Summary of Contents for AEG TR818A2PB
- Page 1 EN User Manual | Tumble Dryer TR818A2PB aeg.com\register...
- Page 2 Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................8 4. TECHNICAL DATA..................9 5.
- Page 3 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
- Page 4 similar accommodation where such use does not exceed (average) domestic usage levels. • Do not change the specification of this appliance. • If the tumble dryer is put on top of a washing machine, use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory.
- Page 5 • WARNING: Do not damage the refrigerant circuit. • If the mains power supply cable is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard. • Do not exceed the maximum load of 8,0 kg (refer to the "Programme chart"...
- Page 6 2.3 Use The appliance contains flammable gas, propane (R290), a gas with a high level of environmental compatibility. Keep fire and WARNING! ignition sources away from the appliance. Risk of injury, electric shock, fire, burns Be careful not to cause damage to the or damage to the appliance.
- Page 7 of environmental compatibility. Keep fire and bundled together), tension pulley, support ignition sources away from the appliance. Be roller, doors, door seals, door handles, careful not to cause damage to the refrigerant door lock assemblies and hinges, lint circuit containing propane. filters, air filters, plastic peripherals, condensate tank.
- Page 8 Access your appliance details, documentation and articles on how to use the best features (User Manual also available at aeg.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at aeg.com/ support ) • Buy accessories, Consumable and Original Spare parts for you appliance (also available at aeg.com/ shop ) ENGLISH...
- Page 9 3.1 Electrical connection The power supply cable must be easily accessible after installing the appliance. At the end of installation you can connect the For any electrical work required to install this mains plug to the mains socket. appliance, contact our Authorised Service The rating plate and the 'Technical Data' Centre.
- Page 10 Weight 0,149 kg 5. CONTROL PANEL low power function Program dial On/Off button with Display Programs Inicio/Pausa button Options 5.1 Display Symbol on the display Symbol description cycle time indication maximum load ENGLISH...
- Page 11 Symbol on the display Symbol description delay start selection (30min-20h) Anti-arrugas/Rugas option on Silencioso option on buzzer off child lock on laundry dryness: iron dry, cupboard dry, extra dry Tiempo/Tempo sec. option on drain the water container indicator: clean the filter indicator: check the condenser indicator:...
- Page 12 Load 1) Properties / Fabric mark 2) Programas Recommended for generic delicate fabrics Delicados 2,0 kg such as viscose, rayon, acrylic and their blends. Gently dries for machine and hand-washable woollens. Re‐ move immediately the items when the programme is comple‐ ted.
- Page 13 Load 1) Properties / Fabric mark 2) Programas Dries and sanitizes your garments and oth‐ er items maintaining the temperature above 60°C over time, removing 99.9% of bacteria 3,0 kg Higienizar and viruses Note: This cycle should only be used for wet items.
- Page 14 7. OPTIONS 7.1 Nivel de Sec. 4. Touch the Inicio/Pausa button repeatedly until you reach the desired target final moisture . This option helps to achieve requested laundry dry‐ ness. You can select the level of dryness: Dryness level Display symbol ready to iron - iron dry level maximum dry‐...
- Page 15 7.7 Alarm. TIME DRYING RECOMMENDATION The acoustic signal sounds at the following: up 10 min action of cool air only (no heater). • cycle end • start and end of crease guard phase 10 - 40 additional drying to improve dryness af‐ The acoustic signal is by default always on.
- Page 16 the display shows the text Hr for 2 1. Switch the appliance on by pressing seconds then 12 for 2 seconds followed On/Off button. by 76. This value is displayed with a 2. Wait approximately 8 seconds. sequence of two digits at a time: the first 3.
- Page 17 Working pump and transferring condensation to the tank. 10. DAILY USE 10.1 Preparing the laundry • Remove all items from pockets. • Turn items with the internal layer made of cotton inside out. Cotton layer must be faced outwards. Loading the drum up to the maximum •...
