ORIGINAL OPERATING INSTRUCTIONS
CORDLESS DRILL DRIVER & IMPACT DRIVER
Thank you for buying a WORKPRO 20V cordless drill driver & impact driver set. Your new cordless drill driver & impact
driver has been engineered and manufactured to WORKPRO's high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's manual.
SAVE THIS MANUAL FOR FUTURE REFERENCE
20V
LI-ION
2.0Ah
W004579AU
20V
LI-ION
2.0Ah
Model #：J0Z-WYT01B-18Li
P0B-WYT02-18Li
Hangzhou Great Star Industrial Co., Ltd.
No.35 Jiuhuan Road, Jiubao Town,
Hangzhou 310019, China
www.greatstartools.com
Distributed by
Advertisement
Related Manuals for WorkPro W004579AU
Summary of Contents for WorkPro W004579AU
- Page 1 2.0Ah 2.0Ah Thank you for buying a WORKPRO 20V cordless drill driver & impact driver set. Your new cordless drill driver & impact driver has been engineered and manufactured to WORKPRO's high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
- Page 2 TABLE OF CONTENTS General safety rules Additional safety instructions Additional safety instructions for the charger Additional safety instructions related to the battery pack and battery safety When to charge the battery Caution Description of symbols Environmental protection Disposal of an exhausted battery pack DRILL DRIVER Component list and specifications Operating instructions...
- Page 3 the switch or energising power tools that have the GENERAL SAFETY RULES switch on invites accidents. WARNING. Read all safety warnings and all d. Remove any adjusting key or wrench before turning instructions. Failure to follow the warnings and the power tool on. A wrench or a key left attached instructions may result in electric shock, fire and/or to a rotating part of the power tool may result in serious injury.
- Page 4 If possible, always use clamps or a vice to hold your work piece. Your Workpro tool with Lithium Ion batteries may only be charged with the specific designed Workpro Always switch off before you put the tool down.
- Page 5 Do not plug anything other than your Workpro tool Do not use the battery to power any device other into the charger, as other objects may touch than the WORKPRO tool it was sold with.
- Page 6 Warnings. housing and cover the battery pack Your WORKPRO power tool has many features that connections with heavy-duty adhesive tape will make your job faster and easier. Safety, to prevent short circuit and energy performance, and dependability have given top priority discharge.
- Page 7 DRILL DRIVER SPECIFICATIONS Charger:...........200-240V~50/60Hz COMPONENT LIST Battery:..............2.0Ah Charging Time:............1H 3/8"(10mm) Keyless Chuck Drill No Load Speed:....... 0-360/0-1300/min Torque Adjustment Ring Torque Settings: .............18+1 Two-speed Gear Control Torque: ............. 25 N.M. Forward/Reverse Rotation Control Belt Clip Drill Chuck Capacity: ......3/8"(10mm) keyless Battery Pack Max.
- Page 8 INTENDED USE The machine is intended for driving in and loosening screws as well as for drilling in wood, metal and plastic. WORKPRO LI-ION 2.0Ah Before Putting Into Operation A. Charging The Battery The battery charger supplied is matched to the Li-ion battery installed in the machine.
- Page 9 DRILL DRIVER WARNING: Never change the direction of Fig. D rotation when the chuck is rotating, wait until it has stopped! Fig. 4. Two-speed Gear Control ( The drill has a two-speed gear control designed for drilling or driving at LOW (mark is 1) or HIGH (mark is 2) speeds.
- Page 10 DRILL DRIVER PROBLEM SOLUTION Fig. H 1. Why Does The Drill Not Turn On When You Press The Switch? The forward/reverse rotation control, which is on top of the trigger, is positioned in the lock function. Unlock the forward/reverse rotation control by putting it into the required rotation position.
- Page 11 UKCA-DECLARATION OF CONFORMITY Herewith we, NINGBO WEILDER ELECTRIC APPLIANCE CO., LTD NO.47 DONGFENG ROAD, FENGHUA, 315500 NINGBO, ZHEJIANG, P.R.C. Declare that the following Appliance complies with the appropriate basic safety and health require- ments of the UKCA Directives(see item 4) based on its design and type, as brought into circulation by This declaration relates exclusively to the machinery in the state in which it was placed on the market, and excludes components which are added and/or operations carried out subsequently by the final user.
- Page 12 IMPACT DRIVER SPECIFICATIONS Charger: ......... 200-240V~50/60Hz COMPONENT LIST Battery: ..............2.0Ah Forward, Reverse Rotation and Lock Control Charging Time: ............1H Belt Clip Drill No Load Speed: ........0-2600/min Battery Pack Torque: .............120 N.M. Battery Pack Release Button Drill Chuck Capacity: ......6.35mm (1/4") hex ON/OFF Switch With Variable Speed Control Driver Impact Frequency: ......0-3000/min LED Light...
- Page 13 INTENDED USE This tool is intended for the fastening and loosening of bolts, nuts and various threaded fasteners. This tool is not intended for use as a drill. WORKPRO LI-ION 2.0Ah BEFORE PUTTING INTO OPERATION 1) Charging the Battery Pack Your battery pack is UNCHARGED and you must charge once before use.
- Page 14 IMPACT DRIVER 4. Using The LED Light PROBLEM SOLUTION The LED light allows you to keep a clear view under Reasons for Different Battery Pack Working Times less illuminated circumstances. To turn on the light Charging time problems, as above, and having not simply press the on/off switch.
- Page 15 MAINTENANCE BATTERY CAPACITY INDICATOR Battery capacity indicator Clean the drill driver and impact driver using a soft, Press the battery capacity indicator switch.The battery damp cloth. Do not use detergents or flam mable capacity indicator shows the charge status of the products which may damage the tool.
- Page 16 UKCA-DECLARATION OF CONFORMITY Herewith we, NINGBO WEILDER ELECTRIC APPLIANCE CO., LTD NO.47 DONGFENG ROAD, FENGHUA, 315500 NINGBO, ZHEJIANG, P.R.C. Declare that the following Appliance complies with the appropriate basic safety and health require- ments of the UKCA Directives(see item 4) based on its design and type, as brought into circulation by This declaration relates exclusively to the machinery in the state in which it was placed on the market, and excludes components which are added and/or operations carried out subsequently by the final user.
