User Guide
SPECIFICATIONS
PRECAUTIONS
PREPARATION
FLEX Top View Series
Operating
Model
Power
DC12V
FLEX T10100
DC12V
FLEX T20100
*Electronic dimming control is supported
10 mm
Lead Wire (Red +, White -)
31.2 mm
5±1
mm
20 mm
Lead Wire (Red +, White -)
62.4 mm
10±1 mm
Use precautions to avoid damages to the product or injuries of users. Any actions against following contents will cause serious
issues such as malfunction, electric shock, or burn.
DC12V
USE DC12V ONLY
AC INPUT
DO NOT USE AC INPUT
Do not cut or rejoion wires while product
is connected wth live power source
Avoid performing installation under rain or
high humidity for outdoor use
Do not use the product under circumstances
listed below
- High temperature spots over 60˚C (140˚F)
- Spots draw extreme moisture or dust
- Spots have corrosive gas or highly effectied
by electromagnetic field
TOOLS REQUIRED
Wire Stripper, Drill, Screw Driver, Wiper
PREPARE CHANNELS
1. Clean moisture and dust inside
1. Wipe out dust, water, and oil inside. 3M tape will come off easily if product is mounted on uncleaned surfaces.
2. Make holes for wires from modules to SMPS.
3. Without bushins, wires will easily be cut and short-circuit will occur.
*Use white paint inside the channels for better reflection
DAEHANTRANS CO.,LTD
#7-11 Songdo-Dong, Yeonsu-Gu, Incheon, Korea
Tel. +82 32 858 0491 Fax. +82 32 832 8421 enquiry@daehantrans.com / www.daehantrans.com
Power
Weight
Consumption
6.0W
75g
3.0W
60g
Front
Cut Mark
LED Lamp
1000±1
mm
Top
Front
Cut Mark
LED Lamp
1000±1 mm
Top
SUPPLIES REQUIRED
Wire Nuts, Cable Ties, IDC Connectors, VCTF(PLTC) Cable,
Super Glue, Silicon(optional)
2. Make holes
Min Bending
Viewing
Radius
Angle
R30mm
120°
R30mm
120°
4.5 mm
Left
4.5 mm
3cut
Left
Do not perform actions listed below
- Alter or modify
- Touch LED lamps with sharp objects
- Put glue or silicon over the LED lamps
Maximum driver quantity per serial
connection is limited. Failure causes overload
of current and damages to the product
Refer to 'WIRE THICKNESS' table to use proper
wire thickness between SMPS and the first
LED module
Failure will cause dimmed output
Cable length between SMPS and the first LED
module is limited. Refer to 'CONNECTION
WITH POWER SUPPLY' on page 2
3. Use bushing to protect wires
1
Max Serial
Connection
3M
3M
Advertisement
Related Manuals for DAEHAN FLEX T10100
Summary of Contents for DAEHAN FLEX T10100
- Page 1 Viewing Max Serial Model Weight Power Consumption Radius Angle Connection DC12V 6.0W R30mm FLEX T10100 120° DC12V 3.0W R30mm 120° FLEX T20100 *Electronic dimming control is supported 10 mm Lead Wire (Red +, White -) Front Cut Mark LED Lamp 4.5 mm...
- Page 2 FLEX Top View Series User Guide BEFORE HANDLING UNITS Do not flex or bend units with less than 15mm in radius, 30mm in diameter. Refer to left illustration. R30mm When stored in cold weather, units are stiff. Connect them with power supplies and wait until they become soft enough to be easily fabricated.
- Page 3 Refer to ‘LAYOUT DENSITY GUIDELINES’ on page 2 to determine spacing and amount of LEDs required. Ask us to obtain accurate layout 2. CUT INTO REQUIRED LENGTH FLEX T10100 CAUTION When handling the module, avoid twisting or bending unit in Cut only at less than R30mm(60mm in diameter) ‘CUT MARK’...
- Page 4 FLEX Top View Series User Guide LAYOUT GUIDE TROUBLE SHOOTING Entire sign or leg does not light after Check connection from power supply lead to first module. Make sure polarity of connections made at the complete installation. power supply lead and any jumper wire is correct. Power supply outputs should be connected red-to-red and white-to-white.
