Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. LG WM2277HB Owner's Manual Shop genuine replacement parts for LG WM2277HB Find Your LG Washer Parts - Select From 393 Models -------- Manual continues below --------...
Page 2 Website: http: //www.LGEservice.com E-mail: http: //www.LGEservice.com/techsup.html WASHING MACHINE SERVICE MANUAL CAUTION READ THIS MANUAL CAREFULLY TO DIAGNOSE PROBLEMS CORRECTLY BEFORE SERVICING THE UNIT. MODEL: WM2277H*/WM2077CW WM2177H*/WM2677H*M WM2477H*/WM2377C* WD-11270BD...
Page 3 JUL. 2006 PRINTED IN KOREA P/No.: MFL30599103...
Page 4 CONTENTS 1. SPECIFICATIONS .........................3 2. FEATURES & TECHNICAL EXPLANATION ................4 3. PARTS IDENTIFICATION ......................7 4. INSTALLATION & TEST ....................... 8 5. OPERATION ..........................11 6. WIRING DIAGRAM/PROGRAM CHART ..................14 7. TROUBLESHOOTING.........................17 7-1. BEFORE PERFORMING SERVICE ...................17 7-2. QC TEST MODE.........................17 7-3.
Page 5 1. SPECIFICATIONS WM2277H* ITEM WM2077CW WD-11270BD WM2677H*M WM2177H* WM2377C* WM2477H* COLOR W: BLUE WHITE, B: BLACK PEARL, S: TITANIUM POWER SUPPLY AC 120 V, 60 Hz PRODUCT WEIGHT 190 lbs. (86 kg) WASHING 280 W ELECTRIC POWER DRAIN MOTOR 80 W CONSUMTION WASH HEATER 1000 W...
Page 6 2. FEATURES & TECHNICAL EXPLANATION 2-1. FEATURES Direct Drive System ■ The advanced Brushless DC motor directly drives the drum without belt and pulley. Tilted Drum and Extra Large Door Opening ■ Tilted drum and extra large door opening make it possible to load and unload easily.
Page 7 2-2. NEURO FUZZY WASHING TIME OPTIMIZATION To get the best washing performance, optimal time is determined by the water temperature, the selected washing temperature, and the size of the load. water temperature washing time the best selected NEURO- washing washing rinsing time temperature FUZZY...
Page 8 2-5. THE DOOR CAN NOT BE OPENED ● While program is operating ● When a power failed and power plug is taken out in operation ● While Door Lock lights turn on. ● White the motor is in the process of intertial rotating, through the operation is paused. 2-6.
Page 9 3. PARTS IDENTIFICATION Water Circulation Nozzle Safety Cover (PLC Moderm) ■ ACCESSORIES...
Page 10 4. INSTALLATION & TEST 1⃞ Before servicing, ask the customer what the trouble is. 2⃞ Check the setup (power supply is 120 V AC, remove the transit bolts..). 3⃞ Check with the troubleshooting guide. 4⃞ Plan your service method by referring to the disassembly instructions. 5⃞...
Page 11 ■ HOW TO CONNECT THE INLET HOSE Verify that the rubber washer is inside of the valve connector. Tighten the inlet hose securely to prevent leaks. ■ CONNECT THE DRAIN HOSE · Make sure that the hose is not twisted. ·...
Page 12 TEST OPERATION Preparation for Press the POWER button. Press the Start/Pause washing. button. Connect the power plug to Listen for a click to determine if the outlet. the door has locked. Connect the inlet hoses. Check the water heating Check the automatic Check the water supply.
Page 13 5. OPERATION ■ WM2277H*/WM2177H*//WM2477H* SPINSENSE WATER PLUS ■ WM2077CW//WM2377C* SPINSENSE WATER PLUS ■ WM2677H*M...
Page 14 • Use this option to preve • Use this button to turn the power • This display shows: Press and hold PRE W On/Off. a) the estimated time remaining in the lock/unlock control. cycle when operating. • When Child lock is set, b) an error code when an error has been buttons are disabled ex detected.
Page 15 ent unwanted use of the washer. • These lights show which portion of WASH button for 3 seconds to • Allows the start of any cycle the cycle the washer is operating. to be delayed for 1~12 hours. CHILD LOCK lights and all xcept the Power button.
Page 16 6. WIRING DIAGRAM PROGRAM CHART ■ WM2277H*//WM2477H* ■ WM2077CW//WM2377C*...
