Sealey APMWB1 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
Unpack the unit and confirm that you have all parts listed.
9
Assemble on a solid, level surface. Avoid carpet.
9
You will require assistance from a second person during assembly.
9
For added safety and support, it is recommended to fix the unit to a wall. Use correct fixings for the structure of the wall.
9
When assembling or installing this product, wear protective gloves and eyewear.
9
This product has been tested to safety carry a load of up to 1100kg evenly distributed, when properly installed and maintained.
9
Heaviest items are to be loaded on the lowest shelves.
9
2. INTRODUCTION
Rubber wood workbench with racking storage and pegboard. Textured powder coat steel frame with three heavy-duty powder coated
steel mesh shelves. Industrial structured beams offer added strength. Tool-less assembly of upright and shelves with just basic
assembly required to attach pegboards. Specifically designed and sized drawer units and cupboards available to keep storage tidy, see
model numbers APMB1, APMB2, APMB3, APMB4 and APMB5 (sold separately).
3. SPECIFICATION
MODEL NO:
Overall Size
Weight Capacity:
4. CONTENTS
NOTE: You will need the following : rubber mallet, crosshead screwdriver, adjustable spanner, drill and 3mm drill bit.
PARTS
© Jack Sealey Limited
HEAVY-DUTY MODULAR WORKBENCH WITH RACKING
& PEGBOARD - 300KG CAPACITY PER LEVEL
MODEL NO:
Wear protective
gloves
APMWB1
Width: 1820mm
Depth: 540mm
Height: 2090mm
Top Shelf: 200kg
Workbench: 300kg
Middle Shelf: 300kg
Bottom Shelf: 300kg
Original Language Version
APMWB1
FIXINGS
APMWB1 Issue 2 (6) 15/04/24
