Sealey VEN500 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Indoor use only Do not cover
instruction
manual
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user's responsibility to check the following:
‰
Check all electrical equipment and appliances to ensure that they are safe before using.
Inspect power supply leads, plugs and all electrical connections for wear and damage.
Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
DO NOT use worn or damaged cables, plugs or connectors.
8
Ensure that any faulty item is repaired or is replaced immediately by a qualified electrician.
9
If the cable or plug is damaged during use, switch off the electricity supply and remove from use.
9
Ensure that repairs are carried out by a qualified electrician.
Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
9
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the
correct fuse.
DO NOT pull or carry the appliance by the power cable.
8
DO NOT pull the plug from the socket by the cable.
8
1.2. GENERAL SAFETY
Disconnect the ventilator from the mains power when not in use, and before servicing or performing any maintenance.
9
Use the fan in dry areas only. Do not use in wet or high condensation locations such as bathrooms, showers, or pools.
9
WARNING! If a ventilator falls into water, immediately switch off at the mains and disconnect from the mains power supply.
‰
DO NOT touch the ventilator until the mains power supply has been disconnected.
8
Always disconnect the ventilator from the power supply when moving it from one location to another.
9
Keep the ventilator clean and maintain in good condition (use an authorised service agent).
9
Use recommended parts only (unauthorised parts may be dangerous, and will invalidate your warranty).
9
DO NOT stand the ventilator where it may be knocked over or off a surface, or where the lead may cause a trip hazard.
8
DO NOT use an extension cord unless it has been approved by an electrical authority.
8
DO NOT insert any objects through the fan guard.
8
DO NOT allow children to operate the ventilator.
8
DO NOT immerse the ventilator in water or any other liquid.
8
DO NOT use the ventilator outdoors.
8
DO NOT cover the ventilator.
8
When not in use store in a safe, dry, childproof location.
9
2. INTRODUCTION
Ideal for use where high-volume air delivery is required. Especially suitable for ventilating confined, hot or fume laden work sites, typically
found in boats, cable/pipe ducts and roof spaces; creating a cleaner more pleasant working environment. Lightweight and robust construction
gives the portability and durability necessary in the workplace. Mounted on a steel frame with 4 castor wheels, 2m cable and 3-pin plug.
Supplied with 5m ducting, optional 10m length available.
3. SPECIFICATION
Model No.: ................................................................VEN500
Airflow: .............................. 9900m³/hr(5814cfm) - 165m³/min
Efficiency Category: ...................................................... Static
Efficiency Grade: ................................................................ 40
Electrical Class: ......................................................... Class 1
Fan Diameter: ......................................................... Ø500mm
Fan Speed: .............................................................. 1400rpm
Fuse Rating: ....................................................................13A
IP Rating: .................................................. IP54 (Fan is IP20)
© Jack Sealey Limited
PORTABLE VENTILATOR Ø500MM WITH 5M
DUCTING
VEN500
MODEL NO:
Original Language Version
VEN500 Issue 1 12/08/24
