You can set whether the temperature ity of an electricity-rate time. should be displayed in °F/Fahrenheit or °C/Celsius.  Select an electricity rate time from R1–R3 to change. The factory default setting is °C/Celsius.
Page 51 Miele PowerDisks (if available), have been activated. you can turn off the refill reminders for reactivation salt and rinse aid if you Audible signals in the event of a fault wish.
Page 52 Settings AutoOpen 2nd interim rinse In some programs, the door automati- You can choose this function to increase cally opens slightly to assist the drying the cleaning performance of the pro- process. grams with a second interim rinse. This function can be deactivated if you When this function is activated, water wish.
Page 53 Settings Water connection System Lock  You can set your water connection type. The system lock prevents your dish- washer being used without your knowl-  If you select , the dish- Automatic edge. washer detects which water connec- tion is currently being used and auto- If an attempt is made to turn the dish- matically selects the right setting.
Page 54 The copyright powers of Miele and third tected by copyright. The copyrights held parties have to be respected. by Miele and third parties must be re- spected. Furthermore, this device/appliance con- tains software components which are...
Page 55 - Total consumption WiFi module settings (where applicable) - Fault memory have to be reset separately (see - Data plate “Miele@home” under “Settings”). - Software version  Select Reset settings?  Touch the  sensor control.  Select the option and confirm with OK.
Page 56 Caring for the environment Energy-saving dishwashing This dishwasher is exceptionally eco- nomical in its use of water and electric- ity. You can make the most of your machine by following these tips: - Washing in a dishwasher generally uses less water and energy than washing by hand.
Page 57 Loading the dishwasher - The spray arms must not be blocked General information by items which are too tall or hang Remove coarse food residues from dish- through the baskets. Test for free ware. movement by manually rotating the spray arms. There is no need to pre-rinse items un- der running water.
Page 58 Loading the dishwasher Wash items not suitable for dishwash- Silverware previously cleaned ers: with a silver polish may still be damp or spotted at the end of a program, where - Wooden cutlery and dishes or items water has not run off smoothly. with wooden parts.
Page 59 Loading the dishwasher Loading examples Loading for 10 standard place settings with cutlery tray Upper basket Lower basket Cutlery tray...
Page 60 Loading the dishwasher Loading for 16 standard place settings with cutlery tray Upper basket Lower basket Cutlery tray...
Page 61 Loading the dishwasher Loading the FlexCare cup rack Upper basket You can put cups, small bowls, and flat Loading the upper basket dishes on the FlexCare cup rack. Glasses can be arranged along the Flex-  Risk of damage due to water Care cup rack so they sit securely during leakage.
Page 62 Loading the dishwasher Adjusting the FlexCare cup rack Loading the silicone elements of the FlexCare cup rack You can set the height and depth of the cup rack at 2 different levels so that it The silicone elements in the cup rack can accommodate larger cups and so are specially designed to hold tall that taller items can be placed under-...
Page 63 Loading the dishwasher Lowering the spikes On both right-hand rows of spikes, you can lower every other spike to make it easier to arrange larger dishes, like ce- real bowls.  Press the yellow lever downward , and then lower the dark gray spikes .
Page 64 Loading the dishwasher Lower the upper basket: Adjusting the upper basket In order to gain more space for taller items in the lower basket or upper bas- ket, the upper basket can be adjusted on 3 levels with 3/4" (2 cm) between each level.
Page 65 Loading the dishwasher Lowering the spikes Lower basket The rows of spikes at the front are used Loading the lower basket for loading plates, soup bowls, platters,  Place larger and heavier items such as dessert bowls, and saucers. plates, serving platters, saucepans, The row of spikes can be lowered to bowls, etc., in the lower basket.
Page 66 Loading the dishwasher FlexCare Glass & Bottle Loading the glass holder The glass and bottle holders are used to The silicone elements in the glass wash stemware, tall glasses, and bot- holder provide a stable and secure hold tles. for delicate stemware. Adjusting the FlexCare Glass &...