- Page 18 Fabric label Description Laundry is not suitable for tumble drying. 10.2 Loading the laundry • After 5 minutes from the end of the programme or anticrease phase. CAUTION! Ensure the laundry is not trapped When the appliance goes in low power between the appliance door and the mode, the display and icons turn off.
- Page 19 10.8 Starting a program To activate or deactivate an option touch the relevant button or a two button combination. To start the program: Corresponding symbol on the display or the led above the button lights up. Touch the Inicio/Pausa button. The appliance starts and the LED above the 10.7 Child lock option button stops flashing and stays on.
- Page 20 4. Close the appliance door. Possible causes of unsatisfactory drying results: If you do not turn off the appliance, the anti-crease phase starts (not active with • Inadequate default dryness level settings. Adjustment of the target final See chapter all programmes). Flashing symbol moisture signals the execution of the anti-crease...
- Page 21 Cleaning the drum Every two months Cleaning the control panel and housing Every two months Cleaning the airflow slots Every two months The following paragraphs explain how you should clean each part. 12.2 Removing the foreign items Make sure that the pockets are empty and all loose elements are tied up before running the drying cycle.
- Page 22 2. Pull the plastic connection out and drain the water into a basin or equivalent receptacle. 3. Push the plastic connection back in and place the water container back into position. Throw the lint in the dustbin. 4. To continue the programme press the 4.
- Page 23 2. Open the condenser cover. 6. Close the condenser lid. 7. Turn the levers until it clicks into position. 8. Put the filter back. 12.6 Cleaning the humidity sensor CAUTION! Risk of humidity sensor damage. Do not use abrasive materials or steel wool to clean the sensor.
- Page 24 12.7 Cleaning the drum Use a moist cloth to clean. Dry the cleaned surfaces with a soft cloth. WARNING! CAUTION! Disconnect the appliance before you Do not use furniture cleaning agents or clean it. cleaning agents which can cause corrosion. Use a standard neutral soap detergent to clean the inner surface of the drum and drum 12.9 Cleaning the airflow slots...
- Page 25 Error code Possible cause Remedy The mains supply is unstable. When the appliance is showing EH0, please wait until main supply is stable than press start. If the appliance paused the cycle with‐ out any indication then press the cycle start. If the warning will occur again check the power cord / socket integrity or main supply.
- Page 26 Problem Possible cause Remedy It is not possible to The option you tried to select is not availa‐ Turn the tumble dryer off and on. Change select an option. An ble for the selected program. the program or option as required. acoustic signal is emitted.
- Page 27 14. CONSUMPTION VALUES 14.1 Introduction The user manual reports two different references for EU energy label and ecodesign regulations. • Reg. (EU) 932/2012 and Reg. (EU) 392/2012 valid up to 30 June 2025 is relate to the Energy efficiency classes from A+++ to D. •...
- Page 28 Initial Energy con‐ Target final Load Spun at mois‐ Drying time Programme sumption Moisture (kg) (rpm) ture (h:mm) (kWh) 1) 2) 1000 2:59 1,28 1) 2) 1000 2:00 0,72 This is the reference programme used to assess the compliance with EU ecodesign and Energy label regula‐ tions, Reg.
- Page 29 Initial Energy con‐ Target final Load Spun at mois‐ Drying time Programme sumption Moisture (kg) (rpm) ture (h:mm) (kWh) Lana/Lãs 1200 1:44 0,78 15. QUICK GUIDE 15.1 Daily use 1. Push the On/Off button to turn on the 4. Touch the Inicio/Pausa button. appliance.
- Page 30 3. Gather lint with hand from both internal filtro symbol At the end of each cycle the parts of the filter. Throw the lint in the comes on the display and you must clean the dustbin. filter. 1. Open the door. Pull the filter up. 2.
- Page 31 the household waste. Return the product to your local recycling facility or contact your municipal office. ENGLISH...
- Page 32 136206860-A-112024...
