Sealey BT2012.V3 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
1.1. PERSONAL PRECAUTIONS
Ensure that there is another person within hearing range and close enough to come to your aid, should a problem arise when working
9
near a lead-acid battery.
Wear safety eye protection and protective clothing. Avoid touching eyes while working near battery.
9
Have fresh water nearby in case battery acid contacts skin, clothing, or eyes.
9
Rinse immediately with water if battery acid contacts skin or clothing. If acid enters eye, flush eye immediately with cool, clean
9
running water for at least 15 minutes and seek immediate medical attention.
Remove personal metallic items such as rings, bracelets, necklaces and watches. A lead-acid battery can produce a short-circuit current
9
which is high enough to weld such items to the vehicle and cause severe burns.
Ensure that hands, clothing (especially belts) are clear of fan blades and other moving or hot parts of engine. Remove ties and contain
9
long hair.
DO NOT smoke or allow a spark or flame in the vicinity of the battery or engine.
8
1.2. GENERAL SAFETY INSTRUCTIONS
Familiarise yourself with the application, limitations and potential hazards of the tester. Also refer to the vehicle manufacturer's hand
9
book.
IF IN ANY DOUBT CONSULT A QUALIFIED ELECTRICIAN.
Ensure that the tester is in good condition before use. If in any doubt DO NOT use the unit and contact a qualified electrician.
9
Only use recommended attachments and parts. To use unapproved items may be dangerous and will invalidate your warranty.
9
Keep tools and other items away from the engine and ensure that you can see the battery and working parts of the engine clearly.
9
Determine the system voltage before using the tester.
9
If the tester receives a sharp knock or blow the unit must be checked by a qualified service agent before using.
9
If the battery terminals are corroded or dirty: clean them before using the tester.
9
Keep children and unauthorised persons away from the work area.
9
DO NOT dismantle the tester for any reason. The tester must only be checked by qualified service personnel.
8
WARNING! To prevent the risk of sparking, short circuit and possible explosion DO NOT drop metal tools in the battery area, or allow
‰
them to touch the battery terminals.
DO NOT cross-connect tester to battery. Ensure positive (RED) clamp is to positive terminal and negative (BLACK) clamp is to negative
8
terminal. If battery symbols cannot be distinguished: the negative terminal is the one directly connected to the vehicle bodywork.
DO NOT use the tester outdoors, or in damp, or wet locations and DO NOT use in the vicinity of flammable liquids or gases.
8
Ensure there is effective ventilation to prevent a build-up of explosive gases.
8
DO NOT use the tester for a task for which it is not designed.
8
When not in use, store the tester carefully in a safe, dry, childproof location.
9
2. INTRODUCTION
Offers a full diagnosis of the vehicle battery, starter motor and alternator in seconds. The tester will work on batteries with as little as
1.5V of residual charge. Supports 12V batteries including standard Lead-Acid, VRLA, GEL plus AGM and EFB found on all
Start/Stop vehicles. Large LCD shows charging and starting system status and returns decision-making information in seconds, with
the facility to print the results. Fitted with a heavy-duty rubber cover for better grip.
3. SPECIFICATION
Model No: ..................................................................... BT2012.V3
Battery: ......................................................... 1 x 9V (not included)
Charging System Capability: ....................................................12V
Consumable ..............................................Parts: .... BT2012.V2-01
- Printing Roll for BT2012.V2 Pack of 2
Minimum Power Requirement: ................................................1.5V
Note: ..................................................*CCA - Cold Cranking Amps
Rated Battery Voltage: .............................................................12V
Rating Systems: ............................................... DIN, EN, IEC, SAE
Voltage Range: ..................................................................1.5-17V
© Jack Sealey Limited
12V DIGITAL BATTERY & ALTERNATOR/
STARTER TESTER WITH PRINTER
MODEL NO:
Wear protective Wear protective
clothing gloves
Original Language Version
BT2012.V3
Warning Warning
corrosive
substance
Test Ranges Table:
50-1400 CCA*, 50-800 CCA* DIN, 50-1400 CCA* EN, 50-
800 CCA* IEC, 50-1400 CCA* SAE, By Battery Type JIS
BT2012.V3 Issue 2 17/10/23