Page 67 Loading the dishwasher Loading the FlexCare Glass & Bottle The glass and bottle holders can be used to keep tall, narrow, and hollow containers, e.g., beer glasses, bottles, vases, secure during a program.  Lean the containers into the holders. Tip: For the best cleaning results, use the “BottleClean”...
Page 68 Loading the dishwasher MultiClip The MultiClips enable you to fasten light wash items such as those made from plastic.  Slightly lift the XL-Assist , fold it out , and hook it back in the new position .  Secure light items to the MultiClips. Make sure that dishware does not obstruct the middle spray arm.
Page 69 Loading the dishwasher StrawClean Loading the StrawClean The drinking straw holder can accom- modate 5 straight or bent straws with a maximum outer diameter of 1/2" (12 mm). Straws with a length of 4"-10" (10– 25 cm) are held particularly securely. The best cleaning results will be ob- tained with straws made of glass or plastic with an inner diameter of more than 1/4"...
Page 70 Loading the dishwasher Adjusting the StrawClean Removing the StrawClean The adjustable bracket of the Straw- You can remove the StrawClean to get Clean ensures that the straws are held more space in the lower basket. securely. Longer straws are held particu- larly securely.
Page 71 Loading the dishwasher Loading the filters Filters You can wash 2 ventilation hood filters You can also wash Miele Ventilation- in the upper basket and 2 filters in the Hood Filters. lower basket at once. Select the program for optimum Filters  If you only want to wash 2 filters, put dishwashing results.
Page 72 Loading the dishwasher You can push the left insert to the mid- Cutlery tray dle in order to accommodate tall items  Arrange the cutlery in the cutlery tray and long stemmed glasses in the upper as shown. basket (see “Loading the silicone ele- ments of the FlexCare cup rack”...
Page 73 Detergents There are different types of cleaning Active ingredients agent:  Damage caused by using unsuit- - Powder and liquid gel cleaning able cleaning agents. agents. These cleaning agents allow Cleaning agents that are not suitable you to adjust the amount dispensed for domestic dishwashers can cause according to the load size and the damage to the dishwasher or to the...
Page 74 Detergents Detergent dispensing  Risk of chemical burns from de- tergent. There are 2 ways of dispensing the de- tergent. Dishwasher detergents can cause burning on the skin and in the eyes, During automatic dispensing, the Auto- nose, mouth, and throat. Dos function will automatically dispense Avoid contact with detergents.
Page 75  Insert a PowerDisk (see “Inserting a pending on the chosen program. PowerDisk” under “Automatic dis- pensing/AutoDos”). PowerDisks are available to order di- rectly from Miele’s online store, Miele The AutoDos function will be activated Customer Service, or from your Miele automatically. dealer.
Page 76 Detergents Inserting a PowerDisk Only replace the PowerDisk when the message PowerDisk empty. Deactivate appears. AutoDos with OK.  Insert the new PowerDisk and press it evenly downward until it sits flush.  Turn the AutoDos lid to  and open The message will ap- AutoDos lid open...
Page 77 Detergents The detergent powder must be dry so that it does not clump together. Do not fill the AutoDos system with any type of fluid. It is not permitted to refill the Pow- erDisk with powder detergent. This will invalidate the warranty. In order to ensure that the AutoDos function works at its best, check it each time you replace the PowerDisk...
Page 78 Detergents Adding detergent Manual detergent dispensing Detergent must be manually dispensed if you have deactivated AutoDos in a program's Options menu. Detergent dispensing The detergent compartment holds a maximum of 3 1/2" tablespoons. There are marks in the detergent com- partment to aid with dispensing: 1 1/4, 2 tablespoons (20, 30 ml).
Page 79 Detergents The detergent must not cause the detergent compartment lid to get stuck. This can prevent the lid from opening during the program se- quence. Do not overfill the detergent com- partment.  If you wish, deactivate automatic dis- pensing/AutoDos. ...
