Model No. EE-C9M

Installation, Operation

Two Post Lift,

and Parts Manual

Manual Release

Lifting Capacity 3500KG

Distributed by

Please read this entire manual carefully and completely before installation or operation of the lift.

DATE：02/02/2024

Table of Contents

Need help?

Do you have a question about the EE-C9M and is the answer not in the manual?

Questions and answers

Summary of Contents for EAE EE-C9M

Page 1 Model No. EE-C9M Installation, Operation Two Post Lift, and Parts Manual Manual Release Lifting Capacity 3500KG Distributed by Please read this entire manual carefully and completely before installation or operation of the lift. DATE：02/02/2024...
Page 2: Important Notes
Liability The liability of EAE is limit to the amount that the customer has actually paid for this product. This exclusion of liability does not apply to damages caused through willful misconduct or gross negligence on the part of EAE.
Page 3: Table Of Contents
Installation, Operation and Parts Manual EE-C9M IMPORTANT NOTES ..........................2 SAFETY NOTES ............................4 1.1 Operation of lifting platforms ........................4 1.2 Checking of the lifting platforms ........................4 1.3 Important safety notices ..........................5 1.4 Warning labels ............................... 6 1.5 Potential safety risks ............................
Page 4: Safety Notes
Installation, Operation and Parts Manual EE-C9M SAFETY NOTES 1.1 Operation of lifting platforms This lift is specially designed for lifting motor vehicles. Users are not allowed to use it for any other purposes. The applicable national regulations, laws and directives must be observed.
Page 5: Important Safety Notices
Installation, Operation and Parts Manual EE-C9M 1.3 Important safety notices 1.3.1 Recommend for indoor use only. Do not expose the lift to rain, snow or excessive moisture. 1.3.2 Only use this lift on a surface that is stable and capable of sustaining the load. Do not install the lift on any asphalt surface.
Page 6: Warning Labels
Installation, Operation and Parts Manual EE-C9M 1.4 Warning labels All safety warning labels are clearly depicted on the lift to ensure that the operator is aware of and avoid the dangers of using the lift in an incorrect manner. The labels must be kept clean and they have to be replaced if detached or damaged. Please read carefully the meaning...
Page 7: Potential Safety Risks
Installation, Operation and Parts Manual EE-C9M 1.5 Potential safety risks 1.5.1 Mains voltage nsulation damage and other faults may result in accessible components being live Safety measures:  Only ever use the power cord provided or a tested power cord.
Page 8: Packing, Storage And Transportation
Installation, Operation and Parts Manual EE-C9M PACKING, STORAGE AND TRANSPORTATION Packing, lifting, handling, transporting operations must be performed only by experienced personnel with appropriate knowledge of the lift and after reading this manual. 2.1 The lift was dismantled into the following 3 parts for transportation...
Page 9: Products Descriptions
Installation, Operation and Parts Manual EE-C9M PRODUCTS DESCRIPTIONS 3.1 General descriptions This is chassis supporting vehicle lift for road vehicles. It is mainly composed by two posts, two carriages, four swing arms and a power and control unit. It is driven by an electro-hydraulic system. The gear pump delivers hydraulic oil to oil cylinders and pushes upwards its piston. The cylinder piston drives to raise the carriage and swing arms.
Page 10: Dimensions
Installation, Operation and Parts Manual EE-C9M 3.4 Dimensions Dimension scheme with two 3-stage arms and two 2-stage arms (Standard arms)
Page 11 Installation, Operation and Parts Manual EE-C9M Dimension scheme with four 3-stage low-profile arms (Optional arms)
Page 12: Safety Devices Descriptions
Installation, Operation and Parts Manual EE-C9M 3.5 Safety devices descriptions POS. Description Function Roof protective limit switch Stop rising in case the overhead bar is touched. Max rise limit switch Stop rising at max height. Mechanical safety locking unit Catch the carriages in case of hydraulic failure.
Page 13: Installation Instructions
Installation, Operation and Parts Manual EE-C9M INSTALLATION INSTRUCTIONS 4.1 Preparations before installation 4.1.1 Space requirements. Refer to 3.4 for the dimensions of the lift. There must also be a clearance of at least 1 meter between the lifting platform and fixed elements (e.g.
Page 14: General Installation Steps
Installation, Operation and Parts Manual EE-C9M 4.3 General installation steps ONLY TRAINED AND QUALIFIED INSTALLERS CAN PERFORM LIFT INSTALLATION DUTIES. Step 1: Remove the packaging and take out the accessories attached. ： Attention The packs must be opened adopting all the precautions required to avoid injury to persons (Keep at a safe distance when cutting the straps) or damage to parts of the machine (Be careful that no parts are dropped while you are opening the packaging).
