User Manual
TMP125
USB Temperature Sensor
Model name
USB-TMP125
USB-TMP125-CAL
VCP-TMP125
VCP-TMP125-CAL
HS code: 8471.60.10.50
Part number Description
601000
USB temperature sensor
608000
USB temperature sensor – calibratable
603000
USB temperature sensor – with VCP mode
605000
USB temperature sensor – calibratable
with VCP mode
Advertisement
Table of Contents
Related Manuals for Dracal Technologies TMP125
Summary of Contents for Dracal Technologies TMP125
- Page 1 User Manual TMP125 USB Temperature Sensor Model name Part number Description USB-TMP125 601000 USB temperature sensor USB-TMP125-CAL 608000 USB temperature sensor – calibratable VCP-TMP125 603000 USB temperature sensor – with VCP mode VCP-TMP125-CAL 605000 USB temperature sensor – calibratable with VCP mode...
-
Page 2: Table Of Contents
6 Installation and Setup 6 Usage Guidelines and Applications 9 Care, Storage, and Recalibration 9 Troubleshooting Guide and Support 10 Return Process and Warranty Information 10 Accessories and Peripherals 10 Disassembly and Environmental Considerations 11 Document Revision History Dracal Technologies Inc. -
Page 3: Compliance Certification
Type of Equipment: USB sensor CE Marking: No Compliance with Directives RoHS3 Directive (2011/65/EU, 2015/863) The USB Sensor Model TMP125 complies with the requirements of the RoHS Directive, restricting the use of hazardous substances in electrical and electronic equipment. Technical Documentation... -
Page 4: Overview
Overview At Dracal Technologies, we want to democratize access to precision data to engineers and scientists to ease their lives so they achieve their goals more quickly. We believe that precision data should not be compromised by ease of use. -
Page 5: Product Overview And Specifications
Product Overview and Specifications Product Overview The TMP125 is a USB temperature sensor designed for accuracy and reliability. With its precision temperature chip, the TMP125 can measure temperatures as low as -55°C with precision and a resolution of 0.0625°C. The sensor’s probe is coated to protect against dust, moisture, and splashes, making it suitable for harsh environments. -
Page 6: Safety Guidelines
Connect an instrument. Launch DracalView. Verify the instrument appears in the Sources tab. Modify units and decimals in the Configuration tab (Optional). Customize the names of channels to record in the Sources tab (Optional). Visualize data on GraphView. Dracal Technologies Inc. - Page 7 Please refer to the TMP125 page for the complete guide, specifically the “Software & Documentation” tab. Of note, to log data with DracalView, these are the remaining main steps of the Getting Started guide: Initiate the logging task in the Logging tab.
- Page 8 DracalView and the command-line tools. For additional information, please click the relevant link in the Software & Documentation section of the TMP125 page. Calibration “-CAL” suffix: If present, the product is equipped with a 3-point user-calibration mechanism.
-
Page 9: Care, Storage, And Recalibration
If the instrument has a “-CAL” suffix, it can be adjusted for accuracy during the calibration. The long-term drift of the TMP125 is minimal. Therefore, depending on the user’s application, an adjustment might be required more frequently. Troubleshooting Guide and Support... -
Page 10: Return Process And Warranty Information
In most cases, there will be an easy solution. In the rare event of a faulty instrument under warranty, Dracal Technologies will proceed to a replacement upon evaluating the situation. The procedure will be explained through email once the customer advises support@dracal.com. -
Page 11: Document Revision History
REACH Compliance These USB sensors comply with REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulations, meeting European safety and environmental impact standards. Document Revision History Version 1.0 2024-02-08 Creation of the User Manual. TMP125 – USB Temperature Sensor... - Page 12 +1 450.812.8612 Dracal Technologies Inc. A204 - 7900 Taschereau Blvd Brossard (Quebec) J4X 1C2 Canada...