Page 80 Back sensor button to return to the Pro- grams menu. If you want to control the dishwasher remotely using the Miele app (depend- ing on model), you will first need to acti- vate the Remote start option (see “Acti- vate Remote start” under “Options”).
Page 81 Operation Display of program duration Starting a program The estimated duration of the selected  Touch the Start sensor control. program appears on the display before If necessary, confirm the previously the program begins. During the program displayed message with OK. sequence, the time left until the end of The program starts and the message the program and the current program...
Page 82 Operation End of the program Energy management The audible signal might sound at the To save energy, the dishwasher will turn end of the program. off automatically 10 minutes after the last time a sensor button is pressed or The program has ended when the dis- after the end of a program.
Page 83 Operation Turning off the dishwasher Unloading the dishwasher  The dishwasher can be turned off at Dishes tend to break and chip more any time using the  sensor control. easily when they are hot. Allow the dishes to cool until they are comfortable Turning the dishwasher off during a pro- enough to handle before unloading gram stops the program.
Page 84 Operation Interrupting a program Canceling or changing a pro- gram A program will be interrupted as soon as the door is opened. If a program is canceled, important If the door is closed again, the program program stages may be missed. will continue from the point it was at be- A program should only be canceled in fore the door was opened.
Page 85 (see “Safety To turn the display back on for a few lock” under “Before using for the first minutes, press the  sensor control. time”). You can also activate a timer via the Miele app.
Page 86 Options Setting “Start at” Setting EcoStart With the function, you set the function enables you to Start at EcoStart exact time at which you want the pro- benefit from cheaper electricity rates at gram to start. night. Before you can use this option, you need to set up to 3 electricity-rate ...
Page 87 Settings timer. Timer  menu will no longer show the function but will instead show EcoStart Deleting the timer (see “Miele@home” under SmartStart  Select the option and confirm Delete “Settings”). with If your energy provider offers this ser-...
Page 88 You can start your dishwasher remotely the  sensor control. The option will using the Miele app. To do this, you first also remain active if you switch the need to install the app on your mobile...
Page 89 Options Operating hours display You can display how many hours the dishwasher has been in operation so far.  Turn the dishwasher on using the  sensor control.  If necessary, confirm the messages and refill reminders with OK.  Use the Back sensor control to switch from the Programs menu to the main menu.
Page 90 Program overview Program When to use Program sequence Pre- Main Interim Final Drying rinse wash rinse rinse °F/°C °F/°C Program for regular use to completely  122–  133–  Normal wash a full load of normally soiled dish- 167/50 149/56 ware with the ability to adjust energy and –75...
Page 91 Program overview Consumption Duration Energy Water Cold water Hot water Gallons/Liters Cold water Hot water 50°F/10°C 120°F/49°C 50°F/10°C 120°F/49°C h:min h:min 0.97 1.05 3.2/12.1 3:01 2:43 1.40 1.55 3.4/13.0 3:29 3:11 0.85 1.05 3.3/12.5 2:51 2:25 1.00 1.10 2.8/10.5 1:18 0:58 1.45 1.55...
Page 92 Energy The water intake temperature must be      Saver 115°F (45°C) for light to normally soiled dishware. Filter Wash program for cleaning Miele ventila-  167/75  131–  tion hood filters. 158/55 –70...
Page 93 Program overview Consumption Duration Energy Water Cold water Hot water Gallons/Liters Cold water Hot water 50°F/10°C 120°F/49°C 50°F/10°C 120°F/49°C h:min h:min 0.01 0.20 1.1/4.0 0:21 0:21 0.95 1.15 2.4/9.0 4:16 3:58 0.60 0.80 2.1/8.0 3:28 3:18 0.05 7.1/27.0 2:47 1.55 1.70 3.3/12.5 3:51...
