MODEL M690 / M690-ES
PORTABLE CADAVER SCISSOR LIFT
with ROLLERS
CAUTION
Inspect unit and all components
for any loosening that may have
occurred during shipping
ATTENTION
Review entire manual before
starting assembly
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
Installation and Operating Instructions
CAUTION
DO NOT USE CLEANERS
CONTAINING CHLORINE WHEN
CLEANING STAINLESS STEEL
ATTENTION
All images and Drawing in this manual
may not represent your model.
Refer to your particular project for
exact specifications
Technical Users' Manual
NOVEMBER 2019
ISO Doc. #OMM690 (REV. E)
Advertisement
Summary of Contents for MORTECH M690
- Page 1 Technical Users’ Manual Installation and Operating Instructions MODEL M690 / M690-ES PORTABLE CADAVER SCISSOR LIFT with ROLLERS CAUTION CAUTION DO NOT USE CLEANERS Inspect unit and all components CONTAINING CHLORINE WHEN for any loosening that may have CLEANING STAINLESS STEEL...
- Page 2 • Is unit draining properly? WARNING • Are all nuts, bolts, and pins secured in place? It is crucial that any work performed on Mortech If unit has an issue contact Mortech Manufacturing Inc. Manufacturing Inc. manufactured items are carried out...
- Page 3 • Accommodates body trays that are 23 to 30 in. (58 to 76 cm) wide with flat bottoms M690 Standard End Load M690SC Standard End Load w/Scale • Designed to extend from a minimum height of 15 in.
- Page 4 Installation M690 Portable Cadaver Scissor Lift w/Rollers SIDE-HANDLE OPERATION Remove quick-release pins securing handle from handle bracket HANDLE REMOVAL After removing quick-release pins, pull handle gently up and away from bracket and frame Gently lift up and away Side handle...
- Page 5 Parts listing M690 Portable Cadaver Scissor Lift w/Rollers M690 Handset (Lift Controller) Locking Latch Steel Rollers Control Station Side Handle Bracket (1) 6” Directional Caster (caster with directional locking mechanism will have a darker grey green tab) Piston Acuator Mechanism M690-ES (3) 6”...
- Page 6 Operation M690 Portable Cadaver Scissor Lift w/Rollers Charging and Control Station Rechargeable Battery Cord Hand Held Push Button Lift Controller CAUTION Piston Acuator When lift is not in operation, the unit’s battery must be recharging Cord Rechargeable Battery Cord To charge battery, plug cord into any wall receptacle.
- Page 7 Operation M690 Portable Cadaver Scissor Lift w/Rollers Hand Held Push Button Lift Controller To operated lift, press arrow UP button to elevate. Press arrow DOWN button to lower lift. DOWN M690 M690-ES Side/End Load CAUTION When operating lift, keep hands and feet clear of moving parts.
- Page 8 Operation M690 Portable Cadaver Scissor Lift w/Rollers M690-ES TRAY LATCHES Tray latches are simple to operate. To load and unload the trays, release tray latches. End Loading Side Loading Flip tray latches up to restrict Flip tray latches downward to...
- Page 9 (2) is restrained, the piston which always run off battery and control boxes with battery rod will move forwards or backwards, when the threaded backup. Contact your Mortech for specification of type, spindle rotates. size etc.
- Page 10 M690 Portable Cadaver Scissor Lift w/Rollers Maintenance • The products must be cleaned at regular intervals to re- Valid for control box and handset move dust and dirt and inspected for mechanical damage, • Electronics must be inspected at attachment points, wires, wear and breaks.
- Page 11 M690 Portable Cadaver Scissor Lift w/Rollers Maintenance USE AND CARE FOR CASTERS 1. To engage brake mechanism, depress brake mechanism down, until you feel it lock. To release brake mechanism press forward to return for range of motion. Mechanisms are located on all (4) wheels.
- Page 12 M690 Portable Cadaver Scissor Lift w/Rollers Maintenance DIRECTIONAL CASTERS USE & CARE: 1. To engage directional locking mechanism, press GREY tab down and straighten/adjust wheel to lock in direction. To disengage multi- directional movement, PUSH down GREEN tab located on wheel.
- Page 13 Stainless steel equipment maintenance MAINTENANCE INSTRUCTIONS had time to oxidize or decompose. The preferred solvent is one that does not contain chlorine, such as acetone, methyl The unit requires regular maintenance and follow the alcohol, and mineral spirits. manufactures directions. EFFECTIVE CLEANING METHODS DISINFECTING AND CLEANING Commercial Cleaners - Many commercial cleaners...
- Page 14 Maintenance record MAINTENANCE RECORD Date...
- Page 15 Training record TRAINING RECORD Date...
- Page 16 PARTS AND SERVICE Information in this Manual is subject to change without notice Customer relations and product support are important and does not represent a commitment on the part of Mortech aspects of Mortech Manufacturing. Inc. Manufacturing. Inc. Mortech Manufacturing. Inc. assumes...
