Assembly and Operating

Instructions

max. 130 kg

~ 60 Min.

80 kg

L 172 | W 84 | H 145

FSDFTM40.02.03

Art.-No. DF-TM40-2

DARWIN

TM40

Need help?

Do you have a question about the TM40 and is the answer not in the manual?

Questions and answers

Summary of Contents for Darwin Fitness TM40

Page 1 Assembly and Operating Instructions max. 130 kg ~ 60 Min. 80 kg L 172 | W 84 | H 145 FSDFTM40.02.03 Art.-No. DF-TM40-2 DARWIN TM40...
Page 2 TM40...
Page 3 Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Programmes 3.3.1 Quick Start 3.3.2 Manual Programme 3.3.3 Pre-set Programmes 3.3.4 User Programmes Heart Rate Controlled Programmes Wireless Connection and Fitness Apps STORAGE AND TRANSPORT General Instructions...
Page 4 DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT TM40...
Page 5 Dear customer, thank you for choosing Darwin fi tness equipment. With Darwin fi tness equipment we off er fi rst class home sports equipment at a great price point. Darwin exercise bikes and strength machines are easy to use, have a space-saving design and look really good. With our equipment we want to support you in reaching your athletic goals, no matter if you want to lose weight or train for the national triathlon.
Page 6 (person with legal responsibility). Class H (home use): use at home. These stationary training devices are intended for the use in private homes where access to the training device is regulated by the owner (person with legal responsibility). TM40...
Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.
Page 8 182.5 cm x 87 cm x 29.5 cm Set-up dimensions (L x W x H): 172 cm x 83.5 cm x 145 cm Folded dimensions (L x W x H): 113.5 cm x 79.5 cm x 146 cm Maximum user weight: 130 kg Use class: TM40...
Page 9 Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.
Page 10 The software systems on gym equipment with TFT consoles are set up only for the pre- installed apps. Do not install any additional apps.  NOTICE The pre-installed apps on TFT consoles are produced and provided by external manufacturers. Fitshop does not take any responsibility for the availability, functionality or contents of these apps. TM40...
Page 11 Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Make sure that there is a safety area behind the treadmill with a length of at least 2 m and a width at least equal to the width of the treadmill. The training room should be well ventilated during training and not be exposed to any draughts.
Page 12 To prevent damage to the equipment and the fl oor, assemble the equipment on a mat or packaging board.  NOTICE In order to make the assembly as simple as possible, some screws and nuts to be used can already be pre-assembled. Ideally, assemble the equipment at its later set-up place. TM40...
Page 13 Scope of Delivery ⚠ WARNING There is a transportation lock that prevents the treadmill from opening during transport. This transportation lock must be removed before assembly. The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred.
Page 14 TM40...
Page 15 Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given.  NOTICE First loosely screw all parts together and check that they fi t properly. Tighten the screws using the tool only when you are instructed to do so.
Page 16 (103) and two bolts (104). ATTENTION Be careful not to pinch the cables in the following step. Connect the two cables (35 and 64) with one another and repeat the previous steps for the right upright post (63). TM40...
Page 17 Step 3: Assembly of the Handrail ATTENTION Be careful not to pinch the cables in the following step. Connect the two cables (64 and 86) on the right side of the console frame weld with one another. Assemble the console frame weld (24) to the upright posts (62 & 63) with four bolts (104).
Page 18 Assembly of the Console ATTENTION Be careful not to pinch the cables in the following step. Connect the cables (86 and 88) with one another. Insert the console fi xed welds (72) to the console frame weld (24) with four bolts (105). TM40...
Page 19 Step 5: Assembly of the Safety Key Set up the treadmill and tighten all bolts. Assemble the safety key (89).
Page 20 To step onto the treadmill, grip the handrails with both hands and step onto the treadmill one foot at a time. To get off , grip the handrails with both hands and step off the treadmill one foot at a time. TM40...
Page 21 OPERATING INSTRUCTIONS  NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Always start your training with low intensity and increase evenly and gently. End your training with a cool-down phase.
Page 22 Display of the training time in minutes Time Display range: 05:00–99:00 Display of the calories in kcal Calories Display range: 20–999 Display of the current speed in km/h Speed Display range: 1.0–20 Display of the current heart rate Pulse Display range: 80–220 TM40...
Page 23 Button Functions BUTTON DESCRIPTION START/PAUSE With this button you can start or pause a training programme. When you are in the main menu, you can start your training via quick start. When your training is paused, you can continue with your training by pressing this button.
Page 24  NOTICE During training, the speed/incline can be adjusted using the corresponding buttons. Press the START/PAUSE button to pause the training. Press the START/PAUSE button again to continue the training. Press the STOP button to end your training. TM40...