Page 94 Program overview Program When to use Program sequence Pre- Main Interim Final Drying rinse wash rinse rinse °F/°C °F/°C Clean Special cleaning program to remove 167/75  158/70  Machine grease deposits from the dishwasher. Sensor- Program for dried-on residue and non- 113–...
Page 95 Program overview Consumption Duration Energy Water Cold water Hot water Gallons/Liters Cold water Hot water 50°F/10°C 120°F/49°C 50°F/10°C 120°F/49°C h:min h:min 1.75 2.00 5.0/19.0 2:37 2:07 3, 4 3, 4 3, 4 2:28–3:45 2:16–3:27 0.85–1.15 0.90–1.30 1.7–3.2/6.5–12.0 1.10 1.25 3.6/13.5 2:49 2:27 0.85...
Page 96 Options The time by which the program cycle Selecting Extras time is shortened varies according to You can use options to adjust the pro- the selected program. grams. In order to achieve optimum wash re- To do this, you can select or deselect sults, the temperature, and therefore the options in the Options menu of a the energy consumption, will slightly in-...
Page 97 Options AutoDos Extra Clean The AutoDos extra can be used to You can select this option to increase switch automatic dispensing on or off the cleaning performance of the pro- (see “Automatic dispensing” under “De- grams. tergent”). When this extra is activated, the pro- The setting applies to all programs.
Page 98 (see “Clean Machine” under “Optional acces- sories”). Follow the dosage recom- mended by the manufacturer on the packaging. Miele cleaning and care products are available to order from Miele’s online store.  Clean the filters in the wash cabinet regularly.
Page 99 Cleaning and care Hygiene cycle Cleaning the door and the door seal The frequent use of low-temperature wash programs increases the risk of The door seal and the sides of the dish- bacteria and odors inside the wash cabi- washer door are not accessed and net.
Page 100 Cleaning and care To avoid damaging the external sur- Cleaning the appliance front faces, do not use the following:  Damage due to soiling. - cleaning agents containing soda, am- Soiling that is left too long might be- monia, acids, or chloride come impossible to remove and - cleaning agents containing lime scale could cause the external surfaces to...
Page 101 Cleaning and care  Turn the AutoDos lid to  and open Cleaning the AutoDos assembly If the message is dis- Clean AutoDos  Remove the PowerDisk if appropriate. played, check that the AutoDos is clean, and clean it if necessary, e.g., powder residues.
Page 102 Cleaning and care The AutoDos lid must close tightly so that the detergent powder does not get wet and clump together. Make sure that all seals are clean and clean them if necessary.  Insert a filled PowerDisk and press it evenly downward until it sits flush.
Page 103 Cleaning and care Removing the cutlery tray (if present) Cleaning the spray arms In order to be able to remove the upper Particles of food can get stuck in the spray arm, you first have to remove the spray arm jets and bearings. The spray cutlery tray (if present).
Page 104 Cleaning and care Removing the upper spray arm Removing the lower spray arm  Remove the lower basket.  Push the upper spray arm upward  to engage the inner ratchet. Then un-  Rotate the screw thread of the lower screw the spray arm by rotating the spray arm counterclockwise ...
Page 105 Cleaning and care Cleaning the spray arms Inserting the upper spray arm  Reinstall the upper spray arm and tighten it by hand. Inserting the middle spray arm  Use a pointed object to push food particles that are stuck in the spray arm jets into the spray arm.
Page 106 Cleaning and care Inserting the lower spray arm Inserting the cutlery tray (if present)  Reinstall the lower spray arm and en-  Slide the cutlery tray back onto the sure that the filter combination lies rails from the front. flat in the base of the wash cabinet.
Page 107 Cleaning and care Checking the filters in the wash Cleaning the filters cabinet  Turn off the dishwasher. The filter combination in the base of the  Remove the lower spray arm (see wash cabinet retains coarse soil from “Cleaning the spray arms” under the suds solution.
