- Page 1 MOD : E9/4PQA8-N Production code : DIPQ98A 0 9 /2023...
- Page 2 INSTALLATION INSTRUCTIONS FOR THE USE OF THE SPECIALISED TECHNICIAN ELEKTRYCZNY ELECTRIC ELEKTRISCH ELECTRIQUE ELÉCTRICO...
- Page 3 GENERAL AND SAFETY INFORMATION Description of pictograms Immediate hazardous situation which could result Danger indications in serious injury or death. Possibly dangerous situation that could cause serious injury or death. High voltage! Caution! Danger of death! Non-observance can cause serious injury or death Risk of high temperatures, non-compliance may result in serious injury or death.
- Page 4 CONTENTS DOCUMENT IDENTIFICATION STANDARDS OF REFERENCE INFORMATION FOR OPERATORS Foreword - Purpose of document - How to read the document Keeping the document - Addressees - Operator training program Pre-arrangements depending on customer - Contents of supply - Intended use Allowed operational and environmental conditions - Test inspection and warranty GENERAL SAFETY INFORMATION General safety indications - Tasks and qualifications - Working areas and dangerous...
- Page 5 INFORMATION FOR OPERATORS Foreword This document has been drawn up in the mother language of the manufacturer (Italian). The information it con- tains is for the sole use of the operator authorised to use the appliance in question. Operators must be trained concerning all aspects regarding functioning and safety. Special safety prescriptions (Obligations-Prohibitions-Dangers) are carried in a specific chapter concerning these issues.
- Page 6 INFORMATION FOR OPERATORS Intended use Original instructions. This device is intended for professional use. The use of the appliance treated in this docu- ment must be considered "Proper Use" if used for cooking or regeneration of goods intended for alimentary use;...
- Page 7 GENERAL AND SAFETY INFORMATION General safety indications Each technical modification affects the machine functioning or safety, therefore, it must be carried out by the manufacturer technical staff or by technicians who has been formally authorized by the same manufacturer. Otherwise, the manu- facturer refuses all responsibility concerning modifications or damages which could be consequently rise.
- Page 8 GENERAL AND SAFETY INFORMATION Tasks and qualifications required for the operators “Homogeneous” Operator (SKILLED OPERATOR) Learned operator, authorized to carry out the handling, transport, installation, maintenance, re- pair and demolition of the equipment. The homogeneous operator can not carry out any type of operation (installation, maintenance and/or other) without having first examined the whole documentation.
- Page 9 GENERAL AND SAFETY INFORMATION Indications concerning residual risks Though the rules for "good manufacturing practice" and the provisions of law which regulate manufacturing and marketing of the product have been implemented, "residual risks" still remain which, due to the very nature of the appliance, could not be eliminated.
- Page 10 POSITIONING AND HANDLING Obligations - Prohibitions - Suggestions - Recommendations On reception, open the packaging and make sure that the appliance and accessories have not been damaged during transportation. If damage is found, report it promptly to the carrier and do not install the appliance.
- Page 11 POSITIONING AND HANDLING Foreword Depending on the cases, the appliance is shipped in the fol- lowing configuration: Blocked on the wooden base, with lining in a material su- itable for packaging (detail A). The type of packaging is chosen according to transport dis- tance, to the customer prescriptions and to how long the ap- pliance will remain in the package.
- Page 12 POSITIONING AND HANDLING Removal of protection materials The outer surfaces of the appliance are protected by a coating of adhesive film, which must be manually re- moved once positioning phase is over. Clean the appliance manually removing all the material used to protect its parts. Make sure not to damage the stainless steel surfaces, and remember especially not to use cor- rosive products, abrasive material or sharp tools.
- Page 13 POSITIONING AND HANDLING “Series” assembly Remove the knobs and unscrew the screws for the fixing of the panel on both appliances (detail F). The minimum distance of the appliance from the wall must be 10 cm, if this should be lower, the walls immediately close to the appliance should be insulated with fire-retardant and/or insulating treat- ments.
- Page 14 CONNECTION TO ENERGY SOURCES 4.1 ELECTRICAL CONNECTION On the power supply line upstream of the appliance, a locking device must be installed that shuts off the power whenever it is necessary to operate in safe conditions, such as: • manual switch of suitable capacity, equipped with fuse valves •...
- Page 15 CONNECTION TO ENERGY SOURCES 4.2 CONNECTION THE “EQUIPOTENTIAL” SYSTEM The protective earthing consists of a series of measures de- signed to ensure the electrical masses the same earth poten- TOP VERSION tial avoiding a situation where these may be in tension. The purpose of earthing is therefore to ensure that the masses of the appliances are at the same earth potential.
- Page 16 INSTRUCTIONS FOR USE Description of stop modes In stoppage conditions caused by faults and emergencies, in the event of imminent danger, it is mandatory to close all the locking devices on the supply lines upstream the appliance (Electrical- Water-Gas). The drawing illustrates the various positions the knobs take on during an emergency stop (A1-B1- C1-D1-E1) and stoppage during a working phase (A2-B2-C2-D2-E2).
- Page 17 INSTRUCTIONS FOR USE Commissioning When commissioning the appliance and when starting it after a prolonged stop, it must be thor- oughly cleaned to eliminate all residue of extraneous material (See Routine Maintenance). When the operations have been successfully performed, go on with the ordinary use of the appliance, see “Daily activation”.