Page 25 3.3.3 Pre-set Programmes A total of 36 pre-set programmes (P01-P36) are available. When you are in the main menu, press the PROGRAM button to select one of the profi le programmes. Confi rm your selection with the MODE button. Adjust the training time using the +/- buttons and confi rm with the MODE button. Press the START/PAUSE button to start the training.
Page 26 Metric TM40...
Page 28 Imperial TM40...
Page 30 During training, the speed/incline can be adjusted using the corresponding buttons. However, the adjustment is only made for the segment you are currently training. Press the START/PAUSE button to pause the training. Press the START/PAUSE button again to continue the training. Press the STOP button to end your training. TM40...
Page 31 Heart Rate Controlled Programmes ⚠ WARNING Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can aff ect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. A total of 3 heart rate-controlled programmes are available (speed limit: 9 km/h, 11 km/h, 13 km/h).
Page 32 Just follow the instructions on the screen to perform the update. Please note: The system is set up only for the pre-installed apps. Do not install any additional apps as their proper functionality can not be guaranteed. The installation of other apps might cause technical issues. Example: Kinomap TM40...
Page 33 STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location.
Page 34 To release the hydraulic brake lock, use your left foot to push the upper part of the hydraulic brake slightly forward until the lock releases and the treadmill can be pulled back. Keep holding the treadmill. The hydraulic brake lowers itself gently downwards. Once the treadmill has lowered 2⁄3, you can let go of the treadmill. TM40...
Page 35 TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may aff ect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.
Page 36 ¼ turn anticlockwise. Then observe the mat for about 30 seconds, as the change is not immediately visible. Repeat this procedure until the running mat is straight again. If the running mat cannot be adjusted, please contact your contract partner. TM40...
Page 37 5.3.2 Re-tensioning the Running Mat If the running mat slips over the rollers during operation (if this is the case, there is a noticeable jerk during running), the running mat must be re tightened. In most cases, the slipping is caused by stretching of the mat through use. This is perfectly normal. ...
Page 38 The materials can be recycled as per their symbols. Through the reuse, recycling of materials or other forms of recovery of old equipment, you make an important contribution to the protection of the environment. TM40...
Page 39 RECOMMENDED ACCESSORIES To make your training experience even more effi cient and pleasant, we recommend that you add suiting accessories to your fi tness equipment. For treadmills this could for example be a fl oor mat, which makes your fi tness equipment stand more securely and also protects the fl oor from sweat or silicone spray to keep moving parts in good shape and lubricate the running mat.
Page 40 The serial number of your equipment is unique. It’s located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate fi eld. Serial number: Brand / Category: Darwin / treadmill Model Name: TM40 Article Number: DF-TM40-2 TM40...
Page 41 Parts List Name Specifi cation Qty. Base weldment "Hexagon large fl at M8×50×20 head half-tooth bolt" hexagon lock nut fl at washer Φ8 "Tapered foot pad (OMA-05-07-005)" Φ50×Φ41×17×M8×27 wheel Φ62×Φ8.0×t22 Curved open pipe plug 40×60×t2.0 frame weldment "Motor mount(1320CA-06)" "motor cover plate" fi xed tube of motor cover Φ16×t1.2×23 Hexagon cylindrical head full tooth bolt...
Page 42 3330EA motor cover rear cover 673×93×51 side rail 87×34.5×1342 wheel Φ62×Φ8.0×t22 cushion Round guide block Φ25×φ5×4.5 pipe strap Φ16 (white) EVA pad t15×30×30 magnet ring cable clip power cable clip upright post L welds upright post R welds 0.32 m TM40...
Page 43 communication line SM4PIN/SM4PIN/L- 1200mm/26# Lift frame welds "Hexagon head half-tooth bolt" M12×Φ14×35×19 "Hexagon large fl at head full tooth bolt" M10×25×15 "Powder metallurgy sleeve" Φ24×Φ19×Φ14×14×3 Sleeve Φ25×Φ18×t3.0 fl at washer Φ14 "Lifting shaft sleeve(OMA-05-06-023)" Φ25×Φ17×Φ10×6×1 "console fi xed welds" speaker grille t0.5×66×90/1260×3000 Cross recessed large fl at head tapping screw ST4×16...
Page 44 Φ88×Φ50×Φ17×606 "gas spring (OMA-01-03-039)" 720×318×Φ10×Φ8.2×350N shrapnel-1 t0.6×16.5×43 acrylic of display board keyboard cover "Hexagon large fl at head half-tooth bolt" M8×50×20 Hexagon large fl at head full tooth bolt M8×15 "Hexagon pan head full tooth bolt" M6×10 TM40...
Page 45 Exploded Drawing...
Page 46 Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty. TM40...
Page 47 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
Page 48 Sie unserer Homepage: Sie unserer Homepage: https://stg.fi t/statit6 https://stg.fi t/statitb https://stg.fi t/statit9 Please fi nd a detailed overview including address and opening hours for all stores of the Fitshop Group in Germany and abroad on the following website: www.fi tshop.com/en/stores TM40...
Page 49 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Fitshop is Europe’s largest specialist store for www.fi tshop.co.uk home fi tness equipment with currently over 70 www.fi tshop.de/blog stores and one of the world’s most renowned online mail order companies for fi tness equipment.
Page 50 Notes TM40...
Page 52 DARWIN TM40...