Page 108 Cleaning and care  In order to clean the inside of the fil-  Rotate the screw thread clockwise ter, pull the microfilter on the plastic until the arrow in the viewing window ring downwards and away from the points to the lock symbol . filter combination.
Page 109 Cleaning and care Cleaning the drain pump If water remains in the wash cabinet af- ter the end of a program, the water has not been drained off. The drain pump may be blocked by foreign objects. These foreign objects are easy to re- move.
Page 110 Cleaning and care  Damage due to incorrect clean- ing. The components are delicate and can be damaged during cleaning. Take care when cleaning the drain pump. The drain pump (see arrow) is under- neath the cover.  Risk of injury from glass splinters. It is especially difficult to see glass splinters in the drain pump.
Page 111 You can save time and money in many cases, as you do not need to contact Miele Customer Service. Information to help you rectify faults yourself can be found at www.miele.com/ser- vice. The following tables are designed to help you to find the cause of a malfunction or a fault and to resolve it.
Page 112 If the fault message appears again, there is a techni- additional details. cal fault.  Turn off the dishwasher.  Close the faucet.  Contact Miele Customer Service. The Waterproof system has reacted.  Waterproof fault Turn the appliance off, close the ...
Page 113 “Before using for the first time”) and turn the additional details. dishwasher back on again.  If the same fault message appears again, contact Miele Customer Service. The door does not close automatically. The door might be obstructed by an item inside the appliance.
Page 114 Frequently asked questions Water intake fault Problem Possible cause and solution The alarm tone is sound- ing. One of the following messages appears in the display:  The water supply is turned off. Open the water supply  Open the water supply all the way. Before remedying the fault:  ...
Page 115 Frequently asked questions Water drainage fault Problem Possible cause and solution The alarm tone is sound- Before remedying the fault: ing.  Turn off the dishwasher. The following message Water-drainage fault. appears on the display: There might be water in the wash cabinet.  ...
Page 116 PowerDisk” under “Detergent”). The following message  If the same fault message appears again, contact appears on the display: Miele Customer Service. AutoDos lid open The following message The AutoDos function is active and the PowerDisk is appears on the display: empty.
Page 117 (see “Manual detergent dispensing” under “De- tergent”).  If you wish to use AutoDos again, contact Miele Customer Service. At the end of the pro- No or an empty PowerDisk has been inserted or the gram, the alarm tone AutoDos is blocked by residual detergent.
Page 118 Frequently asked questions Spray arm fault Problem Possible cause and solution During the program and The lower spray arm is blocked or the jets of the at the end of the pro- lower spray arm are clogged. The AutoDos detergent gram, the display shows outlet may not be completely flushed out.
Page 119  Turn the lighting back on again (see “BrilliantLight” opened. under “Settings”). Faulty wash cabinet lighting.  Contact Miele Customer Service. Detergent residue is left The detergent compartment was still damp when de- in the detergent com- tergent was added.
Page 120 Frequently asked questions Problem Possible cause and solution Build-up of odors in the The frequent use of low-temperature wash programs wash cabinet (< 122°F/50°C) increases the risk of contamination and odors inside the wash cabinet.  Regularly run a high-temperature program. This is to prevent contamination and odors.
Page 121 Frequently asked questions Noises Problem Possible cause and solution There is a knocking A spray arm is knocking against a wash item. noise in the wash cabi-  Carefully open the door and rearrange the wash net. items that are obstructing the spray arm. There is a rattling noise Wash items are not secure in the wash cabinet.
Page 122 Frequently asked questions Poor cleaning results Problem Possible cause and solution The dishware is not The dishware was not loaded correctly. clean.  See notes under “Loading the dishwasher”. The program was not powerful enough.  Select a more powerful program (see “Program overview”).