Page 15 Installation, Operation and Parts Manual EE-C9M Step 4: Erect and secure the post. 1. Make the posts face to each other and the distance between the posts equals to the length of the crossbeam. Use proper means to erect the post.
Page 16 Installation, Operation and Parts Manual EE-C9M Anchoring bolt (foundation thickness ) (drilling depth) (anchoring depth) M18x160 ≥200mm 130mm 105mm 240mm ≤55mm Step 5: Connect and install the crossbeam. 1. Hex nut M14 2. Flat washer M14 3. Spring washer M14 4.
Page 17: Items To Be Checked After Installation
Installation, Operation and Parts Manual EE-C9M Step 6: Connect the synchronization steel cable. 1. Route and fix according to the following scheme. 2. Before attempting to route the cables, raise the lifting carriage at both sides to the first latching position making sure that the mechanical safety locking units in each post are fully engaged.
Page 18 Installation, Operation and Parts Manual EE-C9M Step 8: Connect the hydraulic hoses Connect oil hoses according to the following diagram. It must be taken adequate care that all fittings are securely tightened and no solid substance go into the hydraulic line, otherwise severe leakage will occur.
Page 19 Installation, Operation and Parts Manual EE-C9M 2. Fix roof protection limit switch onto the overhead crossbeam and connect its wire. 1. Limit switch 2. Hex socket screw M4x25 3. Wire 3. Refer to the wire connection schemes and connect wires to the corresponding terminals in the control box.
Page 20 Installation, Operation and Parts Manual EE-C9M 1.Holder 2.Release rope 3.Safety hook 4.Release handle Attention: Tighten the nuts showing in the below scheme. 3. Install the switch. Install the holder (Pos.4) onto the post and fix the switch (Pos.1). Adjust the position of the switch, making it can be activated when the release handle has been pushed down maximally.
Page 21 Installation, Operation and Parts Manual EE-C9M Step 11: Install lifting arms. Install the lifting arms onto the carriages and ensure the arm lock can engage and release effectively. Attention: Install lifting arms ONLY after the complete assembly has been erected and anchored.
Page 22 Installation, Operation and Parts Manual EE-C9M Step 14: Fix the protective column curtain. 1.Hex nut M6 2.Class C flat washer M6 3.Hook 4. Column curtain. 5. Cross socket cap head screw M6x8 Step 15: Install the height-extension adapter holder. (Optional) 1.
Page 23: Items To Be Checked After Installation
Installation, Operation and Parts Manual EE-C9M 4.4 Items to be checked after installation Check items √ Screw torque of expansion bolts : 80-100Nm; √ Rising speed ≥20mm/s; √ Noise with load ≤70dB(A); √ Grounding resistance: not bigger than 4Ω; √...
Page 24 Installation, Operation and Parts Manual EE-C9M 5.2 Operation instructions POS. Descriptions Function Release the mechanical locking unit and Handle control the descending movement Power switch Turn on or off the power supply. Indicating light Indicate if power is on. UP button Control the rising movement.
Page 25: Trouble Shooting
Installation, Operation and Parts Manual EE-C9M TROUBLE SHOOTING ATTENTION: If the trouble could not be fixed by yourself, please do not hesitate to contact us for help. We will offer our service at the earliest time we can. Troubles could be judged and solved much faster when more details or pictures could be provided.
Page 26: Inspection And Maintenance
Installation, Operation and Parts Manual EE-C9M INSPECTION AND MAINTENANCE Easy and low cost routine inspection and maintenance can ensure the lift work normally and safely. Follow the below routine inspection and maintenance schedule with reference to the actual working condition and frequency of your lift.
Page 27 Installation, Operation and Parts Manual EE-C9M Pos. Components Methods Period Use proper means to activate the switch and push UP button to Roof protection limit switch every 30 days check if the carriages stop rising (1)Check if mechanical locking hooks can engage or disengage Mechanical safety locking unit simultaneously.
Page 28: Annex 1, Floor Plan
Installation, Operation and Parts Manual EE-C9M Annex 1, Floor plan Indoor installation only. The space requirement specified in the below scheme is for reference only. There must be sufficient space for driving and lifting vehicles and enough safety distance shall be reserved according to the regulations of the local authorities.
Page 29: Annex 2, Electrical Schemes And Parts List
Installation, Operation and Parts Manual EE-C9M Annex 2, Electrical schemes and parts list...
