User Guide

Lenovo ThinkBook 14 Gen 8 and Lenovo ThinkBook 16 Gen 8

Need help?

Do you have a question about the ThinkBook 14 G8 IAL and is the answer not in the manual?

Questions and answers

Summary of Contents for Lenovo ThinkBook 14 G8 IAL

Page 1 User Guide Lenovo ThinkBook 14 Gen 8 and Lenovo ThinkBook 16 Gen 8...
Page 2 • Setup Guide First Edition (November 2024) © Copyright Lenovo 2024. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
Page 3 Antennas ....2 Unique Lenovo apps ... . . Base ....3 Lenovo Vantage .
Page 4 Change or remove administrator password . . Call Lenovo ....Set user password ... .
Page 5 About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) ThinkBook 14 G8 IAL 21SJ ThinkBook 14 G8 IRL ThinkBook 14 G8 IRL 1...
Page 6 User Guide...
Page 7 Microphones are essential components when you use your PC for video conferencing or voice recording. Infrared LED The infrared LED generates and emits near-infrared waves that are received and used by a camera (or a dedicated infrared camera) for facial recognition. © Copyright Lenovo 2024...
Page 8 Camera shutter The camera shutter is a sliding cap that you can move to block the camera lens. Note: The camera shutter is designed for privacy protection. When the camera lens is blocked, the camera function is disabled. Camera The built-in camera captures visible light and converts it to digital signals. It is used for video recording and video conferencing.
Page 9 Base Figure 1. 14-inch models Figure 2. 16-inch models Description Power light Power button / Fingerprint sensor* Keyboard Touchpad * for selected models Chapter 1 Meet your computer...
Page 10 PC, go to Settings ➙ Accounts ➙ Sign-in options to enroll your fingerprints. Keyboard The keyboard is the primary input device for a PC, designed for typing characters. A Lenovo keyboard also includes shortcut keys that enhance productivity when interacting with the PC, applications, and the Windows operating system.
Page 11 Left Figure 3. IAL and IRL models Figure 4. AHP models Description ® Multi-purpose USB Type-C connector Charging light USB Standard-A connector (always-on connector) ™ HDMI connector Multi-purpose USB Type-C connector Combo audio jack Status light Multi-purpose USB Type-C connector Multi-purpose USB Type-C connector ®...
Page 12 The always-on function can be turned on and off in: • The PC's firmware setup utility, or • Lenovo Vantage or Lenovo PC Manager HDMI connector The HDMI connector is used to connect an external display device, such as a television, a projector, or a monitor.
Page 13 State light The state light indicates the current power state of the PC: whether it is powered on, powered off, in sleep mode, or in hibernation mode. When the PC is powered on, this light can also indicate low battery by blinking rapidly. Note: The status of the state light is synchronized with that of the power light.
Page 14 Right Description SD card slot USB Standard-A connector Ethernet connector Security-lock slot SD card slot The SD card slot is used to insert an SD, SDHC, or SDXC memory card to transfer data between the memory card and your PC. USB Standard-A connector The USB Standard-A connector is used to connect storage or peripheral devices that follow the universal serial bus (USB) specification for data transfer and device interconnection.
Page 15 Bottom Description Air vents (intake) Speakers Novo button hole Air vents (intake) The air vents allow air to be sucked inside of the PC to cool the internal components. Important: When the PC is operating, do not place it on a bed, sofa, carpet, or other flexible surfaces. Otherwise, the air vents will be blocked and the PC may overheat, reducing performance or causing the PC to be unresponsive or even shut down.
Page 16 Features and specifications Dimensions Width • 14-inch models: 313.5 mm (12.3 inches) • 16-inch models: 356 mm (14 inches) Depth • 14-inch models: 224 mm (8.8 inches) • 16-inch models: 253.5 mm (10.0 inches) Thickness • Metal: – Thinnest: 16.9 mm (0.67 inches) –...
Page 17 Mass storage device Type Solid-state drive Form factor M.2 (2242/2280) Interface PCIe Gen 4 × 4 Screen Size • 14-inch models: 355.6 mm (14 inches) • 16-inch models: 406.4 mm (16 inches) Display resolution • 14-inch models: – 1920 × 1200 pixels (WUXGA model), or –...
Page 18 Memory card slot Supported card types: • SD card • SDHC card • SDXC card ™ Security lock slot Kensington Nano Security Slot USB Standard-A connector • Quantity: 2 • Maximum power output: – 5 V, 0.9 A – 5 V, 1.5 A (for always-on connector) •...
