- Page 1 Table Top Freezer Instruction Manual Model number(s): ATTFZ0E1 [W/B/S/SS] For Customer Services & Spare Parts please call 0345 208 8750 IMPORTANT: RETAIN FOR FUTURE REFERENCE...
- Page 2 Contents Safety Instructions ………………………………………. Electrical Safety ………………………………………. Transportation & Handling ………………………………………. Installing & Switch on your Appliance ………………………………………. Before Switching On ………………………………………. Product Overview ………………………………………. Unit & Spare Parts ………………………………………. Usage ………………………………………. Temperature Selection ………………………………………. Door Reversal ………………………………………. 10-11 Energy Saving Advice ……………………………………….
- Page 3 Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. Warning: When positioning the appliance, ensure the supply cord is not trapped or damaged.
- Page 4 • D o not plug in damaged plugs. • D o not pull, twist or damage the power cable. • D o not plug-in or un-plug the appliance with wet hands to prevent electrical shock. • T his appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards...
- Page 5 • If the appliance is left empty for long periods, switch off, defrost, clean, dry and leave the door open to prevent mount developing within the appliance. • This refrigerating appliance is not intended to be used as a built-in appliance.
- Page 6 Installing and Switching on Your Appliance • Operating voltage for your appliance is AC220-240V at 50Hz. • Before plugging in the power supply, ensure that the voltage on the rating label corresponds to the working voltage of your electrical system in your home. •...
- Page 7 WARNING! During use, service and disposal of the appliance, please pay attention to symbol similar to the one shown, which is located on rear of the appliance (rear panel or compressor) and with a yellow or orange colour. It’s risk of fire warning symbol. There are flammable materials in refrigerant pipes and compressor.
- Page 8 Product Overview 1. Cabinet Door Hinge and Cover 2. Wire Rack (Shelf) Door Door Gasket Thermostat Adjustable feet Unit Parts & Spare Parts Before installation, check that all parts detailed in the product overview are present. If any parts are missing, please contact the Customer Service team on 0345 208 8750...
- Page 9 Usage Allow to stand for a minimum of 3 hours before plugging in to the mains The temperature in the appliance is controlled by the temperature control knob located inside the appliance. Rotate the control knob left or right to regulate the temperature inside the freezer.
- Page 10 Door Reversal You will need to tilt the freezer backward to access the lower hinge which holds screws. Do not tilt more than 45 degrees and do not lay the freezer flat on its side. Reversing the door: 1. Remove the top plastic hinge cover and set aside 2.
- Page 11 Door Reversal 4. Remove the adjustable foot at the bottom of the fridge and set aside. 5. Unscrew the two screws holding the bottom door hinge and carefully moving it across to the opposite side and fix into position. Care must be taken as the door will be loose.
- Page 12 Energy Saving Advice • Do not install the appliance close to sources of heat, such as a cooker, dishwasher or radiator. • Locate the appliance in a cool well-ventilated room and make sure that the air vents are clear. • Try to avoid keeping the doors open for a long time, warm air will enter the cabinet and may cause a build-up of ice as well as affecting the energy consumption.
- Page 13 Food Storage Guidelines Refrigerator compartments Type of food Freezer drawer(s)/shelf Foods for long-term storage. Bottom drawer shelf for raw meat, poultry, fish. Top shelf for ice cream, frozen fruit, frozen baked goods. Power Failure If there is a power failure during the storage of frozen foods, keep the door closed. If the temperature within your freezer should rise, do not refreeze the food without checking it's condition.
- Page 14 Maintenance & Cleaning Disconnect the appliance from the power supply before cleaning. Internal Cleaning • Do not pour water over the appliance. • The cavity should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water (5ml to 0.5 litre of water) •...
- Page 15 Maintenance & Cleaning Defrosting Note: Care must be taken when performing the following procedure. Defrost twice a year or when a frost layer of approximately 7 mm (1/4”) has formed. • 6 hours before the defrosting process, set the thermostat knob at the “MAX” position to make sure the food is at the lowest temperature before removing the frozen foods.
- Page 16 Trouble shooting Problem Solution Check that the appliance is switched on. Check that there has not been a power cut. Check that the plug is not faulty. Check that the fuse has not blown. The freezer doesn't work Check that the voltage is correct for the appliance. Are there any faults with the socket? For this purpose, try the plug of your appliance by connecting it to a socket which you are sure is working.
- Page 17 Trouble shooting Problem Solution Check all the food and drink that is in the freezer is in date and correctly packaged. If it isn’t then it should be removed immediately or repackaged. Smell/odour Check for spillages on each shelf, rack and drawer. You may need to remove the drawers to check that no spillages have settle underneath them.
- Page 18 Connection to the Mains Supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC220V - 240V; 50Hz. Check that the voltage marked on the product corresponds with your supply voltage. For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which...
- Page 19 Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Product Care with the original proof of purchase so a replacement or refund can be arranged. Refund or replacement is at the discretion of Product Care.
- Page 20 Technical Specification Model number ATTFZ0E1 [W/B/S/SS] Rated Voltage 220V – 240V ~ 50Hz Capacity External Dimensions(HxWxD) 492mm x 472mm x 450mm Ambient temperature Class Symbol Information range ( ° C) Extended temperate: 'this refrigerating appliance is Extended +10 to +32 intended to be used at ambient temperatures ranging temperate from 10 °...
- Page 21 Product Fiche Supplier's name or Trade Mark: Russell Hobbs Supplier's Address: Unit 1, Green Bank Business Park, Wigan, WN2 4AY / PCT (NI) Ltd, Belfast, BT5 5AD. Model Identifier: ATTFZ0E1 W/B/S/SS Product Type Freezer Value Value Height 49.2 Dimensions (cm) Width 47.2 Total Volume (L)
- Page 22 Notes...
- Page 23 Notes...
- Page 24 Abode is a registered trademark of Product Care Trading Limited, Wigan, WN2 4AY/ PCT (NI) Ltd, Belfast, BT5 5AD Abode Support: call 0345 208 8750 The ‘wheelie bin’ symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