Page 30 Installation, Operation and Parts Manual EE-C9M YV: Solenoid valve for descending SQ1: Limit switch for roof protection SQ2: Limit switch for maximum height SQ3: Switch Symbol Code Description 320104002 Transformer（380V400V415V-24V） 320104001 Transformer（220V230V240V-24V） 320801001 Circuit breaker（3Ph） 320802001 Circuit breaker（1Ph） 320803001 Circuit breaker...
Page 31: Annex 3, Hydraulic Schemes And Parts List
Installation, Operation and Parts Manual EE-C9M Annex 3, Hydraulic schemes and parts list 1.oil tank 2.oil sucking filter 3.gear pump 4.coupling 5.motor 6.hydraulic block 7.cushion valve 8.overflow valve 9.single way valve 10.solenoid valve for descending 11.flow control valve 12.tank cover 13.composite connector...
Page 32 Installation, Operation and Parts Manual EE-C9M Pos. Code Descriptions Specification Power unit 207103025 Composite washer 13_7X20X1_5 Connector 310101008 M14*1.5-G1/4 624008222 Rubber oil hose L=650 615006003 Three-way connector 6214E-A4-B4 Rubber oil hose 624008215 L=7660mm Rubber oil hose 624008211 L=3115mm 615015003 Composite connector...
Page 33 Installation, Operation and Parts Manual EE-C9M Pos. Code Descriptions Specification 320201001 AC motor 220V-2.2KW -1PH-50HZ-2P AC motor 320201002 230V-2.2KW -1PH-50HZ-2P AC motor 320201003 240V-2.2KW -1PH-50HZ-2P AC motor 320201004 380V-2.2KW -3PH-50HZ-2P AC motor 320201005 400V-2.2KW -3PH-50HZ-2P AC motor 320201006 415V-2.2KW -3PH-50HZ-2P...
Page 34 Installation, Operation and Parts Manual EE-C9M Pos. Code Descriptions Specification 330308032 Solenoid plug DIN43650-DC 330308031 Solenoid LC2-0-C-2H,24VDC- 330302008 Non-return valve YBZ-E2D3I1/1-03 330101113 Hydraulic block LBZ-T2BK-8 207103025 Composite washer 13_7X20X1_5 310101008 Transition connector M14*1.5-G1/4 inside cone 210101014 Plug Z3/8 201101100 Bolt M6*50（NLJLD）...
Page 35: Annex 4, Mechanical Exploded Drawings And Parts List
Installation, Operation and Parts Manual EE-C9M Annex 4, Mechanical exploded drawings and parts list Pos. Code Description Specification 615006015 Steel cable L=10280mm 203101009 Hex nut M16-GB6170 204101009 Flat washer D16-GB95 410902109 Pulley C9Z-A1-B2...
Page 36 Installation, Operation and Parts Manual EE-C9M Pos. Code Description Specification Power unit 624008222 Rubber oil hose L=650 Rubber oil hose 624008211 L=3115mm 615015003 Composite connector 6255E-A7-B7 207103025 Composite washer 13_7X20X1_5 615006003 Three way connector 6214E-A4-B4 Rubber oil hose 624008215 L=7660mm...
Page 37 Installation, Operation and Parts Manual EE-C9M Pos. Code Description Specification 410902013 Spring C9Z-A1-B10 410902014 Spring C9Z-A1-B11 410010031 Washer 6254E-A1-B3 204301009 Circlip D25-GB894_2 410902031 Shaft C9Z-A1-B6 202111033 Hex socket flat head screw M8x65-GB70_3 202109152 Hex socket cylinder head screw M4X5-GB70_1 203101005...
Page 38 Installation, Operation and Parts Manual EE-C9M Pos. Code Description Specification 410902494 Steel cable L=7640mm Pos. Code Description Specification 614901721 Crossbeam (outside) C9MV2-A21-B1-1 202109024 Hex socket cylinder head screw M6X35-GB70_1 203103005 Locking nut M6-GB889_1 204101008 Flat washer D14-GB95 204201007 Spring washer...
Page 39 Installation, Operation and Parts Manual EE-C9M Pos. Code Description Specification 203103005 Locking nut M6-GB889_1 410170101B Cylinder orientation ring 6264-A24-B1 202109096 Hex socket cylinder head screw M6X40-GB70_1 614901378 Carriage C9Z-A3-B1-2 420680083 Sliding block C9Z-A3-B5 420680124 Protective rubber pad 62B-A3-B11 202109031 Hex socket cylinder head screw...
Page 40 Installation, Operation and Parts Manual EE-C9M Pos. Code Description Specification 204101008 Flat washer D14-GB95 204201007 Spring washer D14-GB93 203101008 Hex nut M14-GB6170 201102035 Hex head full swivel screw M14X30-GB5783 614901416 Extending post for power side post C9MV2-A5-B1...
Page 41 Installation, Operation and Parts Manual EE-C9M Pos. Code Description Specification 614901486 Power side post C9MV2-A1-B1-1 420680096 Protective cover C9Z-A1-B9-1 202109017 Hex socket cylinder head screw M6X8-GB70_1 202101020 Cross socket cap head screw M5X8-GB818 Control box 203204103 Flange nut M8-GB6177 420040010...
Page 42 Installation, Operation and Parts Manual EE-C9M Optional Low-profile 3-stage arms (615-1150 ,745-1345) Pos. Code Description Specification 614901422 Lifting arm of long 3-stage arm (right side) 6254E-A28-B1 614901423 Mid arm of the long 3-stage arm (right side) 6254E-A28-B2 614901424 Retractable arm of the long 3-stage arm...
Page 43 Installation, Operation and Parts Manual EE-C9M Optional height-extension adapter and holder Pos. Code Description Specification 612004003B Height-extension adapter 6254E-A11,L=100 612005002 Height-extension adapter 6254EB-A4, L=55 410901744 Holder 6254E-A1-B1-C6-V0 202110004 Hex socket button head screw M8X12-GB70_2...