Page 19 Network Ethernet 1 Gbps Wi-Fi • Wi-Fi 6, or • Wi-Fi 6E Bluetooth • Bluetooth 5.2, or • Bluetooth 5.3 * for selected models Statement on USB transfer rate Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual transfer rate using the various USB connectors on this device will vary and will be slower than the data rate listed below for each corresponding device.
Page 20 over 10s at a time. As such, it is recommended that users avoid prolonged direct contact with the bottom of the computer. User Guide...
Page 21 Table 5. Windows recovery options Recovery options Situations Windows runs much slower Restore Windows from a system restore point. after you install an app. Windows hasn't been Reset your PC while keeping your personal files. functioning properly for some time. © Copyright Lenovo 2024...
Page 22 Step 1. Shut down your PC. Step 2. Connect the recovery drive to your PC. Step 3. Press the Novo button or the Lenovo Smart Key to open the Novo button menu. Step 4. Select Boot Menu. Step 5. Select the USB drive as the boot device.
Page 23 In Windows Update, you can view available updates, manually check for updates, and configure settings related to updates. To navigate to Windows Update, select Settings ➙ Windows Update. Use power efficiently As an electronic device, your PC requires electricity to operate. The Windows operating system provides advanced power management features for the devices within your PC.
Page 24 Plug the other end of the Ethernet cable into a network wall jack or a router. Note: If your computer does not include an Ethernet connector, you can purchase a USB-C to Ethernet adapter from Lenovo at https://www.lenovo.com/accessories Connect to a Wi-Fi network Ensure that you have a secure Wi-Fi network account and the required credentials.
Page 25 Lenovo Vantage Lenovo Vantage is a one-stop solution to help you update your computer, configure hardware settings, and access personalized support. If your computer is pre-installed with Lenovo Vantage, type Vantage in the Windows search box to launch this app. Notes: •...
Page 26 Start your computer using a recovery drive Reset your computer Open the advanced options screen Open the Novo Button menu For Lenovo computers with a Novo button, you can press the button to open the Novo Button menu. Step 1. Turn off the computer. Step 2.
Page 27 Figure 5. Locations of the fn lock key and the fn key A Lenovo keyboard usually contains hotkeys in the top row. These hotkeys share keys with the function keys (F1–F12) and other keys. For these dual-function keys, the icons or characters denoting the primary functions are printed on top of the icons and characters denoting the secondary functions.
Page 28 Primary function The Copilot key The era of AI has arrived, and many Lenovo PCs now include a Copilot key on the keyboard. It is located either in the bottom or the top row of the keyboard and is marked with For Windows PCs with Copilot in Windows available and enabled, pressing the Copilot key opens Copilot in Windows.
Page 29 Takes a full-screen screenshot and saves it to a file Numeric keypad (for selected models) Some Lenovo computers include a dedicated numeric keypad on the far right of the keyboard. The keypad is used for entering numbers and operators quickly.
Page 30 Touchpad gestures The Windows operating system supports multi-finger gestures on the touchpad, enhancing productivity while interacting with the operating system. Table 11. Multi-finger touchpad gestures Number of fingers to use Gesture Function Swipe vertically Scrolls pages Pinch in or stretch out Zooms out / Zooms in Displays the context menu (right- clicking)
Page 31 Touch operation Used for Opening the context menu Tap, hold, and lift Zooming out Pinch Zooming in Spread Opening the widgets panel Swipe in from the left edge Opening the notification center Swipe in from the right edge The Windows operating system also supports 3- and 4-finger gestures on the screen and the touchpad. You can set them up in Settings ➙...
Page 32 Connect to a wireless display Ensure that: ® • Both your computer and the display support Miracast technology. • The display is connected to the same Wi-Fi network as your computer and is discoverable. Step 1. Press Windows key + K. The computer searches for wireless display devices and audio devices and lists the results.
