- Page 1 M5AtomS3R Model: AtomS3R Lite 2024...
- Page 2 CONTENTS 1.OUTLINE ........................3 1.1. AtomS3R Lite...................... 3 SPECIFICATIONS....................... 4 2.1. Product Size....................... 5 QUICK START......................6 3.1. SCAN Wi-Fi......................7 SCAN BLE Device....................8 4. FCC Warning......................9...
- Page 3 1. OUTLINE The ATOMS3R Lite is a programmable controller from the M5Stack development kit series, featuring an ESP32 as the main controller. It measures only 24 * 24 * 9.6 mm and utilizes the ESP32-S3-PICO-1-N8R8 solution, which includes 8MB of PSRAM and 8MB of SPI flash memory. It integrates Wi-Fi and Bluetooth 5.0 (LE) functionality and has a built-in 3D antenna, a 5V to 3.3V power circuit, an infrared...
- Page 4 Output Power 21.76dBm BLE Working Frenquency 2402MHz-2480MHz(BLE 1M/2M) BLE Maximum Conducted Peak Output Power 8.71dBm Rated Current 0.5A Manufacturer M5Stack Technology Co., Ltd 501, Tangwei Business Building, Tangwei Manufacturer address Community, Fuhai Street, Bao’an District, Shenzhen, China 2.1 Product Size...
- Page 5 3. QUICK START 3.1. Print WiFi information 1. Open Arduino IDE (Refer to https://docs.m5stack.com/en/arduino/arduino_ide for the installation guide for the development board and software) 2. Press and hold the reset button for 2 seconds until the green light turns on 3.
- Page 6 3. QUICK START 3.1. Print BLE information 1. Open Arduino IDE (Refer to https://docs.m5stack.com/en/arduino/arduino_ide for the installation guide for the development board and software) 2. 2. Press and hold the reset button for 2 seconds until the green light turns on 3.
- Page 7 4. FCC Warning FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