Page 123 Frequently asked questions Problem Possible cause and solution The dishware is not dry The rinse-aid dosage is set too low or the rinse-aid or utensils and glasses reservoir is empty. are flecked.  Replenish the reservoir, increase the dosage, or change the brand of rinse aid (see “Rinse aid”...
Page 124 Frequently asked questions Problem Possible cause and solution  Fill the salt reservoir (see “Reactivation salt” under “Before using for the first time”). The salt-reservoir cap has not been screwed on cor- rectly.  Replace it, making sure that it screws back on cor- rectly.
Page 125 Frequently asked questions Problem Possible cause and solution There are rust stains on The affected items are not corrosion resistant. the cutlery.  No remedy. Purchase cutlery which is dishwasher-safe. A program was not run after reactivation salt was added. Traces of salt have got into the normal wash cycle.
Page 126 In the event of a fault which you cannot remedy yourself, please contact your Miele dealer or Miele Customer Service. You can book a Miele Service Call on- line at www.miele.com/service. Contact information for Miele Cus- tomer Service can be found at the end of this document.
Page 127 Miele appliances. protection additives These and many other useful products - Phosphate-free – kind to the environ- can be ordered directly from Miele’s on- ment line store, Miele Customer Service, or from your Miele dealer. - Water-soluble wrapping – no need to...
Page 128 Optional accessories Appliance care Miele cleaning and care products pro- vide optimum care for your dishwasher. Dishwasher cleaner - For use with the pro- Clean Machine gram without detergent dispensing - Cleans the dishwasher effectively and thoroughly - Removes grease, bacteria, and asso-...
Page 129 A 5 ft (1.5 m) long, flexible metal exten- sion hose (tested to 2,030 psi (14,000 kPa/140 bar) is available as an optional accessory from Miele dealers or Miele Customer Service.
Page 130 *INSTALLATION* Installation The dishwasher is supplied with a 3/8"  Risk of damage due to excessive diameter inlet (with a UNEF 9/16" – 24 pressure. female threaded nut) and requires an A brief increase in the water pressure on-site water connection with 3/8" can damage components of the dish- compression fitting and shut-off valve.
Page 131 Other- wise, the drain hose can become clogged. Only use a Miele approved connection piece when extending the drain line. Only use a Miele extension drain hose. The drain hose must not be shortened.
Page 132 *INSTALLATION* Installation Venting the water drain If the on-site drainage connection is sit- uated lower than the guide path for the lower basket rollers in the open door, the drainage system must be vented. Otherwise, a siphoning effect during a program can cause the wash cabinet to empty itself of water.
Page 133 Customer Service Department: USA: 1-888-99-MIELE(64353) A damaged power cord must only be CDN: 1-800-565-6435 replaced with a genuine Miele cord by a Miele service technician. Specifications The dishwasher comes equipped with a Grounding instructions 4 ft (1.2 m) power cord (measured from...
Page 134 *INSTALLATION* Installation Hardwired electrical connection  Prior to making a hardwire con- It is possible to hardwire this appliance nection to the terminal, remove the to an existing power cable. powercord. Otherwise there will be a risk of electric shock from the at- ...
Page 135 Sound emission testing Prerequisites for sound emission tests Load the dishwasher with 16 standard place settings and use the Normal pro- gram. Setup for sound emission tests The dishwasher must be set up according to the following specifications.  Install the dishwasher into an analyzing unit. ...
Page 136 Sound emission testing  Remove the protective film from the provided insulating strip (depending on model) .  Stick the insulating strip onto the front top edge of the toe-kick board .
Page 139 Customer Service. U.S.A. Canada Miele, Inc. Importer Miele Limited National Headquarters Headquarters and Miele Centre 9 Independence Way 161 Four Valley Drive Princeton, NJ 08540 www.mieleusa.com Vaughan, ON L4K 4V8 www.miele.ca Customer Support Phone: 888-99-MIELE (64353) Customer Care Centre info@mieleusa.com...
Page 140 G 7936 en-US M.-Nr. 12 515 390 / 02...
