ACM Mondella QKGA016M Owner's Manual

1/2 hp high torque garbage disposer

Table of Contents

Quick Links

Download this manual

1/2 HP

HIGH TORQUE GARBAGE DISPOSER

NOTE: This product may require approval of the relevant regulators and/or the sewerage system operator. Waste disposal must be installed according

to AS/NZS 3500.2 requirements. This waste disposer is intended exclusively for home use.

220-240V AC / 50/60Hz / 1.85 A / 375W

OWNER'S MANUAL

Rev. 20220214

Model: QKGA016M

Table of Contents

Need help?

Do you have a question about the Mondella QKGA016M and is the answer not in the manual?

Questions and answers

Summary of Contents for ACM Mondella QKGA016M

Page 1 1/2 HP HIGH TORQUE GARBAGE DISPOSER NOTE: This product may require approval of the relevant regulators and/or the sewerage system operator. Waste disposal must be installed according to AS/NZS 3500.2 requirements. This waste disposer is intended exclusively for home use. 220-240V AC / 50/60Hz / 1.85 A / 375W OWNER’S MANUAL Rev.
Page 2: Table Of Contents
Table of Contents Installation of the Mounting Assembly . . . . . . . . . . . . . . . . . .6 Table of Contents .
Page 3: Warranty
. ACM Pty Limited warrants this product to be free from defects in materials or workmanship for Ten (10) years from the date of purchase . Proof of purchase (original sales receipt) from the original consumer purchaser must be made available to ACM Pty Limited for all warranty claims .
Page 4: Pre-Installation
Pre-Installation TOOLS/MATERIALS REQUIRED (NOT SUPPLIED) Pipe wrench Phillips screwdriver Flat screwdriver Electric drill with 1-1/4”(32mm) hole Plumber’s putty PACKAGE CONTENTS Stopper Splash Guard Sink Flange Gasket Flange Ring Ring Tool Supporting Plate Top Supporting Ring (with 3 screws) Cushion Mount Bottom Supporting Ring Part Description Quantity...
Page 5: Installation
Installation REMOVAL OF OLD UNIT CAUTION: Risk of electric shock . Turn off electric power at fuse box or circuit breaker before removing old unit . General instructions - your model may vary . NOTE: CAUTION: Be sure to support the disposer when removing the mounting ring or it may fall .
Page 6: Installation Of The Mounting Assembly
Installation (continued) INSTALLATION OF MOUNTING ASSEMBLY NOTE: Top supporting ring Top supporting ring screw Pay close attention how the parts come assembled, as they have been correctly assembled by the factory (see Fig. 5). Fig. 5a This food waste disposer has been designed to operate on 220-240V AC, 50/60 Hz electrical circuit.
Page 7: Attaching Discharge Elbow
Installation (continued) If at any time the bottom supporting ring becomes disengaged Slot from the body of the waste disposer, then: 1 . Align the slot in the bottom supporting ring with tab on the waste disposer body . 2 . Lower the bottom supporting ring and make the slot fit in the tab .
Page 8: Connecting Disposer To Mounting Assembly
Installation (continued) CONNECTING THE DISPOSER TO THE MOUNTING ASSEMBLY Fig. 11 Elbow Trap - Adjust the disposer position to make the elbow line up with the trap (see Fig . 11) . Disposer body - The disposer must be installed so that the reset button is Reset Button readily accessible (see Fig .
Page 9: Dishwasher Connection
Installation (continued) Turn the bottom supporting ring 1/3 of a turn counter-clockwise Fig. 13c and repeat the mounting procedure described above (see Fig 13c) . - Connect the bottom of the elbow to the trap by tightening the slip nut (Fig . 14) . - Run water and check all connections for leaks .
Page 10: Operation
Operation TESTING AND OPERATION TIPS FOR SUCCESSFUL OPERATION - Remove sink stopper. Turn on a medium flow of cold water. - Turn switch to ON position; your motor is turning at full speed - Be sure disposer is empty before using your dishwasher so and ready to use .
Page 11: Troubleshooting
Troubleshooting Before seeking repair or replacement, we recommend that you review the following: Problem Solution The disposer is making loud noises . Other than the noises during grinding of small bones and fruit pits, these are usually caused by accidental entry of a spoon, bottle cap or other foreign objects .
Page 12: Service Parts
Service Parts If you are missing parts or if you require replacement parts, please contact our customer service team at 0800 744 794 (Service available Monday - Friday from 8:00 am - 4:30 pm NZDT) . Identify the required part(s) and have the part number(s) ready . Stopper Splash Guard Sink Flange...
Page 13 ACM Pty Limited 47 Stonedon Drive, East Tamaki, Auckland 2013 New Zealand www.acmptyltd.com Customer Service Hotline Telephone : 0800 744 794 - 8.00am – 4.30pm Made in China...