Page 17 ■ WM2177H* 1 2 3 1 2 3 NOISE FILTER 1 2 3 1 2 3 POWER CORD ■ WM2677H*M CON3 CON2 CON1 DISPLAY PWB 2 3 4 5 6 7 8 9 10 11 2 3 4 5 6 7 8 9 10 11 12 13 2 3 4 5 6 7 8 9...
Page 18 Cool-down **Approx. (Minutes) * Wash time is in minutes. ** The total working time will vary with the load size, water temperature and ambient temperature.
Page 19 7. TROUBLESHOOTING 7-1. BEFORE PERFORMING SERVICE ■ Be careful of electric shock when disconnecting parts while troubleshooting. ■ The voltage of each terminal is 110/120 V AC and DC when the unit is plugged in. 7-2. QC TEST MODE. The washer must be empty and the controls must be in the off state. 1.
Page 20 7-4. ERROR DISPLAY If you press the START/PAUSE button when an error is displayed, any error except d e will disappear and the machine will go into the pause status. In case of d e , d e , d e if the error is not resolved within 20 sec., or the in case of other errors, if the error is not resolved within 4 min., power will be turned off automatically and the error code will blink.
Page 21 ERROR SYMPTOM CAUSE OVER • MAIN PWB ASSEMBLY is out of order. CURRENT • Winding in the STATOR ASSEMBLY is short-circuited. ERROR • The connector (3-pin, male, white) in the MOTOR HARNESS is not connected to the connector (3-pin, female, white) of STATOR ASSEMBLY. •...
Page 22 8. ERROR DIAGNOSIS AND CHECK LIST 8-1. DIAGNOSIS AND SOLUTION FOR ABNORMAL OPERATION SYMPTOM GUIDE FOR SERVICE CALL No power Is the power plug connected firmly to 120 V AC outlet? Power failure? or Breaker opened? Is the outlet controlled by a switch? Visit to service.
Page 23 SYMPTOM GUIDE FOR SERVICE CALL Door error Was the load too large? Visit to service. Drain trouble Visit to service.
Page 24 SYMPTOM GUIDE FOR SERVICE CALL Suds overflow from the Is a low-sudsing detergent used? appliance. (In this condition, wash and spin do not operate normally) LOW-SUDSING Is the proper amount of detergent used as recommended? Recommend to reduce the amount of detergent.
Page 25 8-2. FAULT DIAGNOSIS AND TROUBLESHOOTING CAUTION 1. Be careful of electric shock if disconnecting parts while troubleshooting. 2. First of all, check the connection of each electrical terminal with the wiring diagram. 3. If you replace the MAIN PWB ASSEMBLY, reinsert the connectors correctly. NO POWER Check the fuse or reset Is the supplied voltage 110/120 V AC?
Page 26 VIBRATION & NOISE IN SPIN Have all the transit bolts and base packing Remove the transit bolts been removed? and Base packing. Is the washer installed on a solidly constructed Move the washer or floor? reinforce the floor. Check if the washer is perfectly level as follows: Base Packing Level Check the leveling of the washer with a Level...
Page 27 If it still has severe vibration and noise, regulate a specific spin speed that generates excessive vibration and noise as follows: 1) Put an unbalance part (rubber) inside of the drum. 2) Start the QC test mode (Refer to section 7-2). 3) Press Delay Wash button, then ‘...
Page 28 NO WATER SUPPLY Is water supply shut-off? Is the tap opened? Open the tap. When you press both SPIN SPEED button and Check the AIR CHAMBER SOIL LEVEL button simultaneously, is the water and the tube (clogged). level frequency below 246? Is the inlet valve filter clogged? Clean the filter.
Page 29 LIQUID DETERGENT/SOFTENER/BLEACH DOES NOT FLOW IN Refer to Is water supplied? Prewash Bleach ^NO WATER SUPPLY_ Hot water Check the wiring on the Are the plugs correctly connected to the terminals of dispenser. the INLET VALVE ASSEMBLY? Main wash Put it in the correct Is liquid detergent/softener/bleach put in the correct compartment.
Page 30 HEATING WITHOUT WATER When pressing SPIN SPEED and SOIL LEVEL at the same time after draining, is the water level frequency Replace the 255? SENSOR SWITCH When pressing SPIN SPEED and SOIL LEVEL buttons ASSEMBLY. at the same time while washing, is the water level frequency between 230 - 243 ? Replace the MAIN PWB Check the voltage between two pins while pressing...