- Page 18 MAINTENANCE Obligations - Prohibitions - Suggestions - Recommen- dations Before performing any of the cleaning operations described hereafter, the operator must have had a look at the whole document, carefully read: • General and safety warnings • Indications concerning residual risks •...
- Page 19 MAINTENANCE Qualification - Operation - Frequency “Generic” Operator “Homogeneous” Operator Person authorised and in charge of ap- Learned operator, authorized to carry out pliance operation with active guards and the handling, transport, installation, main- capable of performing simple tasks. tenance, repair and demolition of the equipment.
- Page 20 MAINTENANCE Troubleshooting Notes! Whenever the appliance does not work properly, try to solve the less serious problems using this table. FAULT POSSIBLE CAUSE OPERATION The appliance does not turn on. • The master switch is not con- • Connect the master switch. nected.
- Page 21 WASTE DISPOSAL Deactivation and scrapping of appliance OBLIGATION OF DISPOSING OF MATERIALS USING THE LEGISLATIVE PROCEDURE IN FORCE IN THE COUNTRY WHERE THE APPLIANCE IS SCRAPPED In compliance with Directives (see Section n. 0.1) relating to the reduction of use of hazardous sub- stances in electrical and electronic equipment, as well as waste disposal.
- Page 22 DA TI TECNICI - TECHNICAL DA T A - DONNEES TECHNIQUES - DA TOS TÉCNICOS - TECHNISCHE DA TEN Alim. elettrica Alim. elettrica Alim. elettrica Alim. elettrica Forno 380/415 V 380/415 V 220/240 V 220/240 V Dimensioni Dimensioni Potenza Peso Grill MODELLO ~ 3N 50-60 Hz...
- Page 23 SCHEMI D’INST ALLAZIONE - INST ALLA TION DIAGRAM - SCHEMAS D’INST ALLA TION - INST ALLA TIONSPLÄNE - ESQUEMAS DE INST ALACIÓN E2...A - E4...A - E6(F)...A PG21 ELECTRIC CONNECTION 1200 1080 PG21 ELE. CONN. PG21 ELE. CONN. PG21 ELE. CONN. PG21 ELE.
- Page 24 SCHEMI D’INST ALLAZIONE - INST ALLA TION DIAGRAM - SCHEMAS D’INST ALLA TION - INST ALLA TIONSPLÄNE - ESQUEMAS DE INST ALACIÓN E2... - E4... - E6... 1200 1180 CTRICAL SUPPLY ELECTRICAL SUPPLY ELECTRICAL SUPPLY ELECTRICAL SUPPLY 1200 ELECTRICAL SUPPLY ELECTRICAL SUPPLY ELECTRICAL SUPPLY THE PRESENT MANUAL IS PROPERTY OF THE MANUFACTURER.
- Page 25 SCHEMI D’INST ALLAZIONE - INST ALLA TION DIAGRAM - SCHEMAS D’INST ALLA TION - INST ALLA TIONSPLÄNE - ESQUEMAS DE INST ALACIÓN ET A9... ET9... 1/2" GAS INLET 1/2" GAS INLET 1/2" GAS INLET 1/2" GAS INLET EL. SUPPLY ELECTRICAL SUPPLY 1/2"...
- Page 26 SCHEMA ELETTRICO - WIRING DIAGRAM - SCHEMA ELECTRIQUE - SCHAL TPLAN - ESQUEMA ELECTRICO E2... THE PRESENT MANUAL IS PROPERTY OF THE MANUFACTURER. ANY REPRODUCTION, EVEN PARTIAL, IS PROHIBITED. IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - E -...
- Page 27 SCHEMA ELETTRICO - WIRING DIAGRAM - SCHÉMA ÉLECTRIQUE - SCHAL TPLAN - ESQUEMA ELECTRICO E4... THE PRESENT MANUAL IS PROPERTY OF THE MANUFACTURER. ANY REPRODUCTION, EVEN PARTIAL, IS PROHIBITED. IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - F -...
- Page 28 SCHEMA ELETTRICO - WIRING DIAGRAM - SCHÉMA ÉLECTRIQUE - SCHAL TPLAN - ESQUEMA ELECTRICO E6... IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - G -...
- Page 29 SCHEMA ELETTRICO - WIRING DIAGRAM - SCHÉMA ÉLECTRIQUE - SCHAL TPLAN - ESQUEMA ELECTRICO E4F ... THE PRESENT MANUAL IS PROPERTY OF THE MANUFACTURER. ANY REPRODUCTION, EVEN PARTIAL, IS PROHIBITED. IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - H -...
- Page 30 SCHEMA ELETTRICO - WIRING DIAGRAM - SCHÉMA ÉLECTRIQUE - SCHAL TPLAN - ESQUEMA ELECTRICO E6F ... THE PRESENT MANUAL IS PROPERTY OF THE MANUFACTURER. ANY REPRODUCTION, EVEN PARTIAL, IS PROHIBITED. IL PRESENTE MANUALE È DI PROPRIETÀ DEL FABBRICANTE E OGNI RIPRODUZIONE ANCHE PARZIALE È VIETATA. - I - I...
- Page 31 REMARKS THE PRESENT MANUAL IS PROPERTY OF THE MANUFACTURER. ANY REPRODUCTION, EVEN PARTIAL, IS PROHIBITED. - K -...
