LAN
Browser or App
Bluetooth / Wi-Fi
wireless
Antenna
trivum TouchPad 7"
(optional)
DHCP
DHCP
NAS
(optional)
Network
trivum AudioBus In / Out
SDAT / MDAT
Required components for installation:
• Ethernet cable
• Network with DHCP capable router
• Browser (PC / Mac) or trivum App
• Cable with jack 3.55mm connector for Line In and/or Line Out
• Speakers with 4 or 8 Ohms impedance
Expansion with 19" Mounting Kit example
Like any trivum SoundSystem, the SC311m can be expanded and combined with other trivum systems.
In this case it is possible to build the pair into a 19" cabinet with a special mounting kit (AN: 500068).
The Kit includes: 2x rack brackets, 1x mount plate and 8x screws.
More about how to "Combining multiple trivum Devices" you can find by:
www.trivum.de/mcenter-manual
⚠
Please never use screws longer than the ones provided, they can damage the unit internally.
We reserve the right to make misprints, mistakes and changes in the case of product progress, even without prior
notice. 07/2022
Analog Line-Out
Power Supply
DAB+/FM Radio
AC 100V-240V
Trigger
G
1
2
Mains 100-240V AC
Analog Line-In
Speakers
Digital Line-In
trivum AudioBus-Out
MDAT
19" Mount Kit: 500068
SC311m
AN: 201016
Quick Installation Guide
Technical Data
Zones
1 Zone
Expandable to up to 64 zones
Source
1x Streaming Client
1x DAB+/FM Tuner
1x Analog Line Input
1x Digital Line Input (optical)
Streaming
up to 192kHz 24Bit
Radio
DAB+/FM
Music Formats
MP3, AAC, FLAC, M4A, WMA, ALAC
Connections
1x Network (RJ45 Socket)
1x USB (for service)
1x Speaker Stereo (4-Pin connector)
1x Analog Line Input
1x Analog Line Output
1x Digital Line Input (optical)
1x DAB+/FM antenna (F socket)
1x USB-C trivum AudioBus Input (SDAT/MDAT)
1x USB-C trivum AudioBus Output (MDAT)
2x Trigger Input/Output (3-pin beam connector)
1x Bluetooth / Wi-Fi antenna
1x Power (cloverleaf socket)
Amplifier
Class D, 2x 30W @ 4 Ohm
Power Supply
AC 100V-240V (max. 75 watts)
Idle power consumption (without active zone): 5 watts
Casing
Black painted steel sheet, 218 mm x 41 mm x 127 mm (WxHxD)
Weight (netto)
1,33 kg
