Central Brass
Single Handle Basin Faucet:
•
0239-AC
•
0239-AH
•
0239-AP
•
0239-C
•
0239-H
•
0239-P
•
0239-AC4C
•
0239-AC4H
•
0239-AC4P
This product meets the following standards:
•
ASME A112.18.1
•
ANSI A117.1
•
CUPC / IAPMO LISTED / ADA COMPLIANT
•
CONTAINS NO MORE THAN 0.25% WEIGHTED AVERAGE
LEAD CONTENT
C O M P A N Y
A Division of Pioneer Industries, Inc.
Installation Guide
•
0239-C4C
•
0239-C4H
•
0239-C4P
Central Brass Company © 2011
REV-11 14, 11
Advertisement
Related Manuals for Pioneer Central Brass 0239-AC
Summary of Contents for Pioneer Central Brass 0239-AC
- Page 1 Central Brass C O M P A N Y A Division of Pioneer Industries, Inc. Installation Guide Single Handle Basin Faucet: • 0239-AC • 0239-C4C • 0239-AH • 0239-C4H • 0239-AP • 0239-C4P • 0239-C • 0239-H • 0239-P •...
-
Page 2: Care Instructions
Thank You For Choosing Central Brass Products Thank you for purchasing this quality product. Central Brass products are rigorously tested to provide long service under normal conditions. Prior to installation, familiarize yourself with this products diagram. Make sure that you have all of the illustrated parts for your Central Brass product before installation. - Page 3 CENTRAL BRASS LIMITED WARRANTY The Central Brass Company provides to the original consumer the following warranties for Genuine Central Brass manufactured products and components used in commercial or residential applications. Central Brass Company will replace, free of charge, to the original consumer purchaser, any and all parts that prove defective under normal installation, use, and service.
-
Page 4: Faucet Installation
Faucet Installation Apply plumbers putty under neath of the faucet(A). Place the faucet through the mounting surface. Slide the crowfoot washer (B) through shank from underneath of the mounting surface. Tighten the locknut (C) with the help of 1-3/32” socket set. REV-11 14, 11... - Page 5 Main Supply Connection Connect the faucet shank to inlet supply line (D). Connect the supply stop (E) to the inlet supply line (D) Make sure inlet supply line (D) are securely tighten. Do not overtighten. Turn on water. Check for any leaks. Make sure all the connections are secure. Remove aerator (F).Open the handle.
- Page 6 Central Brass C O M P A N Y A Division of Pioneer Industries, Inc. 6892 Snowville Road | Brecksville, Ohio 44141 Telephone: (800) 321-8630 | (216) 883-0220 | Fax: (800) 338-9414 Hours: M - F, 7:30am to 5:00pm EST www.centralbrass.com...