Page 33 Step 3. Move the slider to adjust the color temperature. Note: Selected Lenovo PCs are low blue-light certified. These PCs undergo testing with the night light turned on and the color temperature value set at 48 or above. Chapter 2...
Page 34 User Guide...
Page 35 Intelligent features Your computer may be pre-installed with one of Lenovo Vantage or Lenovo PC Manager but not both. Most features described here can be enabled or disabled in one of these apps. Other features may be enabled in a standalone app.
Page 36 Notes: • Depending on its hardware, your computer may not support all the functions and options described above. • You can view and customize this feature under Device Settings in Lenovo Vantage or Lenovo PC Manager. Manage power Use the information in this section to achieve the best balance between performance and power efficiency.
Page 37 If the battery pack of your computer supports overnight charge optimization, it can be enabled in Lenovo Vantage or Lenovo PC Manager.
Page 38 You can switch the operation mode in the pre-installed app Lenovo Vantage, Lenovo Smart Engine, or Lenovo PC Manager. As a shortcut, you can also use the key combination Fn + Q. Three modes are usually available for most Lenovo computers. The following table lists the operation modes and the recommended conditions for each mode.
Page 39 If your organization mandates a specific data erasure standard, you may want to consider using Lenovo Secure Wipe. Lenovo Secure Wipe is initiated within the firmware setup utility. It can erase both built-in and external storage devices and supports widely recognized data erasure standards. Unless you have specifically selected only data partitions for erasure, the boot and system partitions will be overwritten, rendering the device unbootable after the data erasure process.
Page 40 Administrator password must be set for the firmware setup utility prior to using Lenovo Secure Wipe. Some Lenovo PCs include a utility called Lenovo Secure Wipe. Before selling or donating a Lenovo PC, you can use this software utility to overwrite or block erase the PC's built-in storage device.
Page 41 Open the UEFI/BIOS setup utility Step 1. Turn on or restart the computer. Step 2. When the Lenovo logo appears on the screen, press F1 repeatedly. Or enter Novo Button menu. Step 3. Select UEFI/BIOS Setup. Select boot devices Normally, the computer starts with a boot manager loaded from the secondary storage device of the computer.
Page 42 Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service.
Page 43 Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service.
Page 44 Step 3. Follow on-screen instructions to set both master and user hard disk passwords. Note: The master and user hard disk passwords must be set at the same time. Select Exit ➙ Exit Saving Changes. Step 4. If the hard disk password is set, you must provide the correct password to start the operating system. Change or remove hard disk password Step 1.
Page 45 Do not try to drain out the liquid by turning over the computer. If your computer has keyboard drainage holes on the bottom, the liquid will be drained out through the holes. Where can I get the latest device drivers and UEFI/BIOS? • Lenovo Vantage or Lenovo PC Manager • Lenovo Support Web site at https://support.lenovo.com I pressed the Copilot key on my keyboard, but neither Copilot in Windows nor Windows Search opened.
Page 46 • Use Windows Search. Windows help information • Microsoft Support Web site: https:// support.microsoft.com What is a CRU? Customer replaceable units (CRUs) are parts that can be replaced by the customer. A Lenovo computer may contain the following types of CRUs: User Guide...
Page 47 If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When a return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;...
Page 48 Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Record product information and problem details before you contact Lenovo. Product information Problem symptoms and details •...
Page 49 Purchase additional services During and after the warranty period, you can purchase additional services from Lenovo at https:// pcsupport.lenovo.com/warrantyupgrade Service availability and service name might vary by country or region. Chapter 4 Help and support...
Page 50 User Guide...
Page 51 Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
Page 52 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
