WPG MRPT89ACO Instructions Manual

Manual rotator / power tilter 1000 ac-voltage with high-duty tilt option
Hide thumbs Also See for MRPT89ACO:

Advertisement

Quick Links

Download this manual
KEEP FOR FUTURE REFERENCE
INSTRUCTIONS
International Version
P.O. Box 368 – 908 West Main
Laurel, MT USA 59044
MODEL NUMBER: MRPT89ACO
phone 800-548-7341
phone 406-628-8231
SERIAL NUMBER: ___________
fax 406-628-8354
(please see serial label and record number here)
MANUAL ROTATOR / POWER TILTER 1000
AC-VOLTAGE
WITH HIGH-DUTY TILT OPTION
READ ALL INSTRUCTIONS AND WARNINGS
BEFORE OPERATING THIS LIFTER
DESIGNED FOR THE MATERIALS HANDLING PROFESSIONAL
