HOMEDEPOT.COM THANK YOU We appreciate the trust and con dence you have placed in Glacier Bay through the purchase of this kitchen faucet. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Page 2
Glacier Bay products are manufactured with superior quality standards and workmanship and are backed by our limited lifetime warranty. Glacier Bay products are warranted to the original consumer purchaser to be free of defects in materials or workmanship. We will replace FREE OF CHARGE any product or parts that proves defective.
Page 3
Pre-Installation (continued) PACKAGE CONTENTS Sensor Control Box Soap Pump Assembly Part Description Quantity Part Description Quantity Faucet body Quick connect assembly Washer Sensor control box Battery pack Protective cap "AA" Battery Wrench Soap pump Escutcheon Soap assembly Gasket Soap dispenser Hose mounting nut Weight clip...
Page 4
Installation Preparing for installation CAUTION: Always shut off the water supply before removing an existing faucet or replacing any part of a faucet. Open the faucet handle to relieve water pressure and ensure that the water is completely shut off. □...
Page 5
Installation (continued) Securing the faucet assembly □ Install the washers (B) onto the threaded shank. □ Push the hose (H) up through the faucet body until the end of the hose is ush with the bottom on the shank (1) so it's out of the way for the next step. □...
Page 6
Installation (continued) Attaching the quick connector Installing the protective cap to the hose □ Screw the protective cap (D) onto the threaded □ Pull out the hose (H) from the threaded mounting shank (1). mounting shank (1). □ Attach the quick connector (K) by screwing it onto the threaded end of the hose (H) in a clockwise motion.
Page 7
Installation (continued) Installing the sensor cable NOTE: The side of the control box (L) with "in" and "out" showing must face the front of the cabinet (away from the back of the cabinet). □ Install the sensor cable (1) to the control box connection (2). Ensure the arrows on the sensor cable and control box connection are aligned to one another to ensure proper installation.
Page 8
Installation (continued) Attaching the quick connector to the receiving block □ Connect the hose with the yellow tag to the hose on the control box (L) with a matching yellow tag. Push rmly together until they snap into place. As shown in the Fig 1. □...
Page 9
Installation (continued) Installing the batteries NOTE: This step is for battery installation (optional). If the battery will not be used, install as described in step 10. □ To open the battery housing, squeeze the tabs (1) on the cover (2), then remove the cover (2). □...
Page 10
Installation (continued) Installation using the battery pack NOTE: This step is for battery installation (optional). If the battery will not be used, install as described in step 10. □ Drill a hole in the wall using a 6mm (15/64 in.) diamater drill bit. Install the battery pack (M) using the molly anchor (1) and screw (2) provided.
Page 11
Installation (continued) Installation using the AC adapter (not included) NOTE: This step is for installation without batteries using an AC adapter (not included). If using the batteries, install as instructed in step 8 and skip to step 11. The AC adapter is not included with the product, but can be purchased from Homedepot.com.
Page 12
Installation (continued) Installing the weight □ Install the weight clip (I) at the point of the hose (H) marking “weight here”. □ Insert the weight (J) onto the clip (I) by sliding it down onto the clip (I). Installing the soap dispenser □...
Page 13
Installation (continued) Making the water supply connections NOTE: The hot side inlet tube is indicated by a label. Avoid twisting wires together or placing the wires close to each other and damaging. □ Thread the nut (1) on the supply line onto the outlet of the water supply valve (2) and tighten with a wrench.
Page 14
Operation (continued) Operating the sensor min. NOTE: The sensor is active only when the handle is in the ON position. □ Turn the handle (1) away from the faucet to the full on position. Turn the water on by activating the sensor (2) by waving your hand within Cold 2-3/8 inches of the sensor.
Page 15
Troubleshooting Water will not shut off when The light on the sensor is turning the handle to the OFF flashing continuously position □ If the handle is closed, turn the handle to the □ on position and move your hand in the sensor When you turn the handle to the full on position, area.
Page 16
If the sensor window is clean, and still not functioning, this means the control box will need to be replaced. Call Glacier Bay customer service to request a replacement control box. Replace the old control box with the...
Page 17
Service Parts Faucet ID tags can be found on the hot water inlet Part Description Part Number Part Description Part Number Spray head and Hose RP38599* Quick connect RP70680 assembly Wearable ring RP70380 O-ring RP60071 O-ring RP60089 Cartridge RP20044 Weight clip RP70590 Bonnet nut RP70533...
Page 18
Questions, problems, missing parts? Before returning to the store, call Glacier Bay Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-GLACIER (1-855-434-5224) HOMEDEPOT.COM Retain this manual for future use.