Page 31 WASH HEATER TROUBLE HEATING CONTINUOUSLY ABOVE THE SETTING WATER TEMPERATURE Extra Hot: 70 °C Push the THERMISTOR When checking the THERMISTOR on the tub, tightly to the rubber. is the THERMISTOR loose?
Page 32 WILL NOT CIRCULATE WATER Is the impeller of the drain pump clogged? Remove foreign material. Hose Connector Hose (White) Remove foreign material. Are the Hose Connector and/or Hose clogged? Reconnect or repair Is the connector disconnected, disassembled? the connector. Connector Connector Is the coil of the right side of drain pump open Replace PUMP MOTOR...
Page 33 SPIN TROUBLE Check the SENSOR SWITCH ASSEMBLY or HOSE (Pressure). Check during spin if the frequency of the water If the problem is on the SENSOR level is 248 or more. SWITCH ASSEMBLY or the HOSE, replace the SENSOR SWITCH ASSEMBLY or the HOSE.
Page 34 9. DISASSEMBLY INSTRUCTIONS Be sure to unplug the machine out of the outlet before disassembling and repairing the parts. CONTROL PANEL ASSEMBLY TOP PLATE ASSEMBLY ① ① Unscrew 2 screws on the back of the top plate. ② ② Pull the top plate backward and upward as shown. ③...
Page 35 MAIN PWB ASSEMBLY ① ① Disconnect the POWER connector and SENSOR SWITCH ASSEMBLY. ② ② Remove the Protect Cover. PROTECT COVER ③ ③ Disconnect the connectors. ④ ④ Unscrew 1 screw on the back. ⑤ ⑤ Disassemble the Main PWB.
Page 36 DISPENSER ASSEMBLY ① ① Disassemble the top plate assembly. ② ② Pull out the drawer. ③ ③ Push out the DISPENSER ASSEMBLY after unscrew 2 screws. ④ ④ Unscrew the nut at the lower part of the dispenser. ⑤ ⑤ Disassemble the 4 connectors from the valves. ※...
Page 37 CABINET COVER ① ① Unscrew the 4 screws from upper of the canbinet cover. ② ② Unscrew the screw from filter cover. ③ ③ Put a flat ( - ) screwdriver or putty knife into the both sides of the filter cover, and pull it out. ④...
Page 38 ⑤ ⑤ Open the door. ⑥ ⑥ Disassemble the clamp assembly. ⑦ ⑦ Tilt the cabinet cover. ⑧ ⑧ Disconnect the door switch connector. ※ ※ NOTE: When assembling the CABINET COVER, connect the connector. ⑨ ⑨ Lift and separate the cabinet cover. ⑩...
Page 39 DOOR ① ① Open the door. ② ② Unscrew the 7 screws from the HINGE COVER. ③ ③ Put a flat ( - ) screwdriver into the openng of the hinge, and pull out the hinge cover. ④ ④ Unscrew a screw from the lower side of door. ⑤...
Page 40 PUMP ① ① Disassemble the cabinet cover. ② ② Separate the pump hose, the bellows and the circulation hose assembly from the pump assembly. ③ ③ Disassemble the pump assembly in arrow direction. HEATER ① ① Disassemble the cabinet cover. ②...
Page 41 WHEN FOREIGN OBJECT IS STUCK BETWEEN DRUM AND TUB ① ① Disassemble the cabinet cover. ② ② Separate the heater from the tub. ③ ③ Remove any foreign objects (wire, coin, etc.) by inserting a long bar in the opening. MOTOR/DAMPER ①...
Page 42 10. EXPLODED VIEW 10-1. CABINET & CONTROL PANEL ASSEMBLY F215 A485 F210 F110 A455 A450 A104 A105 A106 A102 A111 A110 A410 A103 A150 A154 A152 A101 A141 A390 A151 A153 A100 A131 A130 A430 A140 A133 A440 A155 A300 A310 A201 A220...
Page 43 10-2. DRUM & TUB ASSEMBLY K143 K123 K350 K360 K351 F140 K610 K411 K410 K611 K115 F466 K110 K141 K111 K140 F315 F310 F465 F463 K122 F464 K125 K130 K320 K530 K310 K121 K510 K311 K105 K135 K131 K340 F467 K520 F468 K550...
Page 44 10-3. DISPENSER ASSEMBLY F323 F322 F462 F321 F300 F170 F160 F227 F226 F225 F436 F430 F220 F431 F441 F440 F435 F120 HOT (RED) A275 F130 COLD (BLUE) A276 F432...
