Summary of Contents for Hifonics HFi Series
- Page 1 HFi100.2 / HFi55.4 / HFi100.4 HFi1000.1D / HFi1500D HFi2000D / HFi3000D...
- Page 2 HFi HIGH PERFORMANCE AMPLIFIERS The HFi Series products have been designed to a very high level of performance, with features unavailable in any other product. All of the amplifiers have variable crossovers built in, with added touches such as subsonic filter, bass equalization and a remote Level control module(some models) that allows subwoofer Level control from the drivers seat.
- Page 3 Power and ground connections(see the features matrix on page 7 for proper gauge cables per amplifier): Use a sufficient gauge power cable and ground cable using the chart below as reference to what size wire you require. HFi series amplifiers require at least 4 gauge power wire.
- Page 4 ! Each model is capable of 4 & 2-Ohms stereo per channel, or 4-Ohms mono bridged operation ! All Hifonics amplifiers feature a comprehensive diagnostic system, with speaker lead short circuit, except the mono amps which are capable of 4, 2 and 1-Ohm loads.
- Page 5 HFi100.2 2 CHANNEL AMPLIFIER APPLICATIONS FULL RANGE STEREO This is the most basic application for the HFi Series 2 channel amplifiers. 4. MODE: Should be in the STEREO position. 1. Interconnect cable checklist: 5. Line Level: Connect the LINE INPUTS to the Radio/CD with good quality RCA cables.
- Page 6 2 or 3 CHANNEL SYSTEM Here we show how to use the 4 channel amplifiers as a 3 channel unit by taking Switch setting checklist: advantage of the mono bridging capability of all Hifonics amplifiers. - 1/2CH X-OVER: FULL - 3/4CH X-OVER: LPF The following example shows how to create a 3 channel system by mono bridging channel pair 3 / 4.
- Page 7 HFi55.4 / HFi100.4 4-CHANNEL AMPLIFIER APPLICATIONS Front/Rear high pass, using a 2 channel amplifier for mono sub bass The combination of a 2 and a 4 channel amplifier, utilizing their built in Channels 1/2: crossovers, makes it a snap to put together a full system with front and rear - HI PASS: 100 Hz highs, with mono sub bass.
- Page 8 HFi1000.1D / HFi1500D / HFi2000D / HFi3000D MONO AMPLIFIER APPLICATION Basic application These sub bass amplifiers can be used in any of the bi-amplification systems described in Crossover frequency control checklist: this manual, replacing the 2 channel amplifiers as per the illustrations. LOW PASS: 35Hz to 250Hz SUBSONIC:15 Hz to 35 Hz Interconnect cable checklist:...
- Page 10 SETTING UP SYSTEMS AFTER INSTALLATION FOR BEST PERFORMANCE HFi100.2 / HFi55.4 / HFi100.4 General: At this point you are ready to get more specific on the settings for your amplifier. High Pass: -When in Hi Pass operation, this setting acts as a low frequency cut off for your system reproduction. The point that you set it at cuts off any frequencies from reproduction beyond this point.
- Page 11 The key to finding the problem in a misbehaving sound system is to isolate parts of that system in a logical fashion to track down the fault. Description of the PROTECT system built into all Hifonics amplifiers The diagnostic system will shut down the amplifier, until reset by turning the head unit off, and back on. This state of affairs will be indicated by the front panel PROTECT LED lighting up under the following conditions: 1 - A sort circuit on the loudspeaker leads.
- Page 12 Maxxsonics Limited Warranty As the manufacturer of Maxxsonics, MB Quart, Autotek, Crunch and Hifonics car audio products, Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier to be free from defects in material and workmanship for one (1) Year from date of purchase.
- Page 13 OEM Integration Accessories MX-1 Premium High To Low Level Converter MX-3 Bass Controller * Converts High Level OEM speaker wires to Ultra Clean RCA Low Level Outputs * High Level Inputs: Accepts all types of High level Inputs * Parametric Bass EQ: Provides a wide array of subwoofer output signal including floating ground and high voltages up to 30 volts.
- Page 14 Accessories SLAVE MASTER 35Hz 250Hz 15Hz 35Hz RED - CLIP TEST TONE MODE LOW PASS OUTPUT SUBSONIC GREEN - 9V 65Hz FILTER LEVEL FILTER 24 dB/OCT 24 dB/OCT MAXX-LINK MLX-100 0.2V +10 dB 30Hz 100Hz INPUT PHASE BOOST BANDWIDTH FREQUENCY LEVEL PARAMETRIC BASS EQ -6dB...
- Page 15 PART#: A1110...
